1-5 Bar Dow™ IntegraTec™ XP 77 IG High Performance Filtration Solutions
Product Details:
| Place of Origin: | China |
| Brand Name: | DOW |
| Certification: | CE |
| Model Number: | IntegraTec™ XP 77 IG (formerly SFP 2880XP) |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiable |
| Packaging Details: | standard export packing |
| Delivery Time: | 5- 8 work days |
| Supply Ability: | 60000 Units per Month |
|
Detail Information |
|||
| Component Diameter Of This Model: | 8 Inch | Component Membrane Area Of This Model: | 77 M² |
|---|---|---|---|
| Component Material: | PVDF | Flow Range Per Module: | 2.0 – 8.5 M³/hr |
| Nominal Pore Diameter Of This Product: | 0.03 µm | Operating Pressure Of This Module: | 1-5 Bar |
| Max. Operating TMP Of This Module: | 2.1 Bar | Max Operating Air Scour Flow Of This Module: | 12 Nm3/hr |
| NaOCl (max.)of This Module: | 2,000 Mg/L | Certifications Of This Model: | ISO 9001, NSF, CE |
| Function Of The Model: | Improve The System Recovery Rate Effectively | Advantages Of The Model: | High Performance Filtration Solutions |
| Highlight: | 1-5 bar dow uf membranes,High performance filtration solutions,high Pressure dow uf membranes |
||
Product Description
Dow™ IntegraTec™ XP 77 IG - High-Flux PVDF UF Module (77m²) for ZLD/RO Pretreatment
-
The Dupont™ IntegraTec™ XP 77 IG Ultrafiltration Membrane is a high-performance filtration solution engineered for demanding industrial and municipal water treatment applications. Combining advanced material science with precision manufacturing, this membrane delivers exceptional separation efficiency, durability, and operational flexibility.
Key Features:
- Superior Filtration Performance: Designed with a optimized molecular weight cutoff (MWCO) to effectively remove suspended solids, colloids, bacteria, and macromolecules while retaining essential minerals.
- High Flux & Low Energy Consumption: Proprietary hydrophilic modification technology ensures high permeability and stable flux rates, reducing energy requirements and operational costs.
- Robust Chemical Resistance: Built to withstand harsh cleaning agents (e.g., acids, alkalis, oxidants) and challenging feedwater conditions, ensuring long-term reliability in aggressive environments.
- Extended Service Life: Reinforced membrane structure and anti-fouling surface coating minimize irreversible fouling, enhancing longevity and reducing maintenance frequency.
- Modular Flexibility: Compatible with standard ultrafiltration systems for easy integration into new or existing installations across industries.
-
Certifications & Compliance:
Meets global standards for water safety and quality, including NSF/ANSI, ISO 9001, and other industry-specific certifications.Ideal for operators prioritizing efficiency, sustainability, and cost-effectiveness, the IntegraTec™ XP 77 IG exemplifies Dupont’s innovation in separation technologies.
Applications:
- Industrial Process Water: Pre-treatment for reverse osmosis (RO), recycling, and reuse in food & beverage, pharmaceuticals, and chemical processing.
- Municipal Water Treatment: Pathogen removal, turbidity reduction, and potable water production.
- Wastewater Reclamation: Advanced treatment for discharge compliance or reuse in agriculture/industrial cooling.
Product Specifications
Figure 1: SFP and SFD 2880XP (8-inch diameter)
Operating Parameters
The difference between 28XX and 26XX
MODULE INSTALLATION
