380GPD Sea Water Reverse Osmosis Desalination System Skid Mount
Product Details:
Place of Origin: | China |
Brand Name: | Fenigal/OEM |
Certification: | CE/UL/NSF etc. |
Model Number: | SWRO4-380GPD~10,000GPD |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 Set |
---|---|
Price: | Negotiable |
Packaging Details: | Standard Export Wood Crate/Carton or Naked wrapped by film |
Delivery Time: | 15~30 days |
Payment Terms: | T/T, Western Union, Paypal etc. |
Supply Ability: | 50 set per month |
Detail Information |
|||
Technology: | Reverse Osmosis | Design: | Skid Mount |
---|---|---|---|
Permeate Flow/TPD: | 1.4~38 | Permeate Flow/GPD: | 380~10,000GPD |
Recovery Rate: | 8~35% | Feed TDS/ppm: | <35,000 |
Water Temp.: | 5~35˚C | PH: | 4~9 |
TSS/mg/L: | <5 | Silt Density Index: | <3 |
Free Chlorine Mg/L: | 0 | Dissolved Iron Mg/L: | <0.1 |
Warranty: | 1 Year | Material: | SS304/SS316L,carbon Steel |
Capacity: | 0.5-100m3/h | Voltage: | 380V,415V,220V,can Be Customized |
Application: | Water Purification,Filtration,pharmceutical,drinking Water,food | Size: | Depends,1750*550*1650mm |
Type: | Seawater Reverse Osmosis System | Function: | Water Purifying, Desalination |
Desalination Rate: | 99%,99.7% | Control: | Electronic,Manual/PLC |
Ro Membrane: | Hydranautics Or DOW,4040 | Pump: | Danfoss/CAT/CNP |
High Light: | 380GPD Reverse Osmosis Desalination System,Skid Mount Seawater Reverse Osmosis System |
Product Description
380GPD Sea Water Reverse Osmosis Desalination System Skid Mount
380GPD Sea Water Reverse Osmosis Desalination System
Sea water reverse osmosis system SWRO4 skid mount DOW filmtec 380 GPD to 10,000 GPD
Seawater desalination utilizes permeable membranes, which are only tasked to remove dissolved solids while dividing the feed water into purified water and the rejected concentrated salts. The salts and other organics are thrown into the brine stream then flushed into a drain. At the end we have purified water that has 99% less dissolved salts. These seawater reverse osmosis systems are immensely powerful, with the capacity of purifying significantly high TDS water.
Seawater RO systems are usable anywhere from yachts to municipalities. It’s important to choose the correct materials of construction to handle seawater (which is highly corrosive). We use materials such as SS316L, Duplex SS 2205, SS 2207, and SS 904 to guarantee a longer operating life and less maintenance.
Commercial SWRO-C is equipped with premium components which include duplex SS centrifugal-type high pressure pump for high performance and corrosion resistance, a programmable computer controller with many built-in features, 1000 psi fiberglass membrane housings for durability and US made seawater membranes for high quality product water.
Our SWRO4 Series is available with capacities ranging from 380 GPD to 10,000 GPD and a maximum feed water TDS of 45,000 ppm. We offer standard units as well as customizable to fit you water application needs.
In choosing the correct SWRO model, the following information must be provided:
- Flow rate (GPD, m3/day, etc.)
- Feed water TDS or sea source (ex: Pacific, Mediterranean, etc.)
