Oem Commercial Advanced Reverse Osmosis Water Treatment System 1-2m Mega Million Gpd

Oem Commercial Advanced Reverse Osmosis Water Treatment System 1-2m Mega Million Gpd

Product Details:

Place of Origin: China
Brand Name: Fenigal/OEM
Certification: CE/NSF etc.
Model Number: SRO-R/N-1M~2M mega-million GPD

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Export Wood Crate/Carton or Naked wrapped by film
Delivery Time: 15~30 days
Payment Terms: T/T, Western Union, Paypal etc.
Supply Ability: 50 set per month
Get Best Price Contact Now

Detail Information

Technology: Commercial Water Reverse Osmosis Design: Skid Mount
Feed TDS/ppm: <2,000 Permeate Flow/TPD: 5~75
Recovery Rate: 65~75% Water Temp.: 5~35˚C
PH: 4~9 TSS/mg/L: <5
Silt Density Index: <3 Free Chlorine Mg/L: 0
Warranty: 1 Year Application: Water Purification,Filtration,pharmceutical,drinking Water,food
Material: SS304/SS316L,carbon Steel Dissolved Iron Mg/L: <0.1
Capacity: 0.5-100m3/h Size: Depends,1750*550*1650mm
Pump: CNP / Grundfos,CNP Function: Water Purifying, Desalination
Desalination Rate: 99%,99.7% Control: Electronic,Manual/PLC
High Light:

commercial advanced reverse osmosis water treatment system

,

OEM advanced reverse osmosis water treatment system

,

commercial reverse osmosis water system oem

Product Description

Oem Commercial Advanced Reverse Osmosis Water Treatment System 1-2m Mega Million Gpd

Skid mount SRO-R/N reverse osmosis water treatment system 1,500GPD~9,000GPD



Reverse osmosis systems are designed and manufactured for commercial and industrial applications. These systems have been engineered for capacities ranging from 1,200-20,000gpd for low TDS feed water design (Feed water TDS<1,500ppm).



RO water filter system 0.25tph SRO-N series 9000gpd



Small size RO system with 4" membranes
SRO-N series Capacity Power rate (50HZ) RO membrane width*depth*height
feed water TDS<1500ppm (1-6 pcs) mm
SRO-N-1500 1500gpd 0.25m3/h 1.5kw 4040 700*650*1650
SRO-N-3000 3000gpd 0.50m3/h 1.5kw 4040 700*650*1650
SRO-N-4500 4500gpd 0.75m3/h 1.5kw 4040 700*650*1650
SRO-N-6000 6000gpd 1.00m3/h 1.5kw 4040 700*650*1650
SRO-N-9000 9000gpd 1.50m3/h 2.2kw 4040 700*650*1650



RO water filter system 0.25tph SRO-R series 9000gpd

SRO-R series Capacity Power rate (50HZ) RO membrane width*depth*height
feed water TDS<1500ppm (1-6 pcs) mm
SRO-R-6000 6000gpd 1.00m3/h 1.5kw 4040 700*1650*1350
SRO-R-9000 9000gpd 1.50m3/h 2.2kw 4040 700*1650*1350
SRO-R-12000 12000gpd 2.00m3/h 3.0kw 4040 850*2350*1350
SRO-R-15000 15000gpd 2.50m3/h 3.0kw 4040 850*2350*1350
SRO-R-18000 18000gpd 3.00m3/h 3.0kw 4040 850*2350*1350





Designed to produce low dissolved solids water from non-polluted surface or well water, these systems use high efficiency reverse osmosis membranes. The product water is used in applications such as semiconductor, boiler feed, pharmaceutical, municipal, water reuse, food processing, bottling, and a wide variety of other applications.






Specification
  • Membrane element and pressure vessel
    • Membrane model---LP21-4040
    • Membrane manufacturer---Vontron/DOW/Hydronautics/Others
    • Membrane rejection---99%-99.6%
    • Pressure vessel spec.---FRP, 300PSI, end port
    • Pressure vessel manufacturer---ROPV/Wave Cyber/First Line/Others
  • Cartridge Filtration
    • Housing---4.5’’*20’’
    • Filter cartridge---4.5’’*20’’, 5micron
    • Quantity--- 1 pc
  • Benefits
  • Fully equipped and customizable
  • Components easily accessible
  • Low operation and maintenance costs
  • 1-Year limited warranty



Application
  • Municipal,
  • Wastewater,
  • Hotel,
  • Military,
  • Hospital,
  • Food and beverage,
  • Pharmaceutical, Mining,
  • Power and energy,
  • Refinery,
  • Restaurants,
  • Schools,
  • Agriculture,
  • Boiler feed,
  • Disaster relief
