415V 108TPH Reverse Osmosis Water Treatment System

415V 108TPH Reverse Osmosis Water Treatment System

Product Details:

Place of Origin: China
Brand Name: Fenigal/OEM
Certification: CE/NSF etc.
Model Number: SROL-16~108TPH

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Export Wood Crate/Carton or Naked wrapped by film
Delivery Time: 15~30 days
Payment Terms: T/T, Western Union, Paypal etc.
Supply Ability: 50 set per month
Get Best Price Contact Now

Detail Information

Technology: Commercial Water Reverse Osmosis Design: Skid Mount
Permeate Flow/TPH: 16~108 Recovery Rate: 65~75%
Feed TDS/ppm: <2,000 Water Temp.: 5~35˚C
PH: 4~9 TSS/mg/L: <5
Silt Density Index: <3 Free Chlorine Mg/L: 0
Dissolved Iron Mg/L: <0.1 Warranty: 1 Year
Material: SS304/SS316L,carbon Steel Capacity: 0.5-100m3/h
Voltage: 380V,415V,220V,can Be Customized Application: Water Purification,Filtration,pharmceutical,drinking Water,food
Size: Depends,1750*550*1650mm Type: Reverse Osmosis System
Function: Water Purifying, Desalination Desalination Rate: 99%,99.7%
Control: Electronic,Manual/PLC Ro Membrane: Vontron, Hydranautics Or DOW,4040
Pump: CNP / Grundfos,CNP
High Light:

108TPH Reverse Osmosis Water Treatment System

,

NSF Reverse Osmosis Water Treatment System

,

415V reverse osmosis water machine

Product Description

415V 108TPH Reverse Osmosis Water Treatment System

SROL Factory supply reverse osmosis water treatment purification system 16T/h~108T/h

SROL Series Reverse Osmosis Systems have been engineered for capacities ranging from 16m3/h to 108m3/h (Feed TDS < 2500 ppm)



Features

Vontron RO membrane

ASME certified membrane housing

CNP boost pump SS316L

(with ABB VFD & High pressure pump soft start)

SS316 high pressure piping

Control box IP54 (painted carbon steel)

Control system (Siemens PLC, Weinview HMI)

Tank level control & Auto flush

Pretreatment lockout control backup



Benefits

Fully equipped and customizable

Individually tested and preserved

Expandable and skid mounted

Low operation and maintenance costs

Components easily accessible

Easy maintenance and servicing

Pre-plumbed, wired and assembled

1-year limited warranty



Model Capacity Recovery
SROL-16 16m³/hr 75%
SROL-20 19.7m³/hr 75%
SROL-24 24m³/hr 75%
SROL-30 29.9m³/hr 75%
SROL-36 32.5m³/hr 75%
SROL-48 48m³/hr 75%
SROL-60 57.8m³/hr 75%
SROL-72 65m³/hr 75%
SROL-90 86m³/hr 75%
SROL-108 96.8m³/hr 75%



415V 108TPH Reverse Osmosis Water Treatment System 0

415V 108TPH Reverse Osmosis Water Treatment System 1
