3.5-5.5m3/H EDI Stacks MK-5T For Electrodeionization Pure Water Production
Product Details:
| Place of Origin: | China |
| Brand Name: | China brand |
| Certification: | CE |
| Model Number: | MK-5T |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiable |
| Packaging Details: | standard export packing |
| Delivery Time: | 5- 8 work days |
| Supply Ability: | 60000 Units per Month |
|
Detail Information |
|||
| Water Flow Range (m³/h) Of Stacks: | 3.5-5.5 | Standard Water Flow Rate (m³/h) Of Stacks: | 5.0 |
|---|---|---|---|
| Resistivity Of Produced Water (MΩ Cm) Of Stacks: | >15 | Silicon And Base Removal Rate (%) Of Stacks: | ≥99 |
| Fresh Water Inlet Pressure(Din、bar): | 1-5 | Fresh Water Outlet Pressure(Cin、bar): | 0.5-1.0 Lower Than Din End |
| Operating Voltage(VDC): | 80-160 | Operating Current(A): | 2-5 |
| Advantages: | Perfect Structural Design,Easy To Operate | Application: | Electrodeionization Pure Water Production |
| Highlight: | Electrodeionization EDI Stacks,5.5m3/H EDI Stacks,Electrodeionization Pure Water Production EDI Stacks |
||
Product Description
2.0-3.5m3/H China EDI Stacks MK-5T For Electrodeionization Pure Water Production
Product Description
EDI Module | Electrodeionization
EDI is a new type of ultra-pure water technology developed in the 1990s, Its development is a revolutionary advance in the history of pure water production technology. EDI can replace traditional ion exchange technology, produce stable deionized water. Unlike the hybrid ion exchange device, the EDI system does not require chemical regeneration, and does not have to be stopped for Adding resins or chemical regeneration. Therefore, EDI can achieve continuous production of water, and water quality is stable.Meanwhile, equipment investment and operating expenses are minimized.
EDI (electrodeionization) technology realizes the perfect combination of ion exchange resin and electrodialysis technology. Through the action of electric field force, ions in water are directed to migrate and pass through the resin layer. This process not only removes most of the salt in the water, but also avoids the tedious steps of resin regeneration in the traditional ion exchange process, greatly improving the operating efficiency of the equipment. . The effluent quality of EDI technology is extremely stable. Due to the dual effects of the electric field and the resin layer, the ions in the water are effectively removed, and the effluent quality can be maintained at a high level for a long time, which is undoubtedly a huge benefit for industrial production and drinking water treatment that require high-precision water quality. Advantages.
Application of EDI Technology
Semiconductor industry: In the semiconductor production process, the requirements for water quality are extremely high, and any tiny impurities may have a serious impact on product quality. EDI technology can provide high-quality ultrapure water to meet the needs of semiconductor production.
Electronics industry: During the manufacturing and assembly of electronic components, a large amount of ultrapure water is required for cleaning and soaking. EDI (electrodeionization) technology can provide stable and reliable ultrapure water to improve the quality and performance of electronic products.
Pharmaceutical industry: In the production process of medicines, ultrapure water is used to prepare various medicines and solvents. EDI technology can ensure the purity of ultrapure water, thereby improving the quality and safety of medicines.
Laboratory research: In scientific research and laboratories, ultrapure water is widely used in various chemical and biological experiments. EDI technology provides laboratories with high-quality ultrapure water, improving the accuracy and reliability of experimental results.
In summary, EDI (electrodeionization) technology is gradually becoming the mainstream technology in the field of ultrapure water preparation with its excellent performance, wide application potential and environmental protection and energy-saving characteristics, leading the water treatment industry to a more efficient and green direction of development. With the continuous advancement and innovation of technology, EDI technology will play an irreplaceable role in more fields and contribute to the sustainable development of human society.
Product features
- Using the full filling technology of the middle partition, the water quality is good
- No need to add salt and concentrate water circulation, easy to operate
- Excellent electrical performance, high current efficiency, low voltage, low energy consumption
- Pipelines are arranged side by side, two inlet and two outlet standard threaded interfaces, easy to install
- Perfect structural design to ensure zero leakage
Application
Typical Applications for EDI:
- purified water
- feed to WFI (Water For Injection) stills
- stream generation / boiler feed during power generation
- microelectronics/semiconductor production
- for high quality makeup demineralized water
- for biomedical and laboratory use, by pharmaceutical compounds as pretreatment for distillation
- surface finishing
- chemical manufacturing
- food and beverage industry
- purified water
- feed to WFI (Water For Injection) stills
- stream generation / boiler feed during power generation
- microelectronics/semiconductor production
- for high quality makeup demineralized water
- for biomedical and laboratory use, by pharmaceutical compounds as pretreatment for distillation
- surface finishing
- chemical manufacturing
- food and beverage industry
Applicable industry
-Boiler feedwater for power, chemical and metallurgical industries
-Super pure water for electronics, semiconductors and precision machinery
-Water for chemical processes
-Medical water
-Ultrapure lab water
-Boiler feedwater for power, chemical and metallurgical industries
-Super pure water for electronics, semiconductors and precision machinery
-Water for chemical processes
-Medical water
-Ultrapure lab water
Specification
| MK- Series water inlet requirements | ||||
| Water inlet requirements | MK Series | Water output | MK-3T | MK-5T |
| Temperature range (℃) | 15-35(Top 25) | Water flow range (m³/h) | 2.0-3.5 | 3.5-5.5 |
| Influent PH | 6.5-9.0 | Standard water flow rate (m³/h) | 3.0 | 5.0 |
| Influent conductivity (us/cm) | 1-10(Optimal<5) | Resistivity of produced water (MΩ cm) | >15 | >15 |
| Total carbon dioxide (ppm) | <3(Optimal<2) | Silicon and base removal rate (%) | ≥99 | ≥99 |
| Total hardness (ppm) | <1 | Operation parameters | MK-3T | MK-5T |
| Silica ·Active Silicon(ppm) | ≤0.5(Optimal≤0.2) | Fresh water inlet pressure(Din,bar) | 1-5 | 1-5 |
| Total organic carbon (ppm) | ≤0.5 | Fresh water outlet pressure(Cin,bar) | 0.5-1.0 lower than Din end | 0.5-1.0 lower than Din end |
| Residual chlorine (ppm) | ≤0.01 | Concentrated water inlet pressure(Dout,bar) | 0.5-2 | 0.5-2 |
| Ionic metal (Fe/Mn.ppm) | 60.01 | Concentrated water outlet pressure(Cout,bar) | 0.5-1.0 lower than Din end | 0.5-1.0 lower than Din end |
| Turbidity (NTU) | <1 | Operating voltage(VDC) | 60-120 | 80-160 |
| grease | Not detected | Operating current(A) | 2-5 | 2-5 |
| Influent particles(um) | ≤1.0(Optimal≤0.5) | Recovery rate(%) | 85-90 | 85-90 |
| Oxidants | Not detected | |||
