Long Service Life Flat Sheet MBR Membranes Process To Wastewater Reuse
Product Details:
| Place of Origin: | China |
| Brand Name: | Fenigal |
| Certification: | CE |
| Model Number: | HF-100-120 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiable |
| Packaging Details: | standard export packing |
| Delivery Time: | 5- 8 work days |
| Supply Ability: | 60000 Units per Month |
|
Detail Information |
|||
| MBR Membrane Area: | 120m2 | The Size Of Pore: | 0.1-0.4um |
|---|---|---|---|
| Product Throughput: | 48-72 M3/d | Product Series: | HF-100 Flat Membrane Series |
| Type Of Membrane: | Flat Sheet Membrane | Related Applicable Industry: | Hotels, Manufacturing Plant, Restaurant, Home Use, Construction Works , Food & Beverage Shops, Advertising Company |
| The Range Of PH: | 1-13 | Advantages: | Easy To Clean |
| Highlight: | bioreactor for waste water treatment,biological reactor wastewater treatment,biological reactor in wastewater treatment |
||
Product Description
Long Service Life Flat Sheet Membrane MBR Membranes Process To Wastewater Reuse HF-100-120
Advantages of flat sheet membrane:
1. Efficient removal of pollutants: MBR flat membrane can intercept almost all suspended solids and microorganisms, greatly improving the removal efficiency of pollutants, including COD, BOD, ammonia nitrogen, total phosphorus, etc., and the effluent quality can reach or exceed the national Class A emission standard.
2. Small footprint: Compared with the traditional activated sludge method, the MBR flat membrane system is compact and occupies less space, which is particularly suitable for urban areas with tight land resources.
3. Stable effluent quality: The stability and continuous operation performance of the MBR flat membrane ensure the consistency and reliability of the effluent quality, and can maintain the stability of the effluent quality even in the face of fluctuations in sewage composition.
4. Reduce sludge production: The high sludge age and low sludge yield in the MBR flat membrane system reduce the generation of excess sludge and reduce the cost of sludge treatment and disposal.
5. Flexible operation: The MBR flat membrane system can adjust the operating parameters according to actual needs, adapt to changes in different flow rates and pollutant concentrations, and achieve flexible operation.
Base plate material: ABS
Membrane pore size: 0.1-0.4um
Standard flux:10-30L/m2.h
Suggested flux: 15-25L/m2.h for normal daily sewage
pH range: 1-13
Aeration: 8-10L/m2.h
For different water qualities, there will be significant differences in their water production. Users should conduct sufficient experiments. This parameter is the initial filtration flux of a membrane element when using MBR membrane to treat municipal wastewater under suction vacuum conditions of 25 ℃ and -10KPa. The unit is L/㎡. d, which is not a guaranteed value.
Membrane module size specifications
HF-100 flat membrane series
| model |
membrane area (m2) |
Throughput (m3/d) |
A (mm) |
B (mm) |
C[1] (mm) |
D (mm) |
E (mm) |
F (mm) |
G (mm) |
| HF-100-50 | 50 | 20-30 | 912 | 700 | 1758 | 153 | 1688 | 535 | 713 |
| HF-100-80 | 80 | 32-48 | 1370 | 1170 | |||||
| HF-100-100 | 100 | 40-60 | 1674 | 1476 | |||||
| HF-100-120 | 120 | 48-72 | 1980 | 1780 |
HF-50 flat membrane series
| model |
membrane area (m2) |
Throughput (m3/d) |
A (mm) |
B (mm) |
C[1] (mm) |
D (mm) |
E (mm) |
F (mm) |
G (mm) |
| HF-50-50 | 25 | 10-15 | 720 | 630 | 1040 | 153 | 970 | 600 | 585 |
| HF-50-80 | 40 | 16-24 | 1150 | 935 | |||||
| HF-50-100 | 50 | 20-30 | 1450 | 1170 |
Schematic diagram of HF-MBR membrane module installation pipeline
| serial number | project | illustrate |
| 1 | use | Used for the separation of activated sludge and other suspended impurities in raw water from water |
| 2 | Operation mode | Produced water from suction operation or water production from gravity flow operation |
| 3 | Aeration volume | 8-10L/㎡.min |
| 4 | Operating transmembrane pressure differential | ＜15KPa _ |
| 5 | Operating water temperature | 5-45 ℃ |
| 6 | Run PHvalue | 1-13 |
| 7 | Cleaning fluid injection pressure | <20 KPa |
|
8 |
Cleaning fluid preparation concentration |
When the membrane is organically contaminated, soak it in 0.5 % concentration NaClO solution for 4 to 6 hours. The cleaning solution preparation quantity is: 3 L / element; when the membrane is contaminated by oil or inorganic scaling, please refer to "Chemical cleaning of Membrane Modules" for details on the treatment method in section 8. |
