100 M³/day 70% Recovery Rate Brackish Water Reverse Osmosis System in 20ft Container
Product Details:
| Place of Origin: | China |
| Brand Name: | FG Water Technologies |
| Certification: | CE |
| Model Number: | BWC100 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Packaging Details: | Standard |
| Delivery Time: | 30 working days |
| Payment Terms: | T/T |
|
Detail Information |
|||
| Rated Recovery Rate: | 70% | Rated Product Flow: | 4.17 M³/h |
|---|---|---|---|
| RO Membrane Qty: | 6 | Dry Weight: | 5T |
| Max System Pressure: | 20barg | RO Membrane Spec: | 8040 |
| Highlight: | 20ft container reverse osmosis system,brackish water RO system 70% recovery,100 M³/day reverse osmosis plant |
||
Product Description
100 M³/day Desal BWC100 Containerized Brackish Water Reverse Osmosis System
Product Description
The Desal BWC100 from FG Water Technologies is a compact, containerized brackish water desalination system designed for small to medium water demands. All core components - including pre-filtration, reverse osmosis membranes, high-pressure pumps, and PLC controls - are pre-installed inside a single 20-foot container.
The system produces up to 100 m³ per day (approx. 4.17 m³/h) of fresh water, effectively treating feed water with TDS between 1,000 and 5,000 mg/L to meet WHO drinking water standards. Factory pre-assembly and pre-commissioning minimize on-site work, reducing civil works and installation time by up to 50% compared to traditional built-on-site plants.
Key Specifications
| Parameter | Unit | Value |
|---|---|---|
| Rated Product Flow | m³/h | 4.17 |
| Rated Product Flow | L/s | 1.39 |
| Rated Recovery Rate | % | 70 |
| Rated Feed Flow | m³/h | 7.14 |
| Max System Pressure | barg | 20 |
| RO Membrane Spec | inch | 8,040 |
| RO Membrane Qty | pcs | 6 |
| Dry Weight | ton | 5 |
| Container Size | ft | 20 |
| Rated Power | kW | 7.9 |
| Energy Consumption | kWh/m³ | 1.58 |
| Installed Power | kW | 18.9 |
| Power Input | - | 3PH, 380V ±10%, 50Hz |
System Features
- Fully integrated in a 20-ft container - minimal site preparation and fast start-up
- Corrosion-resistant construction: Sch10 SS316 high-pressure piping and heavy-duty marine paint
- Energy efficient: IE3 motors and low-energy RO membranes reduce operating costs
- Triple filtration (sand filter, pre-filter, and main filter) protects the pump and membranes
- Quick restoration with standard, off-the-shelf spare parts
- Optional remote monitoring and operational consulting via add-on sensors
Ordering Information
- Standard code: BWC100 (204A003)
- Filter kit (standard): 244P003
- Insulation kit: 254P003
- Premium code: BWC100H (H204A103)
- Filter kit (premium): 244P005
- Insulation kit (premium): 254P003
Applications
Island communities, small towns, hotels & resorts, golf courses, agricultural irrigation, emergency water supply.
