Compact Modular 25TPD Reverse Osmosis Water Treatment System with Space Saving Skid and Quick Install
Product Details:
| Place of Origin: | China |
| Brand Name: | Fenigal/OEM |
| Certification: | CE/NSF/ISO 9001 |
| Model Number: | FRO-Compact-25TPD |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard Export Wood Crate with Protective Film Wrapping |
| Delivery Time: | 15~25 days |
| Payment Terms: | T/T,L/C,Western Union |
| Supply Ability: | 50 set per month |
|
Detail Information |
|||
| Highlight: | Compact Modular RO System,Space Saving RO Water Plant,Quick Install RO Treatment |
||
|---|---|---|---|
Product Description
Compact Modular Reverse Osmosis Water Treatment System 25TPD
The FRO-Compact Series redefines space efficiency in industrial water treatment, delivering a complete 25TPD reverse osmosis system within an exceptionally small footprint of just 1,650 × 850 mm. Purpose-engineered for installations where floor space is at a premium, this modular skid-mounted unit arrives fully pre-plumbed, pre-wired, and factory-tested, enabling same-day installation with only three external connections required: feed water inlet, permeate outlet, and concentrate drain. Despite its compact dimensions, the system incorporates a complete treatment train including multimedia pre-filtration, activated carbon dechlorination, anti-scalant dosing, 5-micron cartridge filtration, and eight 4040 RO membrane elements, making it the ideal choice for commercial buildings, hotels, resorts, restaurants, and small manufacturing facilities that demand reliable water purification without sacrificing valuable operational space.
Key Features
- Ultra-Compact Footprint: With dimensions of just 1,650 × 850 × 1,750 mm (L×W×H), the FRO-Compact occupies approximately 60% less floor area than comparable 25TPD systems, fitting comfortably through standard 900 mm doorways and into utility rooms, basements, or mezzanine levels where conventional skid systems cannot be installed.
- True Plug-and-Play Design: Every component is pre-assembled and tested at our factory, including internal wiring terminated to a single power connection point, pre-connected chemical dosing lines, and labeled quick-connect fittings for external piping. Typical on-site installation time from delivery to operational startup is under 4 hours with basic plumbing and electrical support.
- Eight High-Efficiency 4040 Membranes: Configured in a 2:1:1 array with premium low-pressure RO elements from Vontron or DOW Filmtec, the membrane train delivers consistent 99% salt rejection at recovery rates up to 75%, producing high-quality permeate suitable for boiler feed, humidification systems, and potable water applications.
- Integrated Pre-Treatment Module: The single-skid design incorporates a multimedia filter with automatic time-based backwash valve, activated carbon filter for chlorine and organic removal, and a 5-micron polypropylene cartridge filter, eliminating the need for separate pre-treatment vessels and saving additional floor space and interconnection piping.
- Intuitive Microprocessor Controller: A compact yet powerful control panel with backlit LCD display provides clear status indication for all system parameters including permeate conductivity, operating pressure, flow rates, pump status, and maintenance reminders, with one-button startup and automatic shutdown on fault detection for unattended operation.
- Low-Noise Operation: The carefully selected CNP vertical multi-stage pump with TEFC motor operates at under 62 dBA, making the system suitable for installation in noise-sensitive environments such as hotel equipment rooms, office building utility areas, and food service preparation zones without requiring additional acoustic enclosure.
- Tool-Free Membrane Access: The innovative top-mounted membrane housing arrangement with quick-release clamps allows individual membrane element inspection or replacement in under 15 minutes without disconnecting piping or removing adjacent housings, minimizing maintenance downtime and labor costs.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | FRO-Compact-25TPD |
| Permeate Flow Rate | 25,000 L/D (1,042 L/h, 6,600 GPD) |
| Recovery Rate | 65~75% |
| Feed Water TDS | ≤ 2,000 ppm |
| Nominal Salt Rejection | ≥ 99.0% |
| Membrane Configuration | 2:1:1 Array, 8 × 4040 Elements, FRP Housings (300 psi) |
| Operating Pressure | 8~14 bar |
| Power Consumption | 4.0 kW (380V/50Hz) |
| Feed Water Temperature Range | 5~40°C |
| pH Operating Range | 3~11 (Continuous) |
| Footprint (L×W×H) | 1,650 × 850 × 1,750 mm |
| Net Weight | Approx. 420 kg |
| Noise Level at 1m | < 62 dBA |
| Power Supply | 220V 1PH / 380V 3PH, 50/60Hz |
| Pre-Treatment Included | Multimedia + Activated Carbon + 5µm Cartridge Filter |
Applications
The FRO-Compact Series is purpose-designed for commercial and light industrial applications where space, budget, and installation simplicity are primary considerations. Ideal deployments include hotel and resort potable water systems serving guest rooms and kitchen operations, restaurant chain central water treatment for multiple outlet consistency, office building humidification and cooling tower makeup water, small-scale bottled water production lines with daily output under 6,000 gallons, pharmaceutical intermediate process water preparation, school and university campus drinking water stations, and healthcare facility sterile processing department water supply. The modular nature of the design also supports easy capacity expansion by adding parallel units as demand grows, providing a scalable solution that grows with the business without requiring complete system replacement. For international projects, the compact crate dimensions optimize container loading, reducing shipping costs compared to conventional skid systems.
Packaging & Quality Assurance
Each FRO-Compact system undergoes a rigorous 24-hour continuous wet test at the factory, with all operational parameters recorded and verified against the specified performance criteria. The compact design allows the complete system to be shipped in a single fumigated plywood crate with integrated forklift channels for easy handling. Internal components are secured with transport brackets, and all chemical tanks are emptied and purged before packing. A comprehensive documentation package including installation guide, wiring diagram, P&ID drawing, spare parts catalog, and commissioning checklist is provided in both printed and USB formats. The standard 1-year warranty covers all components, with extended warranty and annual maintenance contract options available for customers seeking long-term operational peace of mind. Express shipping options enable delivery to most international destinations within 15-25 days from order confirmation.
