Industrial Series Reverse Osmosis Membranes ULP-4040MR For Low Working Pressure
Product Details:
| Place of Origin: | China |
| Brand Name: | Keensen |
| Certification: | CE |
| Model Number: | ULP-4040MR |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiable |
| Packaging Details: | standard export packing |
| Delivery Time: | 5- 8 work days |
| Supply Ability: | 60000 Units per Month |
|
Detail Information |
|||
| Active Membrane Area Of The Element: | 7.9m2 | Permeate Flow GPD(T/D) Of Element: | 2200(8.3) |
|---|---|---|---|
| Stable. Rejection Rate (%) Of Element: | 99.6 | Max. Working Pressure Of Element: | 600 Psi(4.14MPa) |
| Max. Feed Water Flow Of Element: | 17.0m /h（8040）、3.6m /h（4040 | Max. Feed Water SDI15 Of Element: | 5.0 |
| Free Chlorine Concentration Of Feed Water: | 0.1mg/L | PH Range Of Feed Water During Continuous Operation: | 3-10 |
| Advantage Of RO Membrane: | Ultra Low Pressure | ||
| Highlight: | Industrial Series Reverse Osmosis Membranes,ULP-4040MR Reverse Osmosis Membranes,Low Working Pressure Reverse Osmosis Membranes |
||
Product Description
Industrial Series Reverse Osmosis Membranes ULP-4040MR For low working pressure
1.Long life and high recovery rate: The ultra-low pressure reverse osmosis membrane has a long service life, reduces the frequency of replacement, and improves economy and environmental protection. At the same time, its recovery rate is high, usually between 60%-80%, and has a higher water resource utilization rate than traditional water treatment technology.
2.Wide application: Ultra-low pressure reverse osmosis membranes are widely used in many fields such as seawater desalination, industrial wastewater treatment, and drinking water purification, showing extremely high application value.
It is suitable for the desalination treatment of municipal tap water and groundwater with a salt content of less than 1500ppm. It can be widely used in residential water supply systems, pure water preparation plants, industry, food production and other fields.
| Model | Active Membrane Area ft2(m2) | Permeate Flow GPD(T/D) | Stable Rejection Rate (%) |
| ULP-4040MR | 85(7.9) | 2200(8.3) | 99.6 |
| Concentration of Solution (NaCl) | Temperature(℃) | pH Value > | Operating Pressure psi(MPa) | Recovery Rate(%) |
| 1500ppm | 25 | 7.5-8 | 150(1.03) | 15 |
Notes: The permeate flow of single membrane element may vary with in ±15%.
Operating Limits and Conditions of Membrane Element:
| Max.Working Pressure | 600 psi(4.14MPa) |
| Max. FeedWater Temperature | 45 ℃ |
| Max. Feed Water Flow | 17.0m3/h |
| Max. FeedWaterSDI15 | 5.0 |
| Free Chlorine Concentration of FeedWater | 0.1mg/L |
| pHRange of FeedWaterDuring Continuous Operation | 3-10 |
| pHRange of FeedWaterDuring Chemical Cleaning | 2-12 |
| Max. Pressure Drop of Single Membrane Element | 10psi(0.07Mpa) |
|
|
Manufacturer, excellent strength
The membrane production process and automated production line introduced from the United States, with an annual production capacity of 3 million square meters of reverse osmosis membranes and nanofiltration membranes. The team has strong and unique R&D and innovation capabilities, and strong technical support can provide customers with customized industry solutions to meet customers' deep and multi-faceted needs.
Quality assurance, superior performance
The entire reverse osmosis membrane and nanofiltration membrane product production process is strictly carried out in accordance with ISO standards. All products are strictly tested with advanced testing equipment to ensure product performance and factory quality.
National qualifications, look for Qinsen Hi-Tech
It has more than 30 international and domestic invention patents, and has fully passed the ISO9001 quality system and national health safety product certification of national authoritative institutions, and the NSF certification of the National Health Foundation of the United States.
