10-30 TPH Containerized Ultrafiltration System with Plug-and-Play Design for Rapid Deployment Water Treatment
Product Details:
| Place of Origin: | China |
| Brand Name: | FG Water Technologies |
| Certification: | CE |
| Model Number: | FG-UF-CON |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 unit |
|---|---|
| Price: | Negotiable |
| Packaging Details: | standard export packing |
| Delivery Time: | 15-30 working days |
| Payment Terms: | ,T/T |
|
Detail Information |
|||
| Model: | FG-UF-CON | Nominal Capacity Range: | 10-30 TPH |
|---|---|---|---|
| Container Standard Size: | 20ft Or 40ft Container | Operating Pressure: | 0.1-0.4 MPa |
| System Recovery: | 90-95% | Power Supply: | 380V/3Phase/50Hz Or Generator |
| Highlight: | 10-30 TPH Capacity Containerized Ultrafiltration System,Plug-and-Play Design Ultrafiltration Water Treatment System,Rapid Deployment Solution UF Water Treatment Plant |
||
Product Description
10-30 TPH Containerized Ultrafiltration System
Plug-and-Play Design For Rapid Deployment Solution
Model: FG-UF-CON
10-30 TPH Capacity | Plug-and-Play Design | Rapid Deployment Solution
Product Overview
The FG-UF-CON is a fully integrated, containerized ultrafiltration system designed for rapid deployment in remote, temporary, or emergency water treatment applications. Housed within standard 20ft or 40ft shipping containers, this system provides complete water treatment capabilities with minimal installation requirements.
Engineered for quick setup and operation, the FG-UF-CON arrives pre-assembled, pre-wired, and pre-tested at our factory, ready for immediate operation upon delivery to your site. Simply connect to power and water sources, and begin producing high-quality treated water within hours.
Key Advantage: Rapid Deployment
The FG-UF-CON reduces installation time by up to 80% compared to conventional skid-mounted systems. With its plug-and-play design, you can have clean water flowing within 24-48 hours of delivery, making it ideal for emergency response, remote operations, and temporary water supply needs.
Technical Specifications
Capacity & Performance
| Model Code | FG-UF-CON |
|---|---|
| Capacity Range | 10-30 TPH |
| GPD Equivalent | 52,800-158,400 GPD |
| UF Membrane Type | PVDF Hollow Fiber |
| Nominal Pore Size | 0.02-0.04 μm |
| SDI Output | ≤3 (Typical ≤2.5) |
Container Specifications
| Standard Size | 20ft or 40ft Container |
|---|---|
| Construction | Weatherproof ISO Container |
| Insulation | Thermal & Acoustic |
| Internal Finish | Epoxy Coated Floor & Walls |
| External Finish | Marine-grade Paint |
| Door Configuration | Double Doors + Side Access |
Operational Parameters
| Operating Pressure | 0.1-0.4 MPa |
|---|---|
| Operating Temperature | 5-45°C (Customizable) |
| System Recovery | 90-95% |
| Power Supply | 380V/3Phase/50Hz or Generator |
| Control System | PLC with HMI & Remote Monitoring |
| Deployment Time | 24-48 hours |
Application Scenarios
The FG-UF-CON is engineered for diverse applications requiring rapid deployment, mobility, and reliable water treatment in challenging environments:
Emergency Water Supply
Rapid deployment for disaster relief, refugee camps, and emergency situations where municipal water infrastructure is compromised or unavailable.
Typical Use Cases:
- Natural disaster response (floods, earthquakes)
- Refugee camp water supply
- Military field operations
- Temporary settlement water treatment
Remote Mining Operations
Provides potable and process water for mining camps and remote extraction sites where water infrastructure is non-existent or limited.
Typical Use Cases:
- Mining camp drinking water
- Mineral processing water
- Dust suppression water treatment
- Exploration site water supply
Construction & Infrastructure Projects
Temporary water treatment for large construction sites, infrastructure projects, and remote development areas during construction phases.
Typical Use Cases:
- Highway/railway construction camps
- Remote infrastructure projects
- Oil & gas pipeline construction
- Tunnel/bridge construction sites
Disaster Recovery & Temporary Replacement
Interim water treatment solutions during plant maintenance, system upgrades, or when existing water infrastructure is damaged or offline.
Typical Use Cases:
- Water plant maintenance bypass
- Infrastructure failure replacement
- Seasonal demand supplement
- Emergency backup systems
Why Choose FG-UF-CON?
Our containerized ultrafiltration systems deliver unmatched mobility, rapid deployment, and reliable performance in the most challenging environments:
Rapid Deployment
Operational within 24-48 hours of delivery. Pre-assembled and factory-tested for immediate use upon arrival at your site.
Complete Mobility
Standard shipping container design allows for easy transport by truck, rail, or ship to any location worldwide.
All-Weather Protection
Weatherproof container provides protection from environmental elements, vandalism, and unauthorized access.
Plug-and-Play Operation
Minimal installation required - just connect to power and water sources. All internal connections are pre-completed.
Flexible Configuration
Customizable for various feed water sources and output requirements. Options include generator power, solar panels, and remote monitoring.
Cost-Effective Solution
Eliminates need for permanent infrastructure. Lower total cost compared to building temporary water treatment facilities.
Container Configuration Options
Choose the configuration that best fits your project requirements and site conditions:
20ft Standard Container
Compact solution for 10-15 TPH capacity. Ideal for space-constrained sites and smaller operations.
40ft Standard Container
Higher capacity 20-30 TPH system with additional space for auxiliary equipment and storage.
40ft High-Cube Container
Additional vertical space for easier maintenance access and more complex system layouts.
Custom Configuration
Tailored solutions with specific features like climate control, security systems, or expanded capacity.
Need Rapid Water Treatment Deployment?
Our containerized UF systems can be on-site and operational within days. Contact us to discuss your project requirements and receive a customized solution with delivery timeline.
