Veolia EDI Modules MK-3MiniH Compact High-Purity Water Solution
Product Details:
| Place of Origin: | China |
| Brand Name: | VEOLIA |
| Certification: | CE |
| Model Number: | Veolia EDI MK-3MiniHT |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiable |
| Packaging Details: | standard export packing |
| Delivery Time: | 5- 8 work days |
| Payment Terms: | T/T |
| Supply Ability: | 60000 Units per Month |
|
Detail Information |
|||
| Shipping Weight (kg): | 52 | Dimensions (cm As Width X Height X Depth): | 30 X 61 X 29 |
|---|---|---|---|
| Maximum Water Production (m3 /hr): | 1.5 | Minimum Water Production (m3 /hr): | 0.5 |
| Typical Designed Water Production (m3 /hr): | 0.5-1.5 | Recovery: | Up To 93% |
| Voltage (VDC): | 0-150 | Turbidity (NTU): | <1.0 |
| Highlight: | EDI Electrodeionization Unit, Electrodeionization Ro Edi Water Treatment, RO Continuous Electrodeionization System | ||
Product Description
The Veolia EDI Modules MK-3MiniH are compact, high-efficiency electrodeionization (EDI) systems engineered by Veolia Water Technologies, designed to produce consistent high-purity water for small to medium-scale industrial applications. As a specialized model in Veolia’s EDI lineup, these modules combine ion exchange resins, selective ion membranes, and low-voltage DC power to remove ions from pre-treated feed water (typically RO permeate), eliminating the need for chemical regeneration and reducing environmental impact. The Veolia EDI Modules MK-3MiniH stand out for their space-saving design, making them ideal for facilities with limited footprint while delivering reliable performance.
The core工艺 of Veolia EDI Modules MK-3MiniH involves electrochemical regeneration: DC power drives ions through selective membranes into a concentrate stream, while resins remain continuously regenerated—no acid or caustic chemicals required. This process ensures stable product water quality with minimal operational hassle, as it operates 24/7 without the downtime associated with traditional ion exchange systems.
Key Specifications of Veolia EDI Modules MK-3MiniH
|
Attribute |
Value |
|
Maximum Water Production |
1.5 m³/h |
|
Recovery Rate |
Up to 93% |
|
Product Water Resistivity |
15-18 MΩ·cm |
|
Operating Voltage |
0-300 V DC |
|
Operating Temperature Range |
5-45°C |
|
Feed Water Conductivity |
<50 μS/cm |
|
Dimensions (L×W×H) |
450×250×600 mm |
The Veolia EDI Modules MK-3MiniH offer distinct advantages: compact size saves installation space, chemical-free operation cuts safety risks and disposal costs, and high recovery rate minimizes water waste. They are widely used in pharmaceutical formulation, electronics manufacturing, laboratory water systems, and boiler feed water treatment. With Veolia’s global expertise in water technologies, the Veolia EDI Modules MK-3MiniH deliver a cost-effective, sustainable solution for businesses seeking reliable high-purity water without compromising on efficiency or environmental responsibility.
