2000 m³/day Containerized BWRO System with 70% Recovery Rate and 1.05 kWh/m³ Energy Consumption
Product Details:
| Place of Origin: | China |
| Brand Name: | FG Water Technologies |
| Certification: | CE |
| Model Number: | BWC500 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Packaging Details: | Standard |
| Delivery Time: | 30 working days |
| Payment Terms: | T/T |
|
Detail Information |
|||
| Rated Recovery Rate: | 70% | Rated Power: | 99.4 KW |
|---|---|---|---|
| Energy Consumption: | 1.05kWh/m³ | Container Size: | 40+40ft |
| RO Membrane Qty: | 108 Pcs | Rated Product Flow: | 85 M³/h |
Product Description
2,000 m³/day Desal BWC2000 – Flagship Containerized BWRO
Key Specifications
| Parameter | Unit | Value |
|---|---|---|
| Rated Product Flow | m³/h | 85 |
| Rated Product Flow | L/s | 23.61 |
| Rated Recovery Rate | % | 70 |
| Rated Feed Flow | m³/h | 121.43 |
| Max System Pressure | barg | 20 |
| RO Membrane Spec | inch | 8,040 |
| RO Membrane Qty | pcs | 108 |
| Dry Weight | ton | 26+6 |
| Container Size | ft | 40 + 40 |
| Rated Power | kW | 99.4 |
| Energy Consumption | kWh/m³ | 1.05 |
| Installed Power | kW | 103.2* |
| Power Input | - | 3PH, 380V ±10%, 50Hz |
*Installed power per original datasheet; please verify with FG Water for exact site configuration.
System Features
- Largest capacity - single system replaces multiple smaller units, reducing footprint
- Redundant pumps - ensures continuous operation even during maintenance
- Intelligent auto-adjustment - adapts recovery and pressure to changing feed water
- Five-layer marine paint - guarantees 20+ years of corrosion protection
- Comprehensive warranty - 18 months from production or 12 months from commissioning
Applications
National strategic water reserves, mega-industrial zones, capital city backup supply, large export-agriculture regions.
