Fishing Boat 10000GPD Seawater Reverse Osmosis For Desalination
Product Details:
| Place of Origin: | China |
| Brand Name: | Fenigal/OEM |
| Certification: | CE/NSF etc. |
| Model Number: | SWRO-380~10000LPD,5-13 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard Export Wood Crate/Carton or Naked wrapped by film |
| Delivery Time: | 15~30 days |
| Payment Terms: | T/T, Western Union, Paypal etc. |
| Supply Ability: | 50 set per month |
|
Detail Information |
|||
| Permeate: | 380~10,000GPD | Recovery Rate: | 8~40% |
|---|---|---|---|
| Feed TDS/ppm: | <42,000 | Water Temp.: | 5~35˚C |
| PH: | 4~9 | Dissolved Iron Mg/L: | <0.1 |
| Material: | SS304/SS316L,carbon Steel | Application: | Water Purification,Filtration,pharmceutical,drinking Water,food |
| Function: | Water Purifying, Desalination | Control: | Electronic,Manual/PLC |
| Ro Membrane: | Hydranautics Or DOW,4040 | Pump: | Danfoss/CAT/CNP |
| Highlight: | Fishing Boat Seawater Reverse Osmosis,1000psi Reverse Osmosis Desalination System,10000GPD Seawater Reverse Osmosis |
||
Product Description
Fishing Boat Seawater Reverse Osmosis Desalination System
Fishing boat drinking seawater desalination system plant 380-10000GPD Sea water treatment system
Commercial SWRO4 is equipped with premium components which include duplex SS centrifugal-type high pressure pump for high performance and corrosion resistance, a programmable computer controller with many built-in features, 1000 psi fiberglass membrane housings for durability and US made seawater membranes for high quality product water.
Our SWRO-C Series is available with capacities ranging from 380 GPD to 10,000 GPD and a maximum feed water TDS of 45,000 ppm. We offer standard units as well as customizable to fit you water application needs.
Operation Specifications
| Feed water TDS: 10,000-42,000 ppm Operating pressure: 700 to 1,000 psi pH tolerance range: 3-11 |
Max. feed water temperature: 42°C Feed TDS up to 50,000 ppm H2S, turbidity and organics must be removed |
Feed water pressure: 40 to 80 psi Antiscalant dosing is required Max. Iron content: 0.05 ppm |
| Model No. | Permeate | Membranes | Motor HP | Approx Weight. | Dimensions | |||||
| at 1000 ppm | ||||||||||
| GPD | M3/Day | Size | Qty | 60 HZ | 50 HZ | LBS. | KG | L”xW”xH” | LxWXH (cm) | |
| SWRO4-125 | 380 | 1.4 | 2.5" x 40" | 1 | 2 | 2 | 220 | 100 | 51X21X30 | 130X53X76 |
| SWRO4-225 | 700 | 2.7 | 2.5" x 40" | 2 | 2 | 3 | 230 | 105 | 51X21X30 | 130X53X76 |
| SWRO4-325 | 1,000 | 3.8 | 2.5" x 40" | 3 | 3 | 3 | 250 | 114 | 51X21X30 | 130X53X76 |
| SWRO4-425 | 1,300 | 5 | 2.5" x 40" | 4 | 3 | 3 | 290 | 132 | 51X21X30 | 130X53X76 |
| SWRO4-104 | 1,100 | 4 | 4" x 40" | 1 | 5 | 5 | 395 | 180 | 61X34X50 | 155X86X127 |
| SWRO4-204 | 2,100 | 8 | 4" x 40" | 2 | 7.5 | 7.5 | 500 | 227 | 61X34X50 | 155X86X127 |
| SWRO4-304 | 3,000 | 11 | 4" x 40" | 3 | 7.5 | 7.5 | 360 | 164 | 61X34X50 | 155X86X127 |
| SWRO4-404 | 3,800 | 14 | 4" x 40" | 4 | 7.5 | 7.5 | 500 | 227 | 61X34X50 | 155X86X127 |
| SWRO4-504 | 4,700 | 18 | 4" x 40" | 5 | 10 | 10 | 750 | 341 | 61X34X50 | 155X86X127 |
| SWRO4-604 | 5,600 | 21 | 4" x 40" | 6 | 10 | 10 | 850 | 386 | 61X34X50 | 155X86X127 |
| SWRO4-704 | 6,000 | 23 | 4" x 40" | 7 | 10 | 10 | 970 | 441 | 61X34X50 | 155X86X127 |
| SWRO4-804 | 7,600 | 29 | 4" x 40" | 8 | 15 | 15 | 1,050 | 477 | 61X34X50 | 155X86X127 |
| SWRO4-1004 | 10,000 | 37.9 | 4" x 40" | 10 | 15 | 15 | 1,150 | 523 | 61X34X50 | 155X86X127 |
