4 Inch 4021 4040 Stainless Steel RO Membrane Housing
Product Details:
| Place of Origin: | China |
| Brand Name: | Fenigal/OEM |
| Certification: | CE/NSF etc. |
| Model Number: | SS-PV |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard Export Wood Crate/Carton or Naked wrapped by film/Containerized |
| Delivery Time: | 15~30 days |
| Payment Terms: | T/T, Western Union, Paypal etc. |
| Supply Ability: | 10,000 set per month |
|
Detail Information |
|||
| Techno Filtrationlogy: | Pressure Vessel | Material: | Stainless Steel |
|---|---|---|---|
| Design: | Skid Mount/containerized | Water Temp.: | 5~35˚C |
| Element: | 1-8/vessel | Voltage: | 380V,415V,220V,can Be Customized |
| Dimension: | 40",80",120" Etc. | Size: | Dia.2.5"/4"/8" |
| Control: | Electronic,Manual/PLC | ||
| High Light: | 4021 stainless steel ro membrane housing,4 Inch stainless steel ro membrane housing,4040 ro membrane filter housing |
||
Product Description
4 Inch 4021 4040 Stainless Steel RO Membrane Housing
4 Inch 4021 /4040 Membrane Housing ABS End Cap /Plug SS304/316L RO Water Purifier Membrane Housing 300psi
4’’ Membrane Housing-ABS/Nylon End Cup -300PSI
End port, Stainless Steel Tri-clamp closure
Max working pressure: 300 PSI
Max working temperature: 90 ℃
Housing Material: SS304/316L
End cap material: ABS/Nylon
O-ring material: EPDM, with NSF certificate
Finish: Mechanical polishing (240 mesh, Ra<0.8)
Connet type:female thread
Model: for 4021/4040 , from 1~3 element
Main performance characteristic
1. 4-inch RO membrane housing 1 core , 2 cores , 3 cores, 4 cores , etc.
2. The membrane housingt tube is divided into tube , two kinds of seamless pipe.
The seam automatic welding work involved forming, weld uniform, smooth, both inside and outside surface for mirror processing. Pressure test before delivery, pressure up to 16 kg;
Seamless tube pull with forging stock directly, uniform wall thickness, not easy to leak,
do mirror processing, internal and external surface before delivery pressure test, pressure up to 25 kg.
3. In and out of nozzle connection with side in side out, side in side out two;
Specifications have 6 x4 points and 4 x4 points two kinds.
4. The head material is ABS, stainless steel.
High Pressure Stainless Steel 4 Inch RO Membrane Housing Victaulic Coupling 1000PSI Vessel
Main performance characteristic
1. 4-inch RO membrane housing 1 core , 2 cores , 3 cores, 4 cores , etc.
2. The membrane housingt tube is divided into tube , two kinds of seamless pipe.
The seam automatic welding work involved forming, weld uniform, smooth, both inside and
outside surface for mirror processing. Pressure test before delivery, pressure up to 16 kg;
Seamless tube pull with forging stock directly, uniform wall thickness, not easy to leak,
do mirror processing, internal and external surface before delivery pressure test, pressure up to 25 kg.
3. In and out of nozzle connection with side in side out, side in side out two;
Specifications have 6 x4 points and 4 x4 points two kinds.
4. The head material is ABS, stainless steel.
Product Discription
4’’ Membrane Housing-For Industry-1000PSI
Side port,Qty:2-8pcs
Max working pressure: 1000PSI
Max working temperature: 90 ℃
Housing Material: SS304/316L
End cap material: SS 304/316L
Adapter: SS304/316L
O-ring material: EPDM, with NSF certificate
Finish: Mechanical polishing (320 mesh, Ra<0.6)
F/C port: Victaulic
Permeate port: NPT/BSP female thread
Model: for 4021/4040 , from 1~3 element
