40TPH Ultrafiltration Water Treatment System For Fruit Juice
UF filtration system For Fruit / Vegetable Juice PVDF 2860 DOW 40 TPH
1. Product Description
Ultrafiltration (UF) is one of the most widely used membrane separation technologies. It is mainly used for the separation of macromolecules in solution, separation, concentration, deep purification, clarification, sterilization and macromolecular substances. Has a very excellent effect. In the field of water treatment, can be used to remove colloids in water, particles, bacteria, viruses, heat and macromolecule organic matter, so that water is purified.
1. Dairy, fruit juice, vegetable juice and other clear, concentrated.
2. Animals and plants (aloe vera, mangosteen, tea, etc.) effective ingredients extraction.
3. Soybean protein, oligosaccharides, isoflavones and other extraction, concentration.
4. Antibiotics, amino acids, VC and other fermentation broth purification, concentration.
5. Chinese medicine (Bupleurum, Salvia, Scutellaria, etc.) injection of active ingredients purification, separation.
6. Polysaccharides (Ganoderma lucidum, Grifola frondosa, mushrooms, etc.) material purification, concentration.
7. Fluorescent whitening agent desalination, concentration.
8. Electrophore paint recovery and water reuse.
9. PVA of textile desizing wastewater reuse.
**Textile, chemical industry, process water / chemical recycled water, chemical products manufacturing purification and preparation of water ;
**Food and beverage industrial water, purified drinking water, beverages, beer, liquor, health care products such as water purification and preparation of water;
**Seawater, brackish water desalination islands, ships, offshore drilling platforms, brackish water areas
**Larger community, real estate property, schools, factories, hospitals, and the restaurants, hotels, beauty salons, canteens and other various types of enterprises and institutions.
**Integrated circuits, silicon wafers, display tubes and other electronic components of electronic industrial water rinse water
**Can be used for filling water bottled water, mineral water and other preparation work
2. Product Details
kyro-40tph Ion exchange equipment
|1. Capacity: 40T/H
|2. Rated power: 25.0KW/H
|3. Voltage: 110V/220V/380V, 50Hz/60Hz, single phase/3phase
|4. Desalting rate:>=97%
|5. Water recovery rate: 50-75%
|6. Optional : O3/ UV / water softener
A. Regulating wheels
B. PC Touch Screen
C. Two-stage RO system
D. PH adjustment
E. CIP cleaning system
F. Auto or manual control valve
G. U-PVC or stainless steel pipe
H. UV sterilizer/Ozone Generator
I. Dosing system(anti-scale)/Water Softener
J. PE or stainless steel raw/pure water tank
K. FRP or stainless steel pre-treatment tank
3. Product Processing
Process: raw water tank + raw water pump + quartz sand filter + activated carbon filter + water softener/chemical dosing system(optional) + security filter + high pressure pump + ro system + pure water tank + UV sterilizer(ozone generator) + precision filter + water supply point
Some parts function:
1. Raw water pump: provide needed pressure for every pre-treatment filter;
2. Quartz sand filter: use fiber glass as housing, fill quartz sand, it can filter big particles impurities, suspended substances, colloids etc. Important to remove iron and sediments you mentioned;^^
3. Activated carbon filter: use fiber glass as housing, fill activated carbon, remove color, odor, residual chlorine and organics substances;
4. Security filter: prevent large particles, bacteria, viruses into RO membrane, accuracy is 5µm;
5. High pressure pump: provide needed working pressure for RO system, ensure production capacity of pure water;
6. RO system: can remove particles, colloids, organic impurities, heavy metal ions, bacteria, virus, heat source etc. harmful substances and 99% dissolved salts.
7. Ozone generator(for bottled drinking): can continue to kill bacteria even water fill into bottled,viruses,cell damage,atc...
