Product Details:

Place of Origin: China
Brand Name: Fenigal/OEM
Certification: CE/ISO etc.
Model Number: MBR-3-3B

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Export Wood Crate/Carton or Naked wrapped by film/Containerized
Delivery Time: 15~30 days
Payment Terms: T/T, Western Union, Paypal etc.
Supply Ability: 200 set per month
Get Best Price Contact Now

Detail Information

Technology: Membrane Bioreactor Membrane: PVDF/PTFE Holow Fiber, Flat-sheet Optional
Design: Skid Mount/containerized Water Temp.: 5~35˚C
Water Flowrate: Up To 315 M3/day Material: Carbon Steel
Voltage: 380V,415V,220V,can Be Customized Application: Waste Water, Sewage Water Treatment
Size: Compact Or Bigger Control: Electronic,Manual/PLC
High Light:

120m3/d Packaged Wastewater Treatment System

,

380V Packaged Wastewater Treatment Systems

,

120m3/d membrane bioreactor wastewater treatment plant

Product Description

380V Packaged Wastewater Treatment System , Membrane Bioreactor Wastewater Treatment Plant

PP or PVDF reinforced hollow fiber membrane mbr package plant wastewater treatment systems



PP or PVDF or mPA reinfroced hollow fiber membrane

Anti-fouling,bigger flux,super hydrophilic Capacities from 10 to 100 000 m3/day

Standard pre-engineered design packages

Efficient, compact design, reduced footprint

Robust, high-quality system and components

Single-source supply,Easily expandable

Fast delivery and installation,modular design

Meets or exceeds most regulatory requirements



Range of MBR applications

MBR plants are increasingly used for locations where water resources are scarce, reusable- quality effluent is desirable, space availability is limited, and/or stringent discharge standards are in effect. There locations includes small communities, housing developments, commercial developments,

mining camps, resorts, hotels, malls, schools, and golf courses, among others. What's more, the MBR system

has been employed in industrial waste water processing and recycle, desalination prefilter, municipal water treatment, the factory of chemical or pesticide or cosmetic or pharmaceuticals,etc.



Specifications:

Type

size

Treatment

capacity

Membrane

size

Qty

(pcs)

Module

(units)

Total

Installed power

Operating power

(KW)

Tank size(mm) No.s of tank
MBR-25 25 m³/d PURE-100 80 1 7.8 3.35 9000*2400*2500 1
MBR-40 40 m³/d PURE-100 100 1 7.8 3.35 7000*2400*2500 1
MBR-50 50 m³/d PURE-100 160 2 9.75 5.25 9000*2400*2500 1
MBR-80 80 m³/d PURE-100 200 2 13.8 5.25 10000*2400*2500 1
MBR-100 100 m³/d PURE-100 140 3 19.9 10.7 10000*2400*2500 1
MBR-120 120 m³/d PURE-100 300 3 21.75 13.55 10000*2400*2500 1
MBR-160 160 m³/d PURE-100 400 4 27.75 16.55 12000*2400*2500 1
MBR-200 200 m³/d PURE-100 500 5 30.85 18.25 7000*2400*2500 2
MBR-240 240 m³/d PURE-100 600 6 38.9 23.2 8500*2400*2500 2
MBR-320 320 m³/d PURE-100 800 8 38.9 23.2 10000*2400*2500 2
MBR-400 400 m³/d PURE-100 1000 10 30.35 15.75 11500*2400*2500 2
MBR-480 480 m³/d PURE-100 1200 12 33.65 15.9

13500*2400*2500

12000*2400*2500

1

1

MBR-560 560 m³/d PURE-100 1400 14 43.85 21 8500*2400*2500 3
MBR-640 640 m³/d PURE-100 1600 16 41.85 20 11500*2400*2500 3
MBR-720 720 m³/d PURE-100 1800 18 54.85 26 12000*2400*2500 3



380V Packaged Wastewater Treatment System , Membrane Bioreactor Wastewater Treatment Plant 0

380V Packaged Wastewater Treatment System , Membrane Bioreactor Wastewater Treatment Plant 1





More features:

1. Because of the high-efficiency solid-liquid separation, it can efficiently remove the SS, colloidal material and dead microbe in the sewage, no need sedimentation tank, or filter device, nor other solid-liquid separation device.

2. The MBR can make the biomass in biological treatment unit maintain high concentration, thus highly improve the volume loading. Meanwhile, the high efficient membrane separation can shorten the HRT. The device is with a compact structure and small space occupation.

3. MBR can filter out bacteria, part of the harmful material such as virus, it can obviously save dosing disinfection dosage, greatly improve the quality of the output water and reduce the operating cost and widen the scope of application of water.

4. Due to the strong interception function of MBR, it can keep the microbe in the reactor to avoid the loss of all kinds of microbe groups, which is good for the growth of the bacteria (such as the nitrifying bacteria), at the same time, it can lengthen the residence time of difficult degradable macromolecule organics to improve the decomposition so as to make the metabolic system process smoothly. The system has a strong impact resistance and wide suitability.

5. It can realize the completely separation of HRT and SRT. By the extended aeration, it can consume the organics, it can theoretically achieve the effect of no excess sludge emissions, thus reduce the surplus sludge treatment costs significantly.

6. The unique mode of operation makes the membrane surface no blocking, and the cleaning interval time is long. The way to clean the membrane is easy, since the membrane module can be separately cleaned, thus, the maintenance is convenience and simple.

The module design make the machine flexible, it is easy to expand the volume.

Advantages:

1) can save 50% area compare with the traditional process

2)Can treat high MLSS waste water (<10g/L), with long residence time for sludge(less30 days)

3)Steady Producing water quality for different water quality

4)Output Sludge value is low , lower the treatment sludge fee

5)Low consumption , cleaning easy ,and low operation cost

6)The equipment is carbon steel Integration , biological oxidation and membrane reaction and back wash operate in same integration sewage treatment plant

(7)Compare the concrete structure , MBR Integration system /Package Sewage treatment Plant low occupy

area , and construction is easy . Only need do a base

(8)Can put underground , and surface can do greening
