Commercial 2300LPH Seawater Reverse Osmosis System
Product Details:
| Place of Origin: | China |
| Brand Name: | Fenigal/OEM |
| Certification: | CE/NSF etc. |
| Model Number: | ROR-300~2300LPH,5-16 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard Export Wood Crate/Carton or Naked wrapped by film |
| Delivery Time: | 15~30 days |
| Payment Terms: | T/T, Western Union, Paypal etc. |
| Supply Ability: | 50 set per month |
|
Detail Information |
|||
| Permeate: | 300~2300LPH | Recovery Rate: | 8~40% |
|---|---|---|---|
| Feed TDS/ppm: | <42,000 | Water Temp.: | 5~35˚C |
| PH: | 4~9 | Dissolved Iron Mg/L: | <0.1 |
| Material: | SS304/SS316L,carbon Steel | Application: | Water Purification,Filtration,pharmceutical,drinking Water,food |
| Function: | Water Purifying, Desalination | Control: | Electronic,Manual/PLC |
| Ro Membrane: | Hydranautics Or DOW,4040 | Pump: | Danfoss/CAT/CNP |
| High Light: | 2300LPH seawater reverse osmosis system,230V seawater reverse osmosis system,2300LPH sea water filtration system |
||
Product Description
Commercial 2300LPH Seawater Reverse Osmosis System
Commercial Seawater Reverse Osmosis Watermaker Systems SWC 80~610GPH 230V 60Hz 3P
Sea Water Reverse Osmosis (SWRO) plants are designed to treat sea water, or high salinity ground water, with < 40,000 mg/L of dissolved solids (TDS) and < 30 mg/L of suspended solids (TSS), to achieve potable water quality.
The standard treatment process involves pre filtration (auto-backwashing multimedia filters and cartridge filters), anti-scalant dosing to prevent membrane scaling, RO desalination and auto flushing and CIP systems for membrane cleaning. Additional pre-RO and post-RO treatment steps may be added as required to suit feed water conditions and/or treated water quality requirements.
Our SWRO plants are available as skid mounted or containerized systems.
Feed water requirement
| Salinity (TDS) | 20,000-45,000 mg/L |
| Temperature | 5-40 °C |
| Turbidity | < 5 NTU |
| COD | < 10 mg/L |
| Ferrous (Fe2+) | < 0.1 mg/L |
| Manganese (Mn2+) | < 0.1 mg/L |
| Note: if the feed water is worse than above, extra pretreatment might be needed. Please contact us for solutions. | |
Technical Data
| Technical Data | Unit | R-6(A) | R-12(A) | R-18(A) | R-24(A) | R-48(A) |
|
Rated Product Flow 1) |
L/H
GPH |
300
80 |
550
150 |
850
220 |
1100
290 |
2300
610 |
| Rated Recovery Rate 1) | % | 30 | 34 | 34 | 34 | 34 |
| Min. Feed-in Pressure | barg | 0 | 0 | 0 | 0 | 0 |
| Max. Feed-in Pressure | barg | 2 | 2 | 2 | 2 | 2 |
| Min System Pressure 2) | barg | 20 | 20 | 20 | 20 | 20 |
| Max System Pressure | barg | 70 | 70 | 70 | 70 | 70 |
| RO Membrane Spec. | inch | 4040 | 4040 | 4040 | 4040 | 8040 |
| RO Membrane Qty. | pcs | 2 | 4 | 6 | 8 | 4 |
| Power | ||||||
| Rated Power 3) | kW | 3.8 | 5.2 | 7.7 | 10.2 | 18.5 |
| Input 4) | 3PH, 380 AC±10%, 50Hz | |||||
Note:
1) The rated product flow and rated recovery rate are based on the design feed (35,000 ppm, 20°C standard seawater). If the feed TDS is lower, higher product flow and higher recovery rate could be available; If the feed TDS is higher, product flow and recovery rate might be lower to avoid over pressure or scaling, contact us for details.
