Ionpure CEDI LX-Z IP-LXM45Z-5 For Electronics Food Beverage Industry
Product Details:
| Place of Origin: | China |
| Brand Name: | IONPURE |
| Certification: | CE |
| Model Number: | IP-LXM45Z-5 |
| Document: | fgwater-ionpure-lxz-ds.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiable |
| Packaging Details: | standard export packing |
| Delivery Time: | 5- 8 work days |
| Supply Ability: | 60000 Units per Month |
|
Detail Information |
|||
| IP-LXM45Z-5 Minimum Flow Rate M3/hr (gpm) Of The Module: | 2.57 (11.3) | IP-LXM45Z-5 Design Flow Rate M3/hr (gpm) Of The Module: | 5.1-7.67 (22.5-33.8) |
|---|---|---|---|
| IP-LXM45Z-5 Shipping Weight Kg (lbs): | 205 (451) | IP-LXM45Z-5 Operating Weight Kg (lbs): | 157 (345) |
| IP-LXM45Z-5 Recovery: | 90–95% | Advantages: | Environmentally Friendly Process |
| Silica (SiO2) Removal: | 90–99%, Depending On Feed Conditions | PH: | 4-11 |
| Application: | Electronics, Food And Beverage Industry | ||
| Highlight: | Food And Beverage Industry CEDI,IP-LXM45Z-5 CEDI,Ionpure CEDI LX-Z IP-LXM45Z-5 |
||
Product Description
Ionpure CEDI LX-Z IP-LXM45Z-5 For Electronics, Food And Beverage Industry
Ionpure LX-Z — 工业 CEDI 模块
Product Overview
The Ionpure® LX-Z IP-LXM45Z is a high-capacity Continuous Electrodeionization (CEDI) membrane stack designed for industrial-scale ultrapure water production. Manufactured by Ionpure (a subsidiary of SUEZ Water Technologies & Solutions), it integrates electrodialysis and ion-exchange technologies to deliver consistent, high-purity water without chemical regeneration. This module is the largest in the LX-Z series, targeting heavy-duty applications in power generation, pharmaceuticals, electronics, and food processing.
Key Features & Advantages
-
Chemical-Free Operation
-
Eliminates acids, alkalis, and neutralizing systems, reducing operational hazards and waste disposal costs.
-
Patented "fully filled" concentrate chamber technology removes the need for brine recirculation pumps or salt addition.
-
-
High-Purity Water Output
-
Produces water with resistivity >16 MΩ·cm (exceeding mixed-bed ion exchange quality) and silica rejection of 90–99%, depending on feed conditions.
-
Stable output quality with no fluctuations, enabled by adaptive DC power control (0–600V, 0–6A).
-
-
Robust Engineering
-
Dual O-ring seals ensure leak-free operation at pressures up to 7 bar (100 psi) and temperatures up to 45°C (113°F).
-
Large-flow spacers and fouling-resistant resin enhance tolerance to feedwater contaminants.
-
-
Operational Efficiency
-
90–95% system recovery rate minimizes wastewater, lowering operational costs by >30% versus traditional ion exchange.
-
Independent power control per module allows uninterrupted operation during maintenance.
-
QUALITY ASSURANCE STANDARDS
CE mark certification, each module is strictly tested before leaving the factory to meet the high standards of the industry and is manufactured under the conditions of complying with ISO 9001 and ISO 14000 quality and environmental management system standards.
About the operating environment of the IONPURE LX-Z module:
The module should be installed indoors, away from direct sunlight, and ensure that the ambient temperature does not exceed 113°F (45°C) to ensure its stable and efficient operation. This can effectively extend the service life of the module while ensuring the stability and reliability of the water quality.
* Actual performance can be accurately estimated using the IP-Pro prediction tool provided by Ionpure.
*Performance data is based on testing at the maximum inlet water conductivity equivalent value (40 μS/cm), ensuring excellent deionization results in various application scenarios.
E-Cell EDI Technology Performance Examples
E-Cell EDI technology has been successfully applied in various industries such as power, petroleum, chemical, steel, pharmaceutical, and electronics.
