Product Details:

Place of Origin: China
Brand Name: Fenigal/OEM
Certification: CE/NSF etc.
Model Number: IX-1A

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Export Wood Crate/Carton or Naked wrapped by film/Containerized
Delivery Time: 15~30 days
Payment Terms: T/T, Western Union, Paypal etc.
Supply Ability: 200 set per month
Get Best Price Contact Now

Detail Information

Technology: Pressurized Filtration Material: Carbon Steel/FRP/stainless Steel
Design: Skid Mount/containerized Water Temp.: 5~35˚C
Water Flow Rate: Up To 200 M3/day.vessel Voltage: 380V,415V,220V,can Be Customized
Application: Surface, Underground Water, Sewage Water Treatment Size: Dia.20cm~180cm
Control: Electronic,Manual/PLC
High Light:

800000 Grain Ion Exchange Water Purification System

,

NSF Ion Exchange Water Purification System

,

800000 Grain dual bed deionizer

Product Description

800000 Grain Ion Exchange Water Purification System

Dual Bed Deionizers by ion exchange purification water filters 200,000 to 800,000 grains

Engineered for large-sized deionization (DI) applications, these dependable units feature precise electronics and performance characteristics, using diaphragm valves package. Applications cover the full spectrum of industrial, medical, electronics manufacturing, boiler feed water, and chemical manufacturing uses. We are able to supply a full line of standard and fully customizable dual bed deionizer systems, all of which are engineered using advanced computer modeling and process design software for accurate and customized solutions.

Advantages Of A Dual Bed Deionizers DB-X Series

  • Two-Bed Automatic “Package” Deionizers are available in sizes from 11-43 GPM, and at rated exchange capacities of 200,000 to 800,000 grains. These systems are fully-assembled, with all wiring and tubing completed requiring minimum installation and start-up effort. Skid mounting is an option.
  • Exchanger's vessels are all nonmetallic construction, rated at 150 psi.
  • Piping is Schedule 80 PVC, with solvent-welded joints, rigidly supported on unit strut channels.
  • Valves-Noryl diaphragm type, pneumatically operated, with integral travel, stops for flow regulation.
  • Internal distributions are PP/schedule 80 PVC and radial lateral design.
  • The provided cation resin is a high capacity strong acid, bead-form, conventional gel polystyrene sulfonated exchange resin which is shipped in the hydrogen form ready for immediate use. Resin capacity information is based on 6 lbs. of HCL per cu. ft. of exchange resin. The provided anion is a high capacity strong base, type 2, bead form, conventional gel exchange resin which is shipped in the chloride form for maximum storage life. Resin capacity information is based on 6 lbs. of NaOH per cu. ft. of exchange resin.
  • Optional stainless steel liquid filled pressure gauges, sample valves, flow indicator on water inlet, and inlet pressure reducing valve.



Pre-Treatment Systems: Post-Treatment Systems Other Systems
  • Multi-media filter
  • Ultrafiltration system
  • Activated carbon filter
  • Reverse osmosis system
  • Mixed bed deionization
  • UV sterilization
  • Ozonation system
  • Activated carbon filter
  • Neutralization system
  • Distribution system
  • Degasifiers




Model #
Nominal
Capacity
(Grains)
Service Flow
(GPM)

Pipe Size

Mineral Tank Size
Resin Quantity (ft)3
Cont. Peak Cation Anion
DB24-FRP 200,000 11 35 2” 24”x72” 10 10
DB30-FRP 300,000 17 50 2” 30”x72” 15 15
DB36-FRP 400,000 25 70 2” 36”x72” 20 20
DB42-FRP 600,000 34 100 3” 42“x72” 30 30
DB48-FRP 800,000 43 135 3” 48”x72” 40 40



Standard Features: Available Options:
  • FRP tank with 150 psi rating / corrosion resistance
  • Auto regeneration on preset water quality limit
  • High quality IX resin
  • Constant monitoring of water quality
  • Solid-state reliability for trouble-free service
  • No untreated by-pass water
  • Automatic shut down in the event of power failure
  • Compact, non-corrosive components
  • Digital stager with resistivity monitor
  • Convenient, modular construction
  • Noryl diaphragm valves
  • Programmable purge prior to regeneration
  • 120V/1ph/60Hz power requirement
  • 1/4” tubing between stager and valves
  • Schedule 80 PVC face piping
  • PP/PVC sch 80 internal piping and distributor
  • Flow control
  • Divert
  • Flow meter
  • Drum suction pipe
  • Duplex, triplex or multi units
  • Skid mounted, plumbed and wired
  • PLC control system
  • ASME coded tanks
  • Butterfly control valves
  • 240V/1ph/50Hz power requirement
  • Recirculation pumps
  • Unistrut channel supports




800000 Grain Ion Exchange Water Purification System 0

800000 Grain Ion Exchange Water Purification System 1



Manufacturing Laboratories Commercial
  • Paint
  • Chemicals
  • Cosmetics
  • Electronics
  • Textiles
  • Plating
  • Electrode position
  • Metalworking lubricants
  • Testing and materials
  • Research and development
  • Glassware rinse
  • Glass/Mirror
  • Boiler feed
  • Humidification control
  • Hospitals/Medical facilities
  • Laboratory Water Purification Systems
  • Vehicle washes - cars to aircraft
  • Film processing
  • Ice plants
  • Horticulture/Greenhouse
  • Food/Beverage processing
  • Printing
  • Ink and dye manufacturing
