AmberTec UP550 OH Ion Exchange Resin 590μm for Water Treatment
Product Details:
| Place of Origin: | China |
| Brand Name: | Dupont |
| Certification: | ISO9001 |
| Model Number: | Dupont AmberTec™ UP550 OH |
| Document: | DuPont-AmberTec-UP550-OH-Io...-L.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | Negotiable |
| Packaging Details: | standard export packing |
| Delivery Time: | 5- 8 work days |
| Payment Terms: | T/T |
| Supply Ability: | 60000 Units per Month |
|
Detail Information |
|||
| Copolymer: | Styrene-divinylbenzene | Type: | Strong Base Anion |
|---|---|---|---|
| Functional Group: | Trimethylammonium | Primary Applications: | Water Treatment In The Nuclear Power Industry |
| Physical Form: | White To Yellow Translucent Spherical Beads | Ionic Form As Shipped: | OH⁻ |
| Highlight: | AmberTec UP550 ion exchange resin,water treatment resin 590μm,OH ion exchange resin |
||
Product Description
AmberTec™ UP550 OH is a premium-quality, high-capacity, uniform particle size strong base anion exchange resin designed for regenerable mixed beds in applications requiring the highest resin purity and water quality, particularly in the semiconductor industry.
Its small average particle size ensures exceptional bead integrity and rapid exchange kinetics, making it ideal for high-flow mixed bed systems. The resin's light color and uniform size are tailored to complement the larger, denser AmberTec™ UP650 H cation resin, enabling easy visual confirmation of separation after backwash. Together, this resin pairing offers outstanding separation performance, excellent water quality, and high purity, establishing it as a premium choice in the semiconductor industry.
- AmberTec™ UP650 H Ion Exchange Resin (gel)
- Regenerable single beds after reverse osmosis
- Regenerable primary mixed beds after reverse osmosis
- Regenerable polishing mixed beds
- Non-regenerable polishing mixed beds
Previously sold as DOWEX MONOSPHERE™ 550A UPW (OH) Ion Exchange Resin.
| Property | Specification |
|---|---|
| Copolymer | Styrene-divinylbenzene |
| Matrix | Gel |
| Type | Strong base anion |
| Functional Group | Trimethylammonium |
| Physical Form | White to yellow translucent spherical beads |
| Property | Specification |
|---|---|
| Ionic Form as Shipped | OH⁻ |
| Total Exchange Capacity | ≥ 1.1 eq/L (OH⁻ form) |
| Water Retention Capacity | 55.0 - 65.0% (OH⁻ form) |
| Ionic Conversion (OH⁻) | ≥ 95% |
| Ionic Conversion (CO₃ ²⁻) | ≤ 5% |
| Ionic Conversion (Cl⁻) | ≤ 0.5% |
| Parameter | Specification |
|---|---|
| Particle Diameter | 590 ± 50 μm |
| Uniformity Coefficient | ≤ 1.10 |
| < 300 μm | ≤ 0.5% |
| > 850 μm | ≤ 1.0% |
| Element | Specification |
|---|---|
| Na | ≤ 25 mg/kg |
| Fe | ≤ 25 mg/kg |
| Cu | ≤ 15 mg/kg |
| Al | ≤ 15 mg/kg |
| Parameter | Specification |
|---|---|
| Whole Uncracked Beads | ≥ 95% |
| Friability (Average) | ≥ 350 g/bead |
| > 200 g/bead | ≥ 95% |
- Shipping Weight: 660 g/L
- Temperature Range: 5 - 60°C (41 - 140°F)
- pH Range (Stable): 0 - 14
- Backwash Expansion: Estimated bed expansion as a function of backwash flow rate and temperature is provided in Figure 1 (refer to original document).
- Pressure Drop: Estimated pressure drop as a function of service flow rate and temperature is shown in Figure 2.
- Rinse Performance: Typical single-bed rinse-down curves for conductivity and TOC (to ΔTOC = 2 ppb) as a function of rinse volume are shown in Figure 3.
- Users should review manufacturing processes and applications from health, safety, and environmental perspectives.
- Refer to the latest Safety Data Sheet (SDS) before use and ensure compliance with local regulations.
