MK-5 EDI Module – 5.0 m³/h Chemical-Free Electrodeionization Module for High Resistivity Ultrapure Water Production
Product Details:
| Place of Origin: | China |
| Brand Name: | VEOLIA |
| Certification: | ISO 14001， CE ，ISO 9001 |
| Model Number: | MK-5 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard Export Wood Crate/Carton or Naked wrapped by film |
| Delivery Time: | 7 work days |
| Payment Terms: | T/T,Western Union,Paypal etc. |
| Supply Ability: | 200 Units per Month |
|
Detail Information |
|||
| Membrane Material:: | Hydrophilic PVDF (XP™) | Name: | MK-5 |
|---|---|---|---|
| Voltage: | 0–400 VDC | Dilute Inlet/Outlet Standard Pressure Drop (Bar) Of MK-5: | 1.4-2.8 |
| Inlet Pressure (Bar) Of MK-5: | Counter-current: 4.1-6.9 Co-current: 3.1-6.9 | Nominal Flow Rate: | 5.0 M3/h (22 Gpm) |
| Designed Water Production (M3 /Hr): | 4.0-6.4 | ||
| Highlight: | 5.0 m³/h EDI Module,Chemical-Free Electrodeionization Module,High Resistivity Ultrapure Water Production System |
||
Product Description
The MK-5 Industrial Electrodeionization (EDI) Module is a high-efficiency purification unit developed for continuous production of high-quality ultrapure water in industrial environments.
Combining electrodialysis technology with ion exchange purification, the module removes dissolved ions through electrically driven membrane separation while continuously regenerating the ion exchange media through water electrolysis. This advanced process eliminates the requirement for traditional acid and chemical regeneration.
With a typical operating capacity of 4.0-6.4 m³/h, the MK-5 provides stable and reliable ultrapure water production for industries where consistent water quality is essential, including semiconductor manufacturing, power generation, pharmaceutical production, and advanced industrial processes.
Designed with a compact structure and proven operating reliability, the module can be easily integrated into new water treatment systems or used as a replacement solution for existing EDI installations.
- Produces ultrapure water without acid or caustic regeneration
- Reduces chemical consumption and operational complexity
- Provides environmentally friendly purification performance
- Delivers consistent product water quality
- Resistivity performance: ≥ 16 MΩ·cm
- Suitable for applications requiring high ionic removal efficiency
- Nominal production capacity: 5.0 m³/h
- Compact module dimensions: 30 * 61 * 72 cm
- Suitable for space-efficient system integration
- Designed for continuous-duty operation
- Maintains stable performance under varying feed conditions
- Compatible with large-scale industrial water treatment systems
| Parameter | Specification |
|---|---|
| Product Model | MK-5 |
| Technology | Electrodeionization (EDI) |
| Nominal Flow Rate | 5.0 m³/h |
| Operating Flow Range | 4.0-6.4 m³/h |
| Operating Voltage | 0-400 VDC |
| Operating Current | 0-5.2 ADC |
| Maximum Inlet Pressure | 6.9 bar (100 psi) |
| Recovery Rate | Up to 97% |
| Dimensions (W * H * D) | 30 * 61 * 72 cm |
| Weight | Approx. 165 kg |
| Parameter | Performance |
|---|---|
| Product Water Resistivity | ≥16 MΩ·cm |
| Sodium Removal | ≤3 ppb |
| Sodium Removal Efficiency | ≥99.9% |
| Silica Concentration | ≤5 ppb |
| Silica Removal Efficiency | Up to 99% |
| Boron Concentration | ≤0.08 ppb |
| Boron Removal Efficiency | Up to 96% |
| Parameter | Maximum Value |
|---|---|
| Total Exchangeable Anions | ≤65 ppm as CaCO₃ |
| Total Hardness | ≤1.0 ppm as CaCO₃ |
| Silica (SiO₂) | ≤1.0 ppm |
| Total Organic Carbon (TOC) | ≤0.5 ppm |
| Operating Temperature | 4.4-40°C |
The MK-5 EDI Module is suitable for industries requiring reliable ultrapure water production, including:
- Semiconductor manufacturing and wafer cleaning
- Solar photovoltaic production
- High-pressure boiler feed water systems
- Green hydrogen electrolysis facilities
- Petrochemical process water treatment
- Pharmaceutical and biotechnology water systems
- Industrial ultrapure water plants
| Feature | Benefit |
|---|---|
| EDI Technology | Continuous ion removal without chemical regeneration |
| High Recovery Rate | Improved water utilization efficiency |
| High Resistivity Output | Meets demanding ultrapure water requirements |
| Compact Structure | Easy installation and system integration |
| Low Chemical Demand | Reduced operating cost and environmental impact |
| Stable Performance | Reliable operation for critical industries |
The MK-5 provides an efficient and sustainable solution for continuous ultrapure water production. With high recovery performance, compact design, and chemical-free operation, it is an ideal choice for industries requiring dependable high-purity water systems.
