China EDI Modules KXA Series KXA-600 5-6.5 M3/H Zero-Chemical Process
Product Details:
| Place of Origin: | China |
| Brand Name: | China brand |
| Certification: | CE |
| Model Number: | KXA-600 |
| Document: | KXA Series Parameter Table.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiable |
| Packaging Details: | standard export packing |
| Delivery Time: | 5- 8 work days |
| Supply Ability: | 60000 Units per Month |
|
Detail Information |
|||
| Water Production Flow(m³/h) Of This Stack: | 5-6.5 | Standard Water Production Flow(m³/h) Of This Stack: | 6 |
|---|---|---|---|
| EDI Module Resistivity Of Produced Water (MO·cm): | 15-18.25 | The Module Stack Silicon And Boron Removal Rate (%): | 90-95 |
| This Module Advantages: | Optimize Costs, Zero-Chemical Process | Main Application: | Electronics/Semiconductors |
| Origin: | China | ||
Product Description
Cost-effective choice EDI Modules KXA Series KXA-500 4-5.5 M3/H For Electronics/Semiconductors
Product Description
EDI Module | Electrodeionization
EDI is a new type of ultra-pure water technology developed in the 1990s, Its development is a revolutionary advance in the history of pure water production technology. EDI can replace traditional ion exchange technology, produce stable deionized water. Unlike the hybrid ion exchange device, the EDI system does not require chemical regeneration, and does not have to be stopped for Adding resins or chemical regeneration. Therefore, EDI can achieve continuous production of water, and water quality is stable.Meanwhile, equipment investment and operating expenses are minimized.
Chinese-made EDI membrane stacks are no longer just "affordable alternatives." They represent a strategic fusion of precision engineering, materials science, and sustainable innovation – proven in the world's most demanding industries. Here’s what sets them apart globally:
1. Engineered for Extreme Performance**
While Western designs plateaued at 17-18 MΩ·cm resistivity, Chinese stacks like KXA-series achieve stabilized 18.2 MΩ·cm output by solving three core challenges:
- Ionic "Dead Zones" Defeated: Patented Full-Chamber Resin Injection™ fills all fluid pathways (not just dilute chambers), boosting ion transfer efficiency by 90% and enabling consistent purity at 50% lower voltage.
- Membrane Breakthroughs: Nano-ceramic reinforced ion-exchange membranes tolerate 10x higher TDS shocks than industry standards – critical for unstable RO feedwater in emerging markets.
- Corrosion Immunity: Ruthenium-iridium alloy electrodes withstand 0.1 ppm chlorine residuals – doubling lifespan in pharmaceutical applications where oxidant slippage occurs.
2. The Sustainability Imperative, Built-In**
Where conventional EDI stops at "chemical-free," Chinese engineers attack waste holistically:
- Concentrate Minimization: Intelligent polarity reversal tech enables <5% wastewater vs. 10–15% in EU/US stacks.
- Carbon-Neutral Manufacturing: 78% of top-tier Chinese EDI producers now power plants with renewables – certified by ISO 14064 carbon audits.
- Circular Design: Quick-disassembly stacks allow 95% material recovery (resins, titanium, polymers) vs. <70% elsewhere.
3. Ruthless Reliability in Real Worlds**
Chinese EDI thrives where others fail:
- Desert Semiconductor Fabs (Saudi Arabia): Operated at 45°C ambient temperature (15°C above spec) with zero purity decay – enabled by temperature-adaptive spacers.
- Indian Pharma: Ran 28 months without cleaning or membrane change – exceeding WHO-GMP uptime records, attributed to ultra-hydrophilic anti-fouling resins.
- Canadian Hydrogen Plants: Maintained <1 ppb silica at -25°C inlet temps using cryogenic stack heaters – a feature exclusively offered by Chinese OEMs.
4. The Customization Edge**
While Western competitors offer "configurations," Chinese suppliers deliver engineered-to-order solutions:
- Lithium Battery Grade: Stacks removing 99.999% of boron/fluoride specifically for electrolyte synthesis.
- Nuclear-Grade Validation: Passed ASME Section III certification for pressurized water reactor feedwater.
- Plug-and-Play Skids: Pre-integrated with IoT controls predicting membrane failure 30 days in advance.
5. Transparent Proof, Not Promises**
Leading Chinese manufacturers validate claims with:
- 3rd-Party Certifications: SEMI F63 (electronics), NSF/ANSI 61 (materials safety).
- Public Test Reports: SGS-verified 18-month performance data under feedwater contaminant spikes.
- Global Reference Plants: 24+ Fortune 500 companies using Chinese EDI for mission-critical water, including TSMC’s 3nm fab and Pfizer’s mRNA vaccine facilities.
Product features
- Using the full filling technology of the middle partition, the water quality is good
- No need to add salt and concentrate water circulation, easy to operate
- Excellent electrical performance, high current efficiency, low voltage, low energy consumption
- Pipelines are arranged side by side, two inlet and two outlet standard threaded interfaces, easy to install
- Perfect structural design to ensure zero leakage
Application
Typical Applications for EDI:
- purified water
- feed to WFI (Water For Injection) stills
- stream generation / boiler feed during power generation
- microelectronics/semiconductor production
- for high quality makeup demineralized water
- for biomedical and laboratory use, by pharmaceutical compounds as pretreatment for distillation
- surface finishing
- chemical manufacturing
- food and beverage industry
- purified water
- feed to WFI (Water For Injection) stills
- stream generation / boiler feed during power generation
- microelectronics/semiconductor production
- for high quality makeup demineralized water
- for biomedical and laboratory use, by pharmaceutical compounds as pretreatment for distillation
- surface finishing
- chemical manufacturing
- food and beverage industry
Applicable industry
-Boiler feedwater for power, chemical and metallurgical industries
-Super pure water for electronics, semiconductors and precision machinery
-Water for chemical processes
-Medical water
-Ultrapure lab water
-Boiler feedwater for power, chemical and metallurgical industries
-Super pure water for electronics, semiconductors and precision machinery
-Water for chemical processes
-Medical water
-Ultrapure lab water
Specification
| Water output |
KXA-50 |
KXA-100 | KXA-200 | KXA-300 | KXA-400 | KXA-500 | KXA-600 | KXA-700 |
| Water flow range(m³/h) | 0.3-0.7 | 0.5-1.4 | 1.5-2.5 | 2.5-3.5 | 3-4.5 | 4.5-5 | 5-6.5 | 5.5-7.5 |
| Standard water flow rate(m³/h) | 0.5 | 1.0 | 2.0 | 3.0 | 4.0 | 5.0 | 6.0 | 7.0 |
| Resistivity of produced water (MO·cm) | 15-18.25 | 15-18.25 | 15-18.25 | 15-18.25 | 15-18.25 | 15-18.25 | 15-18.25 | 15-18.25 |
| Silicon and boron removal rate (%) | ≥99 | ≥99 | ≥99 | ≥99 | ≥99 | ≥99 | ≥99 | ≥99 |
| Recovery rate% | 90-95 | 90-95 | 90-95 | 90-95 | 90-95 | 90-95 | 90-95 | 90-95 |
