DuPont™ AmberLite™ HPR650 H Mixed Bed Demineralization Applications for the Power Industry
Product Details:
| Place of Origin: | China |
| Brand Name: | Dupont |
| Certification: | ISO9001 |
| Model Number: | DuPont™ AmberLite™ HPR650 H |
| Document: | IER-AmberLite-HPR650-H-PDS-...en.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | Negotiable |
| Packaging Details: | standard export packing |
| Delivery Time: | 5- 8 work days |
| Payment Terms: | T/T |
| Supply Ability: | 60000 Units per Month |
|
Detail Information |
|||
| Product Copolymer: | Styrene-divinylbenzene | Product Matrix: | Gel |
|---|---|---|---|
| Product Type: | Strong Acid Cation | Product Functional Group: | Sulfonic Acid |
| Product Water Retention Capacity: | 46.0 – 52.0% (H⁺ Form) | Product Ionic Conversion: | H⁺ ≥ 99% |
| Product Application: | Mixed Bed Demineralization Applications For The Power Industry | ||
Product Description
Product Description
DuPont™ AmberLite™ HPR650 H Ion Exchange Resin is a premium-quality, high-capacity resin with uniform particle size, specifically designed for use in nuclear condensate polishing mixed beds where the highest resin purity and water quality are required.
This resin offers outstanding mechanical strength and excellent oxidative stability, making it ideally suited for the high flow rate demands of condensate polishing applications. Its uniform bead size and dark color are tailored to complement the smaller, less dense, gel-type AmberLite™ HPR550 OH anion exchange resin. The distinct color difference between these two resins allows for easy visual confirmation of separation after backwashing. Together, they provide exceptional separation in mixed beds, delivering superior water quality and resin purity, which has established them as a premium mixed bed pairing in the industry.
For systems requiring exceptional resistance to surface fouling, the macroporous AmberLite™ HPR9000 OH ion exchange resin is recommended as the pairing counterpart.
Recommended Resin Pairings
-
Recommended Pairings:
-
AmberLite™ HPR550 OH Ion Exchange Resin (gel)
-
AmberLite™ HPR9000 OH Ion Exchange Resin (macroporous)
-
-
Additional Options:
-
AmberLite™ HPR550 Cl Ion Exchange Resin (gel)
-
AmberLite™ HPR9000 SO₄ Ion Exchange Resin (macroporous)
-
Applications
-
Mixed bed condensate polishing in PWR nuclear power plants
-
Mixed bed condensate polishing in fossil fuel power plants
-
Mixed bed polishing in industrial demineralization systems
Historical Reference
AmberLite™ HPR650 H Ion Exchange Resin was previously sold as DOWEX MONOSPHERE™ 650C (H) Ion Exchange Resin.
Typical Properties
| Physical Properties | |
|---|---|
| Copolymer | Styrene-divinylbenzene |
| Matrix | Gel |
| Type | Strong acid cation |
| Functional Group | Sulfonic acid |
| Physical Form | Dark amber, translucent, spherical beads |
| Chemical Properties | |
|---|---|
| Ionic Form as Shipped | H⁺ |
| Total Exchange Capacity | ≥ 2.0 eq/L (H⁺ form) |
| Water Retention Capacity | 46.0 – 52.0% (H⁺ form) |
| Ionic Conversion | H⁺ ≥ 99% |
| Particle Size $ | |
|---|---|
| Particle Diameter | 650 ± 50 μm |
| Uniformity Coefficient | ≤ 1.10 |
| < 300 μm | ≤ 0.5% |
| > 850 μm | ≤ 5.0% |
| Purity (dry basis) | |
|---|---|
| Metals: | |
| - Na (Sodium) | ≤ 50 mg/kg |
| - Fe (Iron) | ≤ 50 mg/kg |
| - Cu (Copper) | ≤ 10 mg/kg |
| - Al (Aluminum) | ≤ 50 mg/kg |
| - Heavy Metals (as Pb) | ≤ 10 mg/kg |
| Stability | |
|---|---|
| Whole Uncracked Beads | ≥ 95% |
| Friability: | |
| - Average | ≥ 500 g/bead |
| - Proportion > 200 g/bead | ≥ 95% |
| Swelling (Na⁺ → H⁺) | 7% |
| Density | |
|---|---|
| Particle Density | 1.22 g/mL |
| Shipping Weight | 785 g/L |
$ For additional particle size information, please refer to the Particle Size Distribution Cross Reference Chart (Form No. 45-D00954-en).
Temperature Range (H⁺ form): 5 – 150°C (41 – 302°F)
pH Range (Stable): 0 – 14
For further details regarding recommended minimum bed depth, operating conditions, and regeneration procedures for mixed beds (Form No. 45-D01127-en) or separate beds (Form No. 45-D01131-en) in water treatment, please refer to our Technical Facts documents.
