Microprocessor Based Control Panel Processor Commercial Ro Water Filter System 9000GPD
Product Details:
| Place of Origin: | China |
| Brand Name: | Fenigal/OEM |
| Certification: | CE/NSF etc. |
| Model Number: | SRO-R/N-1500~9000GPD |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard Export Wood Crate/Carton or Naked wrapped by film |
| Delivery Time: | 15~30 days |
| Payment Terms: | T/T, Western Union, Paypal etc. |
| Supply Ability: | 50 set per month |
|
Detail Information |
|||
| Technology: | Commercial Water Reverse Osmosis | Design: | Skid Mount |
|---|---|---|---|
| Permeate Flow/TPD: | 5~75 | Recovery Rate: | 65~75% |
| Feed TDS/ppm: | <2,000 | Water Temp.: | 5~35˚C |
| PH: | 4~9 | TSS/mg/L: | <5 |
| Silt Density Index: | <3 | Free Chlorine Mg/L: | 0 |
| Dissolved Iron Mg/L: | <0.1 | Warranty: | 1 Year |
| Material: | SS304/SS316L,carbon Steel | Capacity: | 0.5-100m3/h |
| Voltage: | 380V,415V,220V,can Be Customized | Application: | Water Purification,Filtration,pharmceutical,drinking Water,food |
| Size: | Depends,1750*550*1650mm | Type: | Reverse Osmosis System |
| Function: | Water Purifying, Desalination | Desalination Rate: | 99%,99.7% |
| Control: | Electronic,Manual/PLC | Ro Membrane: | Vontron, Hydranautics Or DOW,4040 |
| Pump: | CNP / Grundfos,CNP | ||
| High Light: | microprocessor commercial ro water filter system,oem commercial ro water filter system,9000GPD commercial ro water filter system |
||
Product Description
Microprocessor Based Control Panel Processor Commercial Ro Water Filter System 9000GPD
Microprocessor based control panel Commercial Water Treatment System Processor
Max. feed water temperature: 42°C
Equipment upgrade for TDS up to 5,000 ppm
Hydrogen Sulfide must be removed
Max. Silica tolerance: 25 ppm @ 60% recovery
Feed water TDS: 0-2,000 ppm
Operating pressure: 150 to 250 psi
pH tolerance range: 3-11
Max. Iron content: 0.05 ppm
| Small size RO system with 4" membranes | |||||
| SRO-N series | Capacity | Power rate (50HZ) | RO membrane | width*depth*height | |
| feed water TDS<1500ppm | (1-6 pcs) | mm | |||
| SRO-N-1500 | 1500gpd | 0.25m3/h | 1.5kw | 4040 | 700*650*1650 |
| SRO-N-3000 | 3000gpd | 0.50m3/h | 1.5kw | 4040 | 700*650*1650 |
| SRO-N-4500 | 4500gpd | 0.75m3/h | 1.5kw | 4040 | 700*650*1650 |
| SRO-N-6000 | 6000gpd | 1.00m3/h | 1.5kw | 4040 | 700*650*1650 |
| SRO-N-9000 | 9000gpd | 1.50m3/h | 2.2kw | 4040 | 700*650*1650 |
|
RO water filter system 0.25tph SRO-R series 9000gpd |
|||||
| SRO-R series | Capacity | Power rate (50HZ) | RO membrane | width*depth*height | |
| feed water TDS<1500ppm | (1-6 pcs) | mm | |||
| SRO-R-6000 | 6000gpd | 1.00m3/h | 1.5kw | 4040 | 700*1650*1350 |
| SRO-R-9000 | 9000gpd | 1.50m3/h | 2.2kw | 4040 | 700*1650*1350 |
| SRO-R-12000 | 12000gpd | 2.00m3/h | 3.0kw | 4040 | 850*2350*1350 |
| SRO-R-15000 | 15000gpd | 2.50m3/h | 3.0kw | 4040 | 850*2350*1350 |
| SRO-R-18000 | 18000gpd | 3.00m3/h | 3.0kw | 4040 | 850*2350*1350 |
Reverse osmosis systems are designed and manufactured for commercial and industrial applications. These systems have been engineered for capacities ranging from 1,200-20,000gpd for low TDS feed water design (Feed water TDS<1,500ppm).
RO water filter system 0.25tph SRO-N series 9000gpd
Application
- Municipal,
- Wastewater,
- Hotel,
- Military,
- Hospital,
- Food and beverage,
- Pharmaceutical, Mining,
- Power and energy,
- Refinery,
- Restaurants,
- Schools,
- Agriculture,
- Boiler feed,
- Disaster relief
Specification
- Membrane element and pressure vessel
- Membrane model---LP21-4040
- Membrane manufacturer---Vontron/DOW/Hydronautics/Others
- Membrane rejection---99%-99.6%
- Pressure vessel spec.---FRP, 300PSI, end port
- Pressure vessel manufacturer---ROPV/Wave Cyber/First Line/Others
- Cartridge Filtration
- Housing---4.5’’*20’’
- Filter cartridge---4.5’’*20’’, 5micron
- Quantity--- 1 pc
- Boost Pump
- Type---Vertical multistage centrifugal
- Pump material---SS304/SS316/Carbon steel
- Connection---DIN flange
- Brand---CNP
- Benefits
- Fully equipped and customizable
- Components easily accessible
- Low operation and maintenance costs
- 1-Year limited warranty
