Product Details:

Place of Origin: China
Brand Name: Fenigal/OEM
Certification: CE/UL/NSF etc.
Model Number: WTS-1

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Export Wood Crate/Carton or Naked wrapped by film
Delivery Time: 15~30 days
Payment Terms: T/T, Western Union, Paypal etc.
Supply Ability: 200 set per month
Get Best Price Contact Now

Detail Information

Technology: Pretreatment+Reverse Osmosis/UF/NF Etc. Design: Skid Mount/Containerised
Permeate Flow/TPD: 0.25~1000 Permeate Flow: 1,679~263,158 GPD
Recovery Rate: 40~70% Feed TDS: <2,000 Ppm
Water Temp.: 5~35˚C PH: 4~9
TSS: <5 Mg/L Silt Density Index: <3
Warranty: 1 Year Material: SS304/SS316L,carbon Steel,FRP
Capacity: 0.25-100m3/h Voltage: 380V,415V,220~240V Etc
Application: Water Purification,Filtration,pharmceutical,drinking Water,food Desalination Rate: 99%,99.7%
Control: Electronic,Manual/PLC Ro Membrane: Vontron, Hydranautics Or DOW, 4040/8040
High Light:

1000TPD Purified Water Treatment System

,

NSF Purified Water Treatment System

,

1000TPD food and beverage water treatment

Product Description

1000TPD Purified Water Treatment System , Food And Beverage Water Treatment

Purified water treatment system for food and beverage industry



Key food and beverage water treatment technologies include:

We provide a number of technologies for treating water used in the beverage and food industries. Each provides technological solutions for the various stages of water treatment that are required in the food & bev industry.

  • Clarification: helps remove suspended solids and particulate matter - usually with the help of flocculants and coagulants, which improve settling.
  • Filtration: used for the physical, mechanical and biological separation of solids from treated water.
  • Membrane filtration: feed water is forced through a semi-permeable membrane at high pressure to separate specific materials from the solution.
  • Softening: water softening involves removing calcium, magnesium and other metal cations using ion exchange resins.
  • Deionisation: used for water softening, either cationic or anionic ion-exchange.
  • Reverse osmosis: uses membrane separation like membrane filtration.
  • Disinfection with water treatment chemicals and UV: Destroys disease-causing organisms to prevent their spread. Processes such as ozonation and ultraviolet irradiation also aid in the destruction of biological contaminants that remain in the water after treatment.
  • Biological treatment: helps upgrade the quality of beverage and food industry effluent being released into the environment and a major component in water recycling from high organic load wastewater.

FOOD AND BEV APPLICATIONS COVERED

Food and beverage subsectors including:

  • Food: aquaculture, dairy, meat processing, oils, fruit and vegetable processing
  • ​Beverage: breweries, soft drinks, distilleries, spirits

As a water treatment supplier, we understand the key concerns in the water cycle management related to:

  • water as a food ingredient: process water
  • water for industrial use: utility feed water
  • wastewater treatment
  • grease, sludge and by-products treatment
  • ​water recovery, recycling and reuse

Operation Specifications

Max. feed water temperature: 42°C
Equipment upgrade for TDS up to 5,000 ppm
Hydrogen Sulfide must be removed
Max. Silica tolerance: 25 ppm @ 60% recovery
Feed water TDS: 0-2,000 ppm
Operating pressure: 150 to 250 psi
pH tolerance range: 3-11
Max. Iron content: 0.05 ppm
Feed water pressure: 20 to 80 psi
Hardness over 1 GPG requires water softener
Turbidity should be removed
Operate at higher TDS by lowering recovery





Model Number Permeate Flow Rate Pressure Vessel 4" Membranes Motor Rating at 1,000 ppm Approx. Weight Dimensions
GPD M3/D Qty. Qty. 60Hz (hp) 50Hz (kw) LBS KG L”xW”xH” LxWXH (cm)
RON-3340 13,000 50 3 9 3 2.2 750 341 136x43x60 345x109x152
RON-5240 15,000 57 5 10 5 3 850 386 96x43x60 244x109x152
RON-4340 18,000 68 4 12 5 2.2 875 398 136x43x60 345x109x152
RON-5340 22,000 85 5 15 5 3 900 409 136x43x60 345x109x152
RON-8240 24,000 91 8 16 5 3 950 432 96x43x68 244x109x173
RON-6340 27,000 102 6 18 5 3 990 450 136x43x68 345x109x173
RON-7340 32,000 121 7 21 5 4 1025 466 136x43x68 345x109x173



1000TPD Purified Water Treatment System , Food And Beverage Water Treatment 0

1000TPD Purified Water Treatment System , Food And Beverage Water Treatment 1

1000TPD Purified Water Treatment System , Food And Beverage Water Treatment 2

1000TPD Purified Water Treatment System , Food And Beverage Water Treatment 3