2) The normal system operating pressure shall be above the minimum pressure, and shall not exceed the maximum pressure. For higher system pressure, please contact us.
3) The maximum power at 70bar.
4) For other input voltage and frequency, please inform us while placing the order.
| Technical Data | Unit | R-6A | R-12A | R-18A | R-24A | R-48A |
| L x W x H | mm | 1300x1000x1700 | 1450x1000x1700 | 1500x900x2010 | 1500x960x2010 | 2200x1250x2050 |
| Dry Weight (wet) 1) | kg | 360(+135) | 460(+190) | 840(+350) | 980(+400) | 1500(+600) |
| Inlet | 1” | 1” | 1” | 1” | 1 1/2” | |
| Fresh Outlet | 1/2” | 1/2” | 1/2” | 1/2” | 1 | |
| Waste Outlet | 1” | 1” | 1” | 1” | 1 1/2” | |
Note:
1) The dry weight excludes membrane, quartz sands, filter cartridge and water. The wet weight includes membrane, quartz sands, filter element and water (fully filled).
Optional spec.
Operation Specifications
| Feed water TDS: 10,000-42,000 ppm Operating pressure: 700 to 1,000 psi pH tolerance range: 3-11 |
Max. feed water temperature: 42°C Feed TDS up to 50,000 ppm H2S, turbidity and organics must be removed |
Feed water pressure: 40 to 80 psi Antiscalant dosing is required Max. Iron content: 0.05 ppm |
| Model No. | Permeate | Membranes | Motor HP | Approx Weight. | Dimensions | |||||
| at 1000 ppm | ||||||||||
| GPD | M3/Day | Size | Qty | 60 HZ | 50 HZ | LBS. | KG | L”xW”xH” | LxWXH (cm) | |
| SWRO4-125 | 380 | 1.4 | 2.5" x 40" | 1 | 2 | 2 | 220 | 100 | 51X21X30 | 130X53X76 |
| SWRO4-225 | 700 | 2.7 | 2.5" x 40" | 2 | 2 | 3 | 230 | 105 | 51X21X30 | 130X53X76 |
| SWRO4-325 | 1,000 | 3.8 | 2.5" x 40" | 3 | 3 | 3 | 250 | 114 | 51X21X30 | 130X53X76 |
| SWRO4-425 | 1,300 | 5 | 2.5" x 40" | 4 | 3 | 3 | 290 | 132 | 51X21X30 | 130X53X76 |
| SWRO4-104 | 1,100 | 4 | 4" x 40" | 1 | 5 | 5 | 395 | 180 | 61X34X50 | 155X86X127 |
| SWRO4-204 | 2,100 | 8 | 4" x 40" | 2 | 7.5 | 7.5 | 500 | 227 | 61X34X50 | 155X86X127 |
| SWRO4-304 | 3,000 | 11 | 4" x 40" | 3 | 7.5 | 7.5 | 360 | 164 | 61X34X50 | 155X86X127 |
| SWRO4-404 | 3,800 | 14 | 4" x 40" | 4 | 7.5 | 7.5 | 500 | 227 | 61X34X50 | 155X86X127 |
| SWRO4-504 | 4,700 | 18 | 4" x 40" | 5 | 10 | 10 | 750 | 341 | 61X34X50 | 155X86X127 |
| SWRO4-604 | 5,600 | 21 | 4" x 40" | 6 | 10 | 10 | 850 | 386 | 61X34X50 | 155X86X127 |
| SWRO4-704 | 6,000 | 23 | 4" x 40" | 7 | 10 | 10 | 970 | 441 | 61X34X50 | 155X86X127 |
| SWRO4-804 | 7,600 | 29 | 4" x 40" | 8 | 15 | 15 | 1,050 | 477 | 61X34X50 | 155X86X127 |
| SWRO4-1004 | 10,000 | 37.9 | 4" x 40" | 10 | 15 | 15 | 1,150 | 523 | 61X34X50 | 155X86X127 |
