SS316L 1600TPD Ultrafiltration Water Treatment System

SS316L 1600TPD Ultrafiltration Water Treatment System

Product Details:

Place of Origin: China
Brand Name: Fenigal/OEM
Certification: CE/NSF etc.
Model Number: UF-400~1600TPD

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Export Wood Crate/Carton or Naked wrapped by film
Delivery Time: 15~30 days
Payment Terms: T/T, Western Union, Paypal etc.
Supply Ability: 50 set per month
Get Best Price Contact Now

Detail Information

Technology: Ultrafiltration Design: Skid Mount
Permeate Flow/TPD: 5~100/skid Recovery Rate: 90~98%
Feed TDS/ppm: <35,000 Water Temp.: 5~35˚C
PH: 2~11 TSS/mg/L: <100
Tubidity: <300 Free Chlorine Mg/L: 0
Dissolved Iron Mg/L: <0.1 Warranty: 1 Year
Skid Material: SS304/SS316L,carbon Steel Voltage: 380V,415V,220V,can Be Customized
Application: Water Purification,Filtration,pharmceutical,drinking Water,food Size: Depends,1750*550*1650mm
Function: Water Purifying, RO Pre-treatment Desalination Rate: 99%,99.7%
Control: Electronic,Manual/PLC UF Membrane: Hydranautics Or DOW / China Make
Pump: CNP / Grundfos,CNP
High Light:

1600TPD Ultrafiltration Water Treatment System


SS316L Ultrafiltration Water Treatment System


1600TPD ultrafiltration equipment

Product Description

SS316L 1600TPD Ultrafiltration Water Treatment System

Industrial ultrafiltration water treeatment outside-in hollow fibre membrane system 400TPD~1,600TPD skid mount


Ultrafiltration (UF) Systems Advantages

Ultrafiltration (UF) membranes systems are more reliable than a conventional multi-media filter, which removed approximately 10 micron or larger of matter, where an ultrafiltration membrane pore size ranges from 0.01 to 0.10 micron. In addition to superior turbidity removal, UF membranes efficiently remove bacteria and most viruses.

  • Superior filtration performance with high flux
  • Very small nominal pore diameter (0.03 µm)
  • Efficiently removes bacteria and viruses
  • Occasionally back washed and air scoured to boost performance and removing the fouling layer to extend operating life
  • Low fouling membrane modules
  • UF Outside-In or Inside-Out Configuration permits reduced plugging and higher solids loading
  • Basic, vertical, modular design permits low cost, compact systems
  • Effective membrane cleaning has a high chemical resistance and temperature tolerance


Industrial Ultrafiltration UF Systems


Model No. Capacity - Surface Water Capacity - Seawater Capacity - Ground Water
Flux at 25 GFD Flux at 35 GFD Flux at 53 GFD Qty of
GPD M3/ Day GPD M3/ Day GPD M3/ Day UF Modules
UF-400-10 105,263 400 158,038 599 258,608 980 10
UF-480-12 126,316 480 190,623 722 311,929 1,182 12
UF-640-16 168,421 640 254,164 963 415,905 1,575 16
UF-800-20 210,526 800 316,076 1,197 517,215 1,959 20
UF-1040-26 273,684 1040 412,202 1,561 674,512 2,555 26
UF-1200-30 315,789 1,200 475,743 1,802 778,489 2,949 30
UF-1600-40 421,053 1,600 633,781 2,401 1,037,096 3,928 40


SS316L 1600TPD Ultrafiltration Water Treatment System 0


What is ultrafiltration in water treatment?


Ultrafiltration systems utilize hollow membrane fibers to eliminate suspended solids, bacteria, viruses, and pathogens from the feed water. Pumps send the treated water through microscopic pores, which act as a physical barrier that only allows filtrates to pass through them. Ultrafiltration strainers are used next to remove solids such as weeds and plastics from the filtered water before it enters the UF system. Ultrafiltration plants have been extremely useful in water and wastewater treatment by continuously providing excellent results. After UF treatment, the water can be sent to a reverse osmosis system for further purification or can be used supplied for immediate public usage.


What is Ultrafiltration (UF) Plant and its importance?


Most regions around the world utilize ultrafiltration plants to maintain sufficient preservation of clean water for public consumption. The water filtration efficiency achieved by UF systems are around 250 times greater than conventional media filtration systems. These plants are also very suitable to many industries that require ultra pure water pushed out from these factories. The ultrafiltration membranes used in these plants are enforced to lower turbidity, or utilize as pretreatment to maintain the effectiveness of your reverse osmosis membrane. These plants are generally considered to be of low cost, easy to operate, carry no contaminate residue, and have considerably high recovery ratio.
