Product Details:

Place of Origin: China
Brand Name: Fenigal/OEM
Certification: CE/UL/NSF etc.
Model Number: Container-RO-1E

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Export Wood Crate/Carton or Naked wrapped by film
Delivery Time: 15~30 days
Payment Terms: T/T, Western Union, Paypal etc.
Supply Ability: 50 set per month
Get Best Price Contact Now

Detail Information

Technology: Reverse Osmosis Design: Skid Mount Containerized
Permeate Flow/TPD: 10~50 Permeate Flow/GPD: 2,632~13,158
Recovery Rate: 40~70% Feed TDS/ppm: <5,000
Water Temp.: 5~35˚C PH: 4~9
TSS/mg/L: <5 Silt Density Index: <3
Free Chlorine Mg/L: 0 Dissolved Iron Mg/L: <0.1
Warranty: 1 Year Material: SS304/SS316L,carbon Steel
Capacity: 0.5-100m3/h Voltage: 380V,415V,220V,can Be Customized
Application: Water Purification,Filtration,pharmceutical,drinking Water,food Size: Depends,1750*550*1650mm
Type: Reverse Osmosis System Function: Water Purifying, Desalination
Desalination Rate: 99%,99.7% Control: Electronic,Manual/PLC
Ro Membrane: Hydranautics Or DOW,4040 Pump: CNP / Grundfos,CNP
High Light:

10FT containerized wastewater treatment plant

,

380V containerized wastewater treatment plant

,

10FT containerized ro system

Product Description

10FT 40m3/H Containerized Wastewater Treatment Plant

Containerized Seawater desalination RO system for drinking water production 40m3/hour

Seawater reverse osmosis system is a containerized desalination solution, with most parts installed into 1 or 2 containers, and fresh water capacity of 50 to 2,000 m3/day (2,040 - 83,270 liters/hour).



The water intake recommendation, extra pre-treatment and post-treatment customizing, installation supervision service, commissioning services could be provided by the technical team upon request.



The desalination process aims to take away salt from seawater. The Reverse Osmosis membrane process starts by filtering feed water particles through applying pressure from the feed pump to the sand filter (No need to use sand filter if the feed water turbidity is lower than 0.3 NTU), then entering the high-pressure pump, to pressurize fresh water out through the membrane, while concentrated water is discharged after pressure relief.



Applications
 Power or Chemical Plants
 Offshore platforms
 Island residents
 Hotels, resorts
 Construction sites
 Emergent water supply, mobile water plants


Operation Limits
Feed water1) salinity (TDS): 20,000-45,000 mg/L Feed water temperature: 5-40 °C Feed water turbidity: < 1 NTU Feed water COD: < 10 mg/L Feed water Ferrous (Fe2+): < 0.1 mg/L Feed water Manganese (Mn2+): < 0.1 mg/L Product2) conductivity3): < 1,200 μS/cm



Technical Data Unit

A20



C20

A50



C50

A80



C80

A100



C100

A150



C150

Rated Product Flow 1) M3/H 0.8 2.3 3.5 4.5 6.5
Rated Recovery Rate 1) % 34 34 34 34 34
Min Pressure In2) barg 4 4 4 4 4
Max Pressure In 2) barg 6 6 6 6 6
Min System Pressure3) barg 20 20 20 20 20
Max System Pressure3) barg 70 70 70 70 70
RO Membrane Spec. inch 4040 8040 8040 8040 8040
RO Membrane Qty. pcs 6 4 6 8 12
Container size (qty) ft 10 10 20 20 20
Weight (dry) 4) ton 3 3 5 6 7
Rated Power5) kW 5 17 25 32 44
Power Input 6)   3PH, 380 AC±10%, 50Hz





Technical Data Unit

A100E



C100E

A150E



C150E

A200E



C200E

A300E



C300E

A500E



C500E

A700E



C700E

A1000E



C1000E

Rated Product Flow 1) M3/H 4.5 6.5 9.5 12.5 21.5 32 41.5
Rated Recovery Rate 1) % 35 35 36 36 45 45 45
Min Pressure In 2) barg 4 4 4 5 5 5 5
Max Pressure In barg 6 6 6 7 7 7 7
Min System Pressure 3) barg 20 20 20 20 20 20 20
Max System Pressure 3) barg 70 70 70 70 70 70 70
RO Membrane Spec.   8040 8040 8040 8040 8040 8040 8040
RO Membrane Qty. pcs 8 12 18 21 42 56 70
Container size (qty) ft 20 20 40 40 40 40(2) 40(2)
Weight (dry) 4) ton 6 7 11 12 15 24 28
Rated Power 5) kW 17 23 30 36 69 92 119
Input 6)   3PH 380V AC±10%,50Hz



Desalination system is designed to produce high quality portable water from seawater or high salinity brackish water.
Together with our 2nd pass RO or even EDI system, it could provide highly pure water for industrial or commercial usage.
It can produce fresh water from 20 to 1000 ton (5-260 thousand gallons) per day.



Whether your application is drinking, process, or waste water. An onsite containerized water or wastewater treatment system is more practical and cost effective instead of buying treated water or discharging the wastewater to water treatment facilities to remove harmful contaminants from the water. Here are some industries that employ the most use of containerized water treatment systems:

  • Public Delivery
  • Mining
  • Military
  • Agriculture
  • Disaster Relief
  • Swimming Pools
  • Power & Energy
  • Wastewater
