100 TPD Solar Hybrid Containerized RO Pure Water Equipment in 40ft Unit for Seawater Desalination
Product Details:
| Place of Origin: | China |
| Brand Name: | Fenigal/OEM |
| Certification: | CE/ISO 9001/CSC Container |
| Model Number: | FRO-CSolar-100 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Self-Contained 40ft ISO Container (PV Panels Shipped Separately) |
| Delivery Time: | 60~75 days |
| Payment Terms: | T/T,L/C,Western Union |
| Supply Ability: | 6 set per month |
|
Detail Information |
|||
| RO Permeate Flow: | 100 M³/day (4.2 M³/h, 26,400 GPD) | RO Recovery Rate: | 65~75% |
|---|---|---|---|
| Feed Water TDS: | ≤ 3,000 Ppm | Salt Rejection: | ≥ 99.0% |
| RO Operating Pressure: | 8~14 Bar | Solar PV Array: | 50 KWp (125 * 400W Monocrystalline Modules) |
| Highlight: | Solar Hybrid Containerized RO,Off Grid RO Water System,100m3 Day Renewable Desalination |
||
Product Description
For Seawater/Brackish Water Desalination
The FRO-CSolar-100 is a revolutionary off-grid water treatment solution that combines a proven 100 m³/day (26,400 GPD) reverse osmosis desalination plant with an integrated solar photovoltaic energy system and diesel generator backup, all managed by an intelligent Energy Management System (EMS) within a standard 40ft ISO container. Designed for locations without any grid electricity infrastructure, this hybrid system enables year-round reliable water production with 70-85% of annual energy provided by renewable solar power, dramatically reducing both operational costs and carbon emissions compared to diesel-only solutions.
- Intelligent Tri-Mode Energy Management: Proprietary EMS controller optimizes power sourcing across solar-direct, battery-powered, and generator-backup modes for uninterrupted 24/7 operation
- 50 kWp Solar PV Array: Field-deployed ground-mount system with 125 high-efficiency monocrystalline modules (400W each) and adjustable tilt-angle mounting structures
- 100 kWh LiFePO4 Battery Bank: Provides 12-14 hours of autonomous RO operation at full capacity with superior thermal stability and 6,000+ cycle life
- 16 Low-Energy RO Membranes with VFD Pump: DOW Filmtec BW30-8040 elements requiring only 8-14 bar operating pressure, combined with Grundfos CRN pump with variable frequency drive
- Integrated 80 kVA Diesel Generator: Sound-attenuated generator with 500L belly tank, automatic start/stop control, and fire-rated compartment
- 4G Remote Monitoring with Energy Analytics: Comprehensive SCADA system transmits operational data to cloud dashboard for remote monitoring and maintenance optimization
- Simplified Field Assembly: Fully pre-commissioned unit requiring only on-site PV array assembly and external pipe connections, enabling commissioning within 3-5 days
| Parameter | Specification |
|---|---|
| Model | FRO-CSolar-100 |
| RO Permeate Flow Rate | 100 m³/day (4.2 m³/h, 26,400 GPD) |
| RO Recovery Rate | 65~75% |
| Feed Water TDS | ≤ 3,000 ppm |
| Nominal Salt Rejection | ≥ 99.0% |
| RO Membranes | 16 * DOW BW30-8040 Low-Energy Elements |
| RO Operating Pressure | 8~14 bar |
| Solar PV Array | 50 kWp (125 * 400W Monocrystalline Modules) |
| Battery Storage | 100 kWh LiFePO4 (Lithium Iron Phosphate) |
| Backup Generator | 80 kVA Diesel, 500L Belly Tank, Sound-Attenuated |
| Daily Solar Fraction (Typical) | 70~85% (Tropical/Subtropical) / 50~65% (Temperate) |
| Battery Autonomy (Full Load) | 12~14 hours |
| RO Power Draw | 22 kW (Average at Full Flow) |
| Container Type | 40ft High Cube ISO, CSC Certified |
| Operating Weight | Approx. 15,500 kg (with Batteries and Generator) |
| Control and Monitoring | PLC + EMS Controller + 4G Cloud Dashboard |
| Climate Control | 18,000 BTU HVAC for Electronics and Battery Compartment |
| Pre-Treatment | Multi-Media + Activated Carbon + Anti-Scalant + 5µm CF |
The FRO-CSolar-100 is specifically engineered for regions where grid electricity is unavailable, unreliable, or prohibitively expensive. Primary deployment scenarios include remote island communities and atoll nations, off-grid eco-resorts and safari lodges, humanitarian refugee camp water supply, remote agricultural irrigation in arid regions, and mining exploration camps. The system's hybrid architecture also provides an economically attractive transitional solution for communities that will eventually be connected to grid power.
Each FRO-CSolar-100 system undergoes integrated factory testing including 48-hour continuous RO wet testing, EMS logic validation across all operating modes, battery charge/discharge cycle verification, and full SCADA communication verification. The system ships as a complete water treatment and power management unit with comprehensive documentation. Optional services include turnkey installation, operator training, and comprehensive service agreements. Warranty coverage includes 1-year for the RO system, 5-year performance warranty for LiFePO4 batteries, and 25-year linear power output warranty for PV modules.
