1000L PE Tank Auto Chemical Dosing System With Metering Pump

1000L PE Tank Auto Chemical Dosing System With Metering Pump

Product Details:

Place of Origin: China
Brand Name: Fenigal/OEM
Certification: CE/NSF etc.
Model Number: CDS-5B

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Export Wood Crate/Carton or Naked wrapped by film
Delivery Time: 15~30 days
Payment Terms: T/T, Western Union, Paypal etc.
Supply Ability: 200 set per month
Get Best Price Contact Now

Detail Information

Application: Chemical Dosing Method: Chemical Treatment
Function: Mix And Dosing Chemical Agent To Wastewater Usage: Industrial
PE Tank Volume: 100~1000L Configuration: Pump + Mixer+ PE Tank
Control: Electronic,Manual/PLC
High Light:

120GPD Auto Chemical Dosing System

,

1000L Auto Chemical Dosing System

,

120GPD dosing system in water treatment plant

Product Description

1000L PE Tank Auto Chemical Dosing System With Metering Pump

Chemical Dosing Systems with 100~1000L PE tank and metering pump

Chemical dosing system is widely applied in corrosion, scale inhibition, sterilization and algae removal of the circuiting water systems such as air-conditioning cooling water, chilled water, ice storage, etc.The chemical dosing system can also achieve the effect equivalent to the electronic descaling instrument.In the process of air conditioning circulating water and various purified water, the water quality always decides if the system can run efficiently for a long time. The pipeline corrosion, scaling, microbial propagation and other common problems of circulating water always disturber the owners.


The CDS series chemical dosing systems offer a wide range of capacities to meet various chemical treatment applications. Each system includes the chemical metering pump and polyethylene chemical tank, along with the necessary hoses and fitting for the pump.



Standard Features

Fully adjustable output capacity from 3-120 GPD

Manual function control for stroke rate & length

Highly reliable timing circuit

EMI resistant

Thermally protected solenoid with auto-reset

Bleed valve assembly

Plastic pvc head/fittings and polyethylene tank for a

wide range of corrosion resistance to such

chemicals as mild acid, chlorine, and caustic solution



Available Options

Epoxy coated stainless steel mixer

pH controller

ORP controller

Stand-by pump

Skid mounted unit

Custom built unit

Pump maintenance spare kit

Level switch

Local control panel



Materials of Construction

Pump Head: PVC

Diaphragm: Teflon-faced

O-Rings: Teflon

Balls: Ceramic

Fittings: PVC

Tubing: Clear PVC / White PE

Tank / Cover: Polyethylene



Product Paramenters

Chemical tank volume 100/200/500/1000 Liters
Chemical tank material PE/SUS316L
Water quality monitor pH/orp/conductivity/chlorine monitor
Power supply 110-240V/50,60Hz/1phase



Chemical dosing system is widely applied in corrosion, scale inhibition, sterilization and algae removal of the circuiting water systems such as air-conditioning cooling water, chilled water, ice storage, etc.The chemical dosing system can also achieve the effect equivalent to the electronic descaling instrument.In the process of air conditioning circulating water and various purified water, the water quality always decides if the system can run efficiently for a long time.



Equipment Model

Type Volume of chemical tank(Liters)

Dimension

(LxW xH mm)

Flow rate of circulating water

(m3/h)

One tank with One pump 100 550 550 1250 no more than 300
One tank with One pump 200 650 650 1440 no more than 5000
One tank with One pump 500 910 910 1650 no more than 20000
One tank with One pump 1000 1140 1150 1800 no more than 30000
Two tank with Two pump 200 1250 650 1440 no more than 5000
Two tank with Two pump 500 1770 910 1650 no more than 20000
Two tank with Two pump 1000 2250 1150 1800 no more than 30000
Three tank with Three pump 200 1250 650 1440 no more than 5000
Three tank with Three pump 500 1770 910 1650 no more than 20000
Three tank with Three pump 1000 2250 1150 1800 no more than 30000
Three tank with Three pump 200 1850 650 1440 no more than 5000
Three tank with Three pump 500 2630 910 1650 no more than 20000
Three tank with Three pump 1000 3350 1150 1800 no more than 30000
