Veolia Electrodeionization EDI Stack Modules MK-7 Suez EDI Stacks Conductivity < 62 µs/cm
Product Details:
| Place of Origin: | China |
| Brand Name: | VEOLIA |
| Certification: | CE |
| Model Number: | E-Cell MK-7 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiable |
| Packaging Details: | standard export packing |
| Delivery Time: | 5- 8 work days |
| Supply Ability: | 60000 Units per Month |
|
Detail Information |
|||
| Data Validation: | Built-in Validation Rules And Custom Validation Options | External Size: | 230*381*110mm |
|---|---|---|---|
| Data Transformation: | Flexible Data Transformation Capabilities | Compatibility: | Compatible With Various EDI Systems |
| Manufacturer: | Various Manufacturers | Payment: | T/T,L/C,Western Union |
| Maximum Voltage: | 240V | Paint Finish: | Epoxy Polyester Coating |
| Product Developer: | IBM | Data Communication: | Secure Data Transmission Through FTP, AS2, SFTP, HTTP/S, And More |
| Boron: | As Low As 0.08 Ppb | Customization Options: | Yes |
| Boron Removal: | > 95% | Lock: | Available On Request |
| Type: | Advertising Lighting Balloon | ||
| Highlight: | edi water electrodeionization system,electrodeionization edi water purification system,edi electrodeionization water purification system |
||
Product Description
Veolia Electrodeionization (EDI) Stack Modules MK-7 Suez EDI Stacks Conductivity < 62 µs/cm
The Veolia MK-7 EDI Stack Modules are designed to provide high-purity water for applications where water quality is critical, such as pharmaceuticals, laboratories, and water for injection (WFI). The MK-7 model ensures continuous, chemical-free deionization, offering a sustainable and reliable solution for ultra-pure water needs.
Key Features:
Specifications:
Applications:
For more information or to request a quote, please contact our sales team.
The following figure shows GE, Suez and Veolia from left to right (all the same product: MK-7 EDI Stack).
Notes:
1. Actual performance may vary depending on site conditions. Reference Winflows projection software to verify expected product water quality as well as the resistivity, sodium, and silica performance guarantees that are offered for the design conditions. To obtain boron or other guarantees, contact Veolia.
2. Inlet pressure is determined by the downstream pressure requirements for the product and concentrate streams, the choice of counter-current or co-current operation, and stack pressure drop.
3. At nominal flow and 25°C. Reference Winflows projection software to verify for design conditions.
4. Reference the Winflows projection software and the E-Cell Stack Owner’s Manual to verify feed water specifications for the design conditions.
5. TEA (ppm as CaCO3) - Total Exchangeable Anion, this represents the concentration of all of the anions present in the feed water including contributions from OH-, CO2 and SiO2. Winflows must be used to confirm the feed water TEA is acceptable at the specific applications’ operating conditions. Table value is at minimum flow and maximum temperature.
6. 1.0 ppm as CaCO3 feed water hardness limit applies to standard counter-current flow operation only. Allowable feed water hardness decreases to 0.1 ppm as CaCO3 in co-current flow operation.
7. Allowable silica limit decreases above 5 m3/h flow. Allowable silica limit decreases to 0.5 ppm with feedwater hardness above 0.5 ppm as CaCO3.
8. The boron feed level is limited to 0.3 ppm as B whenever there is a silica guarantee requirement or resistivity guarantee requirement above 10 MOhm-cm, as higher boron levels could impact performance. Without these requirements the limit is 1.0 ppm boron.
9. Reverse Osmosis (RO) or equivalent feed water: RO provides EDI feed water that is substantially free of particulate matter, colloidal material and high molecular weight organic substances, which can foul ion exchange media. RO permeate quality is specified since EDI stacks contain packed beds of ion exchange medium that cannot be backwashed/fluidized to remove particulate matter. Systems with an open system between a RO system (or other source) and E-Cell (ex. tank, decarbonator) must be fitted with filters immediately preceding the E-Cell, to protect the E-Cell against contamination with particulate matter. Generally, a 5 µm absolute or 1 µm nominal filter will be acceptable.
10. APHA - color standard/scale named for the American Public Health Association and defined by ASTM D1209.
For more models, please click: https://www.fgwater.com/Veolia-Electrodeionization-EDI-Stack-Module/389.html
E-Cell EDI Technology Performance Examples
E-Cell EDI technology has been successfully applied in various industries such as power, petroleum, chemical, steel, pharmaceutical, and electronics.
For application cases, please click:https://www.fgwater.com/Industries/