- Seawater Source (open intake or beach well)
- Iron, manganese, and hydrogen sulfide must be removed before the water enters the reverse osmosis unit
- TSS must be removed before commercial SWC system
- Turbidity should be removed
- SDI must be less than 3
- Water should be free from oil and grease
- Chlorine must be removed
- Available voltage, phase, and frequency
- Dimensions of proposed area where commercial SWC System will be installed
Operation Specifications
Feed water TDS: 10,000-42,000 ppm Operating pressure: 700 to 1,000 psi pH tolerance range: 3-11 |
Max. feed water temperature: 42°C Feed TDS up to 50,000 ppm H2S, turbidity and organics must be removed |
Feed water pressure: 40 to 80 psi Antiscalant dosing is required Max. Iron content: 0.05 ppm |
Technical Specification
Model No. | Permeate | Membranes | Motor HP | Approx Weight. | Dimensions | |||||
at 1000 ppm | ||||||||||
GPD | M3/Day | Size | Qty | 60 HZ | 50 HZ | LBS. | KG | L”xW”xH” | LxWXH (cm) | |
SWRO4-125 | 380 | 1.4 | 2.5" x 40" | 1 | 2 | 2 | 220 | 100 | 51X21X30 | 130X53X76 |
SWRO4-225 | 700 | 2.7 | 2.5" x 40" | 2 | 2 | 3 | 230 | 105 | 51X21X30 | 130X53X76 |
SWRO4-325 | 1,000 | 3.8 | 2.5" x 40" | 3 | 3 | 3 | 250 | 114 | 51X21X30 | 130X53X76 |
SWRO4-425 | 1,300 | 5 | 2.5" x 40" | 4 | 3 | 3 | 290 | 132 | 51X21X30 | 130X53X76 |
SWRO4-104 | 1,100 | 4 | 4" x 40" | 1 | 5 | 5 | 395 | 180 | 61X34X50 | 155X86X127 |
SWRO4-204 | 2,100 | 8 | 4" x 40" | 2 | 7.5 | 7.5 | 500 | 227 | 61X34X50 | 155X86X127 |
SWRO4-304 | 3,000 | 11 | 4" x 40" | 3 | 7.5 | 7.5 | 360 | 164 | 61X34X50 | 155X86X127 |
SWRO4-404 | 3,800 | 14 | 4" x 40" | 4 | 7.5 | 7.5 | 500 | 227 | 61X34X50 | 155X86X127 |
SWRO4-504 | 4,700 | 18 | 4" x 40" | 5 | 10 | 10 | 750 | 341 | 61X34X50 | 155X86X127 |
SWRO4-604 | 5,600 | 21 | 4" x 40" | 6 | 10 | 10 | 850 | 386 | 61X34X50 | 155X86X127 |
SWRO4-704 | 6,000 | 23 | 4" x 40" | 7 | 10 | 10 | 970 | 441 | 61X34X50 | 155X86X127 |
SWRO4-804 | 7,600 | 29 | 4" x 40" | 8 | 15 | 15 | 1,050 | 477 | 61X34X50 | 155X86X127 |
SWRO4-1004 | 10,000 | 37.9 | 4" x 40" | 10 | 15 | 15 | 1,150 | 523 | 61X34X50 | 155X86X127 |
Standard Features: | Available Options: | |||||
Low & high pressure switches Permeate TDS monitor Stainless steel high pressure piping Stainless steel throttling valve for reject stream Powder coated steel frame Heavy duty 5 micron cartridge prefilter Seawater resistant SS pump Microprocessor/PLC based control panel & VFD Glycerin-filled 316 SS prefilter pressure gauges Product & reject flow meters TFC spiral wound membranes FRP membrane housings 380-415V/3Ph/50Hz power supply Automatic feed shut off valve |
Chemical dosing systems Media and Iron prefiltration systems Ozonation and UV sterilization systems Post deionization polishers Remote monitor / control option Product tank level controller switch Feed pH controller with sensor Feed ORP controller with sensor Water and hour meters Feed water conductivity monitor Membrane cleaning skid Automatic hourly flush Feed/Permeate blending Explosion proof RO Export crating Containerized / mobile seawater RO 460V/3Ph/60Hz power supply |
Ideal applications for a Reverse Osmosis Water Maker include: | ||||||
Cargo Ships Coastal Developments Hotels & Resorts Seaside Work Sites |
Seaside Villas Work Boats Fish Processing Plants Boat, Yacht and Sailboat |
Oil Tankers Island-Based Businesses Villages & Cities |
More information about SWRO
What is seawater reverse osmosis?
Seawater reverse osmosis systems are designed to decline more than 99% of saline compromised within the feed water. These systems also incorporate a rinsing, chemical purifying apparatus to eliminate sodium chloride, avert scaling, and preserve system performance. There are two fundamental elements within every seawater reverse osmosis system, which are reverse osmosis membranes and high pressure feed pumps. These elements make up the center of any reverse osmosis system and need special consideration and application for successful operation.
Does reverse osmosis remove salt from seawater?
Yes, semipermeable membranes enable the feed water to pass through it at a much higher volume than dissolved salts. Reverse osmosis systems work by applying pressure as freshwater streams through its membranes to filter out the concentrated saline in the feed water, as well as minerals and pollutants. These unwanted impurities are either flushed away, recycled, or processed. Seawater reverse osmosis systems utilize more than one membrane to boost the load of purified water turned out each day.
What are the advantages of desalination plants?
Seawater desalination has become a vital alternative to the production of pure freshwater throughout the areas of the world without drinkable water. As other sources such as rivers, lakes, wells, and springs have become more exhausted due to excessive extraction, the ocean has provided an abundant supply of available water for human use. Although ocean water consists of elevated levels of salt, and therefore is unable to be utilized for consumption or most other purposes, seawater desalination has helped make it practical.
