Water Purifying 60000GPD Seawater Reverse Osmosis System

Water Purifying 60000GPD Seawater Reverse Osmosis System

Product Details:

Place of Origin: China
Brand Name: Fenigal/OEM
Certification: CE/UL/NSF etc.
Model Number: SWR-300GPD~60,000GPD

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Export Wood Crate/Carton or Naked wrapped by film
Delivery Time: 15~30 days
Payment Terms: T/T, Western Union, Paypal etc.
Supply Ability: 50 set per month
Get Best Price Contact Now

Detail Information

Technology: Reverse Osmosis Design: Skid Mount
Recovery Rate: 8~40% Feed TDS/ppm: <42,000
Water Temp.: 5~35˚C PH: 4~9
TSS/mg/L: <5 Silt Density Index: <3
Free Chlorine Mg/L: 0 Dissolved Iron Mg/L: <0.1
Warranty: 1 Year Material: SS304/SS316L,carbon Steel
Voltage: 380V,415V,220V,can Be Customized Application: Water Purification,Filtration,pharmceutical,drinking Water,food
Type: Seawater Reverse Osmosis System Function: Water Purifying, Desalination
Desalination Rate: 99%,99.7% Control: Electronic,Manual/PLC
Ro Membrane: Hydranautics Or DOW,4040 Pump: Danfoss/CAT/CNP
High Light:

60000GPD seawater reverse osmosis system

,

SS316L seawater reverse osmosis system

,

99% seawater desalination system

Product Description

Water Purifying 60000GPD Seawater Reverse Osmosis System

SWR-60k Seawater Reverse Osmosis Water Treatment System 300GPD~60,000GPD



For continuous or heavy-duty service in marine applications on and off shore, we manufacture a full line of designed seawater desalination systems.
Seawater Reverse Osmosis (SWRO) is a reverse osmosis desalination membrane process that has been commercially used since the early 1970s. The typical single pass SWRO system consists of the following components:

· Intake: well or open water

· Pre-treatment: Filtration and chemical dosing

· High-pressure pump: to achieve the needed pressure

· Membrane assembly: to perform the desalination process

· PH adjustment: to adjust the alkalinity or acid level

· Disinfection: to prevent any bacterial or organic growth

· Experience in manufacture and supply hundreds of seawater desalination plants with feed water TDS up to 45,000 ppm.



Technical data

Model Capacity Operate pressure Mpa Electricity Dimension Machine type
GPD M3/D Pretreat Membrane Voltage Motor (kw) Power LxWxD (cm)
SWR-300 300 1.1 0.1-0.3 4-6.5 220/380 1.5 15Kwh/T 58x44x160 Vertical
SWR-600 600 2.3 0.1-0.3 4-6.5 220/380 1.5 11Kwh/T 58x44x160 Vertical
SWR-900 900 3.4 0.1-0.3 4-6.5 220/380 1.5 8Kwh/T 58x44x160 Vertical
SWR-1500 1500 5.7 0.1-0.3 4-6.5 220/380 2.2 7.8Kwh/T 65x44x160 Vertical
SWR-3000 3000 11.4 0.1-0.3 4-6.5 380 4.5 7Kwh/T 95x60x180 Vertical
SWR-6000 6000 22.8 0.1-0.3 4-6.5 380 7.5 6Kwh/T 250x70x120 Horizontal
SWR-15K 15000 57.0 0.1-0.3 4-6.5 380 22 4Kwh/T 250x120x170 Horizontal
SWR-30K 30000 114.0 0.1-0.3 4-6.5 380 40 3.5Kwh/T 340x150x180 Horizontal
SWR-60K 60000 228.0 0.1-0.3 4-6.5 380 80 3Kwh/T 340x200x180 Horizontal



2. Operation specifications

Feed TDS 10,000-42000 ppm
Electric control Programmable logic controller | PLC
Feed temperature 2-40℃
Feed PH 3-11
Operation pressure 600-1000 psi / 4-6.5 Mpa
Desalination rate >98%
Permeate water salinaty <500 mg/L
Capacity 500-750 m3/day
Electricity 380V/50HZ/3PH, other volt please specify upon order
Feed water pressure 40-80 psi / 0.1-0.3Mpa







​3. Standard features:

Powder coated carbon steel frame
Heavy duty 5 micron cartridge prefilter
Chemical dosing (for 100TPD or above)
Seawater corrosion resistant stainless steel pumps
PLC based controller panel
Liquid filled 316L pressure gauges
Product and reject flow meters
Spriral wound RO membranes
FRP membrane pressure housings up to 1200 psi
Low and high pressure switch
Permeate TDS monitor
Stainless steel high pressure piping


4. Options

PH/ORP controller
Clean-in-place CIP skid
Multimedia prefilter
Activated carbon prefilter
UV sterilization
Mineralization device
Integrated water purification device
Containerized mobile seawater desalination plant


5. Applications

Island-based business Coastal developments
Work boats Villages & cities
Hotel and resorts Fish processing plants
Cargo ships Seaside work sites
Seaside villas Oil tankers


6. Competitve advantage
We can assist in all or any number of areas required to plan, implement, operate and maintain your seawater RO desalination plant. Defining the Plant Scope refers to establishing the overall project limits that define who is responsible for each part of the Plant, and where the boundaries exist between client and supplier.



Water Purifying 60000GPD Seawater Reverse Osmosis System 0

Water Purifying 60000GPD Seawater Reverse Osmosis System 1



More information about SWRO

What is seawater reverse osmosis?

Seawater reverse osmosis systems are designed to decline more than 99% of saline compromised within the feed water. These systems also incorporate a rinsing, chemical purifying apparatus to eliminate sodium chloride, avert scaling, and preserve system performance. There are two fundamental elements within every seawater reverse osmosis system, which are reverse osmosis membranes and high pressure feed pumps. These elements make up the center of any reverse osmosis system and need special consideration and application for successful operation.



Does reverse osmosis remove salt from seawater?

Yes, semipermeable membranes enable the feed water to pass through it at a much higher volume than dissolved salts. Reverse osmosis systems work by applying pressure as freshwater streams through its membranes to filter out the concentrated saline in the feed water, as well as minerals and pollutants. These unwanted impurities are either flushed away, recycled, or processed. Seawater reverse osmosis systems utilize more than one membrane to boost the load of purified water turned out each day.



What are the advantages of desalination plants?

Seawater desalination has become a vital alternative to the production of pure freshwater throughout the areas of the world without drinkable water. As other sources such as rivers, lakes, wells, and springs have become more exhausted due to excessive extraction, the ocean has provided an abundant supply of available water for human use. Although ocean water consists of elevated levels of salt, and therefore is unable to be utilized for consumption or most other purposes, seawater desalination has helped make it practical.
