OEM 6000LPH Reverse Osmosis Water Treatment System

OEM 6000LPH Reverse Osmosis Water Treatment System

Product Details:

Place of Origin: China
Brand Name: Fenigal/OEM
Certification: CE/NSF etc.
Model Number: RO-6000L/H, 1-20

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Export Wood Crate/Carton or Naked wrapped by film
Delivery Time: 15~30 days
Payment Terms: T/T, Western Union, Paypal etc.
Supply Ability: 50 set per month
Get Best Price Contact Now

Detail Information

Permeate Flow: 6000L/h, 38000GPD Design: Skid Mount
Recovery Rate: 60~65% Feed TDS/ppm: <2,000
Water Temp.: 5~35˚C Material: SS304/SS316L,carbon Steel
Voltage: 380V,415V,220V,can Be Customized Desalination Rate: 99%,99.7%
Control: Electronic,Manual/PLC Ro Membrane: Vontron, Hydranautics Or DOW,4040
High Light:

380V Reverse Osmosis Water Treatment System

,

38000GPD Reverse Osmosis Water Treatment System

,

6000LPH underground water purifier

Product Description

OEM 6000LPH Reverse Osmosis Water Treatment System

6TPH Tap/Underground Water Purifier to high pure water Industrial RO Water Treatment Plant



REVERSE OSMOSIS SYSTEMS IN GENERAL :

Reverse osmosis systems, with the most general definition, is removal process of the anion and cation ions by an advanced filtration method which the highest technologies are used as a water treatment system. Water is forced to pass from semi-permeable membranes by applying high pressure. Water cross flows from the surface to the center of the membrane. During this transition, organic and inorganic substances, heavy metals, projects veins, bacteria etc. in the structure of the water retains by the membrane and discharges from the concentrate line. 95% to 99% Purified water can be collected to a tank through permate line. System autoflush before the production starts in order to clean the surface of the membrane.

In this type of systems, for longer and effective use of membranes, pre-filtration and dosing systems must be done correctly.


This water treatment system uses mechanical filters, activated carbon filter as a pre-class treatment, the effective removal of suspended solids in raw water, sediment particles , organic colloids, organic matter, odor, chlorine and other impurities, with pre-programmed as a reverse osmosis desalination plant to remove the raw water. Most of the dissolved salts, bacteria, hot stream and so on, to ensure finished water quality standards.



Features:

1). Automatic backwash and manual backwash
2). Automatic switch on when low water level, and switch off when high water level
3). Water shortage protection for multi-stage pump
4). Protection when no voltage, under-voltage, over-current, short circuit and creepage
5). Full stainless steel structure, durable and easy to clean.
6). Integrating water flow indicator, conductivity indicator, pressure indicator, control panel
7). China Top Brand or world famous brand electrical, switch and valve systems
8). Core components of RO system are imported, USA Filmtec Dow membranes
9). Run and produce water continuously, high degree automation



Processing

raw water - raw water tank - raw water pump - sand filter - carbon filter - softener (optional) - security filter-high pressure pump-reverse osmosis system - water tank-booster pump-reverse osmosis system-pure water tank-water supply points

Flow Chart

Model
RO-6000L
Production capacity
6000L/Hr
Power
3.5Kw
Power supply
2P 380V 50Hz
Reverse osmosis (RO)membrane
USA DOW/VONTRON
Membrane housing
8040FRP
Raw water pump
CNP
Quartz sand filter, activated Carbon filter,Water softener
FRP 3pcs
Security filter
5um PP filter with Stainless steel
High pressure pump
CNP
Activated carbon
250kg
Quartz sand
750kg
Auto Valve
Runxin
Scale
25KG

Applications

1.Textile, chemical industry, process water / chemical recycled water, chemical products manufacturing purification and preparation of water ;
2.Food and beverage industrial water, purified drinking water, beverages, beer, liquor, health care products such as water purification and preparation of water;
3.Seawater,brackish water desalination islands,ships,offshore drilling platforms,brackish water areas;
4.Larger community, real estate property, schools, factories, hospitals, and the restaurants, hotels, beauty salons, canteens and other various types of enterprises and institutions;
5.Integrated circuits, silicon wafers, display tubes and other electronic components of electronic industrial water rinse water;
6.Can be used for filling water bottled water, mineral water and other preparation work.



OEM 6000LPH Reverse Osmosis Water Treatment System 0

OEM 6000LPH Reverse Osmosis Water Treatment System 1

OEM 6000LPH Reverse Osmosis Water Treatment System 2

OEM 6000LPH Reverse Osmosis Water Treatment System 3
