Pressurized Outside to In Ultrafiltration UF Membrane Module UF3OA200
Product Details:
| Place of Origin: | China |
| Brand Name: | Zhaojin Motian |
| Certification: | CE |
| Model Number: | UF₃OA200 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiable |
| Packaging Details: | standard export packing |
| Delivery Time: | 5- 8 work days |
| Supply Ability: | 60000 Units per Month |
|
Detail Information |
|||
| Product Model: | UF₃OA200 | Product Material: | PVDF(Polyvinylidene Fluoride) |
|---|---|---|---|
| Product Surface Area: | 60m²(646ft²) | Product Nominal Pore Size: | 0.03µm |
| Product Maximum Water Inlet Pressure: | 0.2MPa | Product Molecular Weight Cutoff: | 100,000Dal |
| Product Module Fiber Inner/outer Diameter: | 0.8 /1.3mm | Product Maximum Transmembrane Pressure Difference: | 0.15MPa |
| Product Operating Temperature Range: | 5-45°C | Feature Of Product: | Pressurized Outside To In |
| Highlight: | Pressurized Ultrafiltration Membrane Module,Outside to In Ultrafiltration Membrane Module,UF3OA200 Ultrafiltration Membrane Module |
||
Product Description
Pressurized Outside to In Ultrafiltration (UF) Membrane Module UF₃OA200
Pressurized Outside to In / Dead-end Filtration Ultrafiltration (UF) Membrane Module
Pressurized outside-in/dead-end filtration ultrafiltration (UF) membrane modules are a highly efficient membrane separation technology that pushes water or solutions from the outside of the membrane to the inside by applying pressure, thereby achieving effective filtration and separation of tiny particles such as suspended solids, colloidal particles, bacteria and viruses. This membrane technology is widely used in water treatment, food processing, biopharmaceuticals and other fields, and can effectively remove suspended solids and microorganisms, improve water quality and product purity. The design and material selection of UF membrane modules play a vital role in their filtration performance and service life, so reasonable design and operation are required according to specific application requirements when selecting and using them.
· Simple preprocessing
Excellent runner design broadens the influent water conditions.
· Long cleaning cycle
Strong pollution resistance, long decay period, good drug resistance, easy to clean and restore.
· Long service life
Membrane filament strength is high, continuous filament, permanent hydrophilic, slow flux decay.
· Safe and reliable water production
Mean aperture structure, large water production flux, wide range of adaptation to raw water quality.
· Low operating cost
Super hydrophilic modification, fast infiltration, less agent demand, thorough cleaning.
|
| Material Specifications | |
| Description | Material |
| Casing | uPVC |
| Cap | uPVC |
| Potting | Epoxy resin |
| O-ring | EPDM |
