Product Details:

Place of Origin: China
Brand Name: DuPont
Certification: CE
Model Number: XP 51 IG(previously SFP-2860XP)
Document: UF-IntegraTec-XP51-IG-en.pdf

Payment & Shipping Terms:

Minimum Order Quantity: 1 pc
Price: Negotiable
Packaging Details: standard export packing
Delivery Time: 5- 8 work days
Supply Ability: 60000 Units per Month
Get Best Price Contact Now

Detail Information

Mode Of Filtration: Out-In Pressurized XP 51 IG Membrane Type: Hollow Fiber
XP 51 IG Membrane Material: PVDF (Polyvinylidene Fluoride XP 51 IG Membrane Pore Size: Approx. 0.03 µm
XP 51 IG Operating Process: Dead-end Other Wetted Module Components: Polyurethane, Polyethylene, And Polyamide
Active Membrane Area: 51 M² Shipping Weight: 60 Kg
Weight Empty: 48 Kg Weight Filled: 83 Kg
Application Of The Product: Wastewater Treatment Advantages: • Municipal Drinking Water. • Industrial Utility Water. • Industrial Wastewater Reuse. • Municipal Wastewater Filtration. • RO Pretreatment

Product Description

DuPont™ XP 51 IG PVDF UF Module – High Recovery Rate For Industrial Water Treatment

The DuPont™ XP 51 IG is a premium polyvinylidene fluoride (PVDF) hollow fiber ultrafiltration (UF) membrane, engineered for superior performance in demanding water treatment applications. Designed with high chemical resistance and robust durability, this membrane delivers reliable filtration efficiency for industrial, municipal, and process water systems.

Key Features:

  • Advanced PVDF Hollow Fiber Technology – Ensures high mechanical strength and long-term stability.

  • High Chlorine and Chemical Resistance – Withstands aggressive cleaning regimes, reducing fouling and maintenance.

  • Outer-Pressure (Out-to-In) Filtration – Handles high turbidity and suspended solids with minimal pretreatment.

  • Precision Filtration (0.03μm Pore Size) – Effectively removes bacteria, viruses, and colloidal particles for superior water quality.

  • Optimized for Large-Scale Systems – Available in standard 8-inch diameter configurations for high-capacity applications.

Applications:

  • Industrial Wastewater Treatment & Reuse (e.g., chemical, textile, mining)

  • Drinking Water Purification (removal of pathogens and turbidity)

  • RO/NF Pretreatment (seawater desalination, boiler feed water)

  • Municipal Water & Wastewater Treatment (tertiary filtration for reuse)

Technical Specifications:

  • Membrane Material: Hydrophilic PVDF

  • Filtration Mode: Dead-end / Crossflow (Outer-Pressure)

  • Operating pH Range: Broad tolerance for acidic and alkaline conditions

  • Temperature Range: Suitable for cold to moderate-temperature operations

  • Certifications: Compliant with industry standards for water treatment

Why Choose DuPont™ XP 51 IG?

The XP 51 IG combines high flux performance, durability, and ease of maintenance, making it an ideal choice for harsh water treatment environments. Its PVDF-based construction ensures resistance to fouling and chemical degradation, while its optimized design maximizes system efficiency and lifespan.

DuPont™ XP 51 IG PVDF UF Module – High Recovery Rate For Industrial Water Treatment 0


Product Specifications

Membrane area Module volume Weight
(empty/ water filled)
Model Type / m2 ft2 Liters Gallons Kg/lbs Kg/lbs
 XP 51 IG  Industrial
51 549 35 9.3 48/83 106/183
XP 51 NSF/ANSI 61 and 419
51 549 35 9.3 48/83 106/183

Figure 1:  XP 51/ XP 51 IG (8-inch diameter)


DuPont™ XP 51 IG PVDF UF Module – High Recovery Rate For Industrial Water Treatment 1

Properties
Length

Diameter Width
Units L L1 L2 L3 D W1 W2
SI (mm) 1860 1500 1630 1820 225 180 342

Operating Parameters


SI units US units
Filtrate Flux @ 25ºC 40-110 l/m2/ hr 24-65 gfd
Flow range 2.0 8.5 m3/hr 8.8 37.4 gpm
Temperature 1-40ºC 34-104ºF
Max. inlet module pressure (@ 20ºC) 6.25 bar 90.65 psi
Max. operating TMP 2.1 bar 30.5 psi
Max operating air scour flow 12 nm3/hr 7.1 scfm
Max backwash pressure 2.5 bar 36 psi
Operating pH 2- 11
NaOCl (max.) 2,000 mg/L
Particle size (max.) 300 µm
Flow configuration Outside in,dead end flow
Expected filtrate turbidity ≤0.1 NTU
Expected filtrate SDI ≤2.5
/
/


The difference between 28XX and 26XX

DuPont™ XP 51 IG PVDF UF Module – High Recovery Rate For Industrial Water Treatment 2

MODULE INSTALLATION

DuPont™ XP 51 IG PVDF UF Module – High Recovery Rate For Industrial Water Treatment 3

DuPont™ XP 51 IG PVDF UF Module – High Recovery Rate For Industrial Water Treatment 4


DuPont™ XP 51 IG PVDF UF Module – High Recovery Rate For Industrial Water Treatment 5

DuPont™ XP 51 IG PVDF UF Module – High Recovery Rate For Industrial Water Treatment 6

For application cases, please click:https://www.fgwater.com/Industries/


For detailed parameters, please visit:

DuPont™ XP 51 IG PVDF UF Module – High Recovery Rate For Industrial Water Treatment 7 DuPont™ XP 51 IG PVDF UF Module – High Recovery Rate For Industrial Water Treatment 8
