DuPont AmberLite IRA402 Cl Ion Exchange Resin 1.07 g/mL for Demineralization
Product Details:
| Place of Origin: | China |
| Brand Name: | Dupont |
| Certification: | ISO9001 |
| Model Number: | DuPont™AmberLite™ IRA402 Cl |
| Document: | IER-AmberLite-IRA402-Cl-PDS...en.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | Negotiable |
| Packaging Details: | standard export packing |
| Delivery Time: | 5- 8 work days |
| Payment Terms: | T/T |
| Supply Ability: | 60000 Units per Month |
|
Detail Information |
|||
| Whole Uncracked Beads: | ≥ 90% | Swelling (Cl⁻ → OH⁻): | ≤ 20% |
|---|---|---|---|
| Particle Density: | 1.07 G/mL | This Model Primary Applications: | Industrial Demineralization Applications |
| Temperature Range: | OH⁻ Form: 5 – 60°C (41 – 140°F) † | Cl⁻ Form: | 5 – 100°C (41 – 212°F) |
| Service Cycle: | 1-14 | Stable: | 0--14 |
| Highlight: | DuPont AmberLite IRA402 resin,ion exchange resin for demineralization,water treatment resin with warranty |
||
Product Description
DuPont™ AmberLite™ IRA402 Cl Ion Exchange Resin For Industrial Demineralization Applications
DuPont™ AmberLite™ IRA402 Cl is a gaussian, gel-type, strong base anion exchange resin (Type I) designed for industrial demineralization applications. With a long-established track record of reliable performance, this resin offers an excellent balance of high capacity, mechanical strength, and silica selectivity.
Applications
- Demineralization
- Ideal for treating water with a high percentage of silica
- Effective for removing strong and weak acids and achieving low silica leakage
Compatible System Designs
- Co-current regeneration systems
Typical Properties
Physical Properties
| Property | Specification |
|---|---|
| Copolymer | Styrene-divinylbenzene |
| Matrix | Gel |
| Type | Strong base anion, Type I |
| Functional Group | Trimethylammonium |
| Physical Form | Amber translucent spherical beads |
Chemical Properties
| Property | Specification |
|---|---|
| Ionic Form (as shipped) | Cl⁻ |
| Total Exchange Capacity | ≥ 1.20 eq/L (Cl⁻ form) |
| Water Retention Capacity | 49.0 - 59.0% (Cl⁻ form) |
Particle Size Distribution
| Parameter | Specification |
|---|---|
| Uniformity Coefficient | ≤ 1.80 |
| < 300 μm | ≤ 1.0% |
| > 1180 μm | ≤ 5.0% |
For additional particle size information, refer to Document No. 45-D00954-en.
Stability
- Whole Uncracked Beads: ≥ 90%
- Swelling (Cl⁻ → OH⁻): ≤ 20%
Density
- Particle Density: 1.07 g/mL
- Shipping Weight: 670 g/L
Operating Conditions
- Temperature Range:
- OH⁻ form: 5 - 60°C (41 - 140°F) †
- Cl⁻ form: 5 - 100°C (41 - 212°F)
- pH Range:
- Service Cycle: 1 - 14
- Stable: 0 - 14
† Operating at elevated temperatures (e.g., >60-70°C) may impact resin life. Consult DuPont technical representatives for details.
Hydraulic Characteristics
- Backwash Expansion: Estimated bed expansion as a function of backwash flow rate and temperature is shown in Figure 1.
- Pressure Drop: Estimated pressure drop as a function of service flow rate and temperature is shown in Figure 2 (valid for clean water and well-classified beds at service run start).
(Note: Refer to original document for graphical data.)
Safety & Compliance
Warning: Strong oxidizing agents (e.g., nitric acid) may degrade the resin or cause violent reactions. Consult experts before use.
Users should review safety data sheets (SDS) and ensure compliance with local regulations.
