Chemical Resistant Cleaning Ultrafiltration UF Membrane Module UF3OA225L For Desalination
Product Details:
| Place of Origin: | China |
| Brand Name: | Zhaojin Motian |
| Certification: | CE |
| Model Number: | UF₃OA225L |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiable |
| Packaging Details: | standard export packing |
| Delivery Time: | 5- 8 work days |
| Supply Ability: | 60000 Units per Month |
|
Detail Information |
|||
| Model Of This Element: | UF₃OA225L | Material: | PVDF(Polyvinylidene Fluoride) |
|---|---|---|---|
| Membrane Surface Area Of Element: | 75m²(807.3ft²) | Pore Size Of This Element: | 0.03µm |
| Module Maximum Water Inlet Pressure Of This Element: | 0.2MPa | Module Molecular Weight Cutoff: | 100,000Dal |
| Module Fiber Inner/outer Diameter: | 0.7/1.2mm | Module Maximum Transmembrane Pressure Difference: | 0.15MPa |
| Module Operating Temperature Range: | 5-45°C | Product Feature: | Dead-end Filtration |
| Maximum Transmembrane Differential Pressur: | 0.15Mpa | Application Of This Element: | Desalination |
| Highlight: | Desalination UF Membrane Module,Chemical Resistant Cleaning UF Membrane Module,UF3OA225L UF Membrane Module |
||
Product Description
Chemical Resistant Cleaning Ultrafiltration (UF) Membrane Module UF₃OA225L For Desalination
Pressurized Outside to In / Dead-end Filtration Ultrafiltration (UF) Membrane Module
1. The quality of the produced water is greatly improved, and most of the suspended matter, colloids, microorganisms, organic pollutants, etc. contained in the water can be filtered out. The pollution index of the ultrafiltration membrane component is SDI15<2.
2. The water quality of the ultrafiltration membrane component is relatively stable and will not change with the operation time and the water quality of the system inlet.
3. The ultrafiltration membrane component is less polluted and has a long service life.
4. The operation intensity of the ultrafiltration membrane system is reduced, and full automatic control can be achieved, reducing the investment of labor costs.
5. The ultrafiltration membrane system has a compact structure design and saves floor space.
· Simple preprocessing
Excellent runner design broadens the influent water conditions.
· Long cleaning cycle
Strong pollution resistance, long decay period, good drug resistance, easy to clean and restore.
· Long service life
Membrane filament strength is high, continuous filament, permanent hydrophilic, slow flux decay.
· Safe and reliable water production
Mean aperture structure, large water production flux, wide range of adaptation to raw water quality.
· Low operating cost
Super hydrophilic modification, fast infiltration, less agent demand, thorough cleaning.
| Material Specifications | |
| Description | Material |
| Casing | uPVC |
| Cap | uPVC |
| Potting | Epoxy resin |
| O-ring | EPDM |
