Product Details:

Place of Origin: China
Brand Name: Vontron
Certification: CE
Model Number: ULP-4040 series

Payment & Shipping Terms:

Minimum Order Quantity: 1 pc
Price: Negotiable
Packaging Details: standard export packing
Delivery Time: 5- 8 work days
Supply Ability: 60000 Units per Month
Get Best Price Contact Now

Detail Information

Productivity: 250L/Hour Weight (kg): 15 Kg
Core Components: Membrane Place Of Origin: China
Brand Name: Vontron Key Words: 4040 8040 Ro Membrane
Membrane Area: 40 Or 44 Square Meters Feature: High Water Output,low Energy Consumption
Highlight:

High water output Reverse Osmosis Membranes

,

low energy consumption Reverse Osmosis Membranes

,

4040 Reverse Osmosis Membranes

Product Description

Vontron Membrane 4040 Water Reverse Osmosis Membranes High water output,low energy consumption


Vontron Membrane 4040 Water Reverse Osmosis Membranes High Water Output Low Energy Consumption 0
LP-8040, Firstly, in terms of effective membrane area, it is 40 or 44 square meters. When the conductivity is 1000, the water production of a single membrane is greater than 1 ton per hour. The biggest feature of this low-pressure membrane is its high water production and low energy consumption. It is mainly used in brackish water, tap water, and groundwater with a salt content below 5000 milligrams. The main operating pressure is around 10-15 kilograms, with a desalination rate of over 99% and a service life of about 3 years.
Vontron Membrane 4040 Water Reverse Osmosis Membranes High Water Output Low Energy Consumption 1
Vontron Membrane 4040 Water Reverse Osmosis Membranes High Water Output Low Energy Consumption 2
ULP- 4040 series, the membrane effective area is 10 square meters, the water production capacity is 0.25T/H, the water inlet pressure is 150psi.
The biggest feature of this low-pressure membrane is high water production and low energy consumption.
It is mainly used in brackish water, tap water, and groundwater ,But,with a salt content below 5000 milligrams.
The main operating pressure is around 10 kilograms, with a desalination rate of over 99% and a service life of about 3 years
Vontron Membrane 4040 Water Reverse Osmosis Membranes High Water Output Low Energy Consumption 3
Model
BW-8040
BW-4040
Types
Material
Aromatic polyamide composites

Effective membrane area
400(37.2)
85(7.9)

Thickness of water inlet screen
32mil
Performance
Desalination rate
99.3%-99.5%

Water output
10500gpd(40m'/d)
2600gpd(9.2 m'/d)
Test conditions
NaCl solution concentration
2000mg/L
2000mg/L

Pressure, psi (Mpa)
225(15.5)
225(15.5)

Temperature ℃
25℃
25℃

Recovery rate of single membrane
15%
15%

Test solution PH
6.5-7.0
6.5-7.0
Usage conditions
Maximum inlet pressure
600(4.14)


Maximum inlet flow gpm (m³/h)
75(17)
16(3.6)

Inlet PH range
2-10
2-10

Clean PH range
1-12
1-12

Maximum inlet turbidity, NTU
1.0
1.0

Maximum inlet SDI
<5
<5

Maximum inlet residual chlorine concentration.mg/L
<0.1
<0.1

Minimum ratio of concentrated water to water output
5:1
5:1

Maximum pressure drop of single membrane element psi (MPA)
10(0.07)
10(0.07)
Vontron Membrane 4040 Water Reverse Osmosis Membranes High Water Output Low Energy Consumption 4
Vontron Membrane 4040 Water Reverse Osmosis Membranes High Water Output Low Energy Consumption 5
Vontron Membrane 4040 Water Reverse Osmosis Membranes High Water Output Low Energy Consumption 6
Vontron Membrane 4040 Water Reverse Osmosis Membranes High Water Output Low Energy Consumption 7
Vontron Membrane 4040 Water Reverse Osmosis Membranes High Water Output Low Energy Consumption 8
Vontron Membrane 4040 Water Reverse Osmosis Membranes High Water Output Low Energy Consumption 9



Vontron Membrane 4040 Water Reverse Osmosis Membranes High Water Output Low Energy Consumption 10 Vontron Membrane 4040 Water Reverse Osmosis Membranes High Water Output Low Energy Consumption 11

Manufacturer, excellent strength
The membrane production process and automated production line introduced from the United States, with an annual production capacity of 3 million square meters of reverse osmosis membranes and nanofiltration membranes. The team has strong and unique R&D and innovation capabilities, and strong technical support can provide customers with customized industry solutions to meet customers' deep and multi-faceted needs.

Quality assurance, superior performance
The entire reverse osmosis membrane and nanofiltration membrane product production process is strictly carried out in accordance with ISO standards. All products are strictly tested with advanced testing equipment to ensure product performance and factory quality.

Vontron Membrane 4040 Water Reverse Osmosis Membranes High Water Output Low Energy Consumption 12

National qualifications, look for Qinsen Hi-Tech
It has more than 30 international and domestic invention patents, and has fully passed the ISO9001 quality system and national health safety product certification of national authoritative institutions, and the NSF certification of the National Health Foundation of the United States.

Vontron Membrane 4040 Water Reverse Osmosis Membranes High Water Output Low Energy Consumption 13



About Us
FG Water Technologies (www.fgwater.com) is now an organic part of Wuxi Fenigal Science and Technology Co. Ltd., which is a high-tech entity integrating water treatment quipment design, manufacturing, trading and shipment served for main industrial sectors.
HAFE-FG Water Technologies has focused on the research of water treatment technology, equipment development and manufacturing, testing and international shipment etc. We work with many leading large-scale or small-medium original equipment manufacturers in China High-tech Development Zones, and engaged ourselves in R&D, manufacturing, and quality testing.
Our main products include a variety of water purification and different treatment equipment, such as seawater reverse osmosis (SWRO) system, brackish water rever osmosis (BWRO), ultrafiltration (UF)system, Electrodeionization/EDI equipment, media pressure filters and ion exchanger softeners. So far, our company has become a major water treatment equipment supplier for food and beverage industry, pharmaceutical industry, chemical industry, electric power industry, urban water supply industry, municipal and industrial wastewater treatment and more industries, as well as being an exporter to more than 20 countries and regions in Asia, Europe, the Americas, Africa, etc.
