316L Polymer Preparation Unit

316L Polymer Preparation Unit

Product Details:

Place of Origin: China
Brand Name: Fenigal/OEM
Certification: CE/NSF etc.
Model Number: CDS-9

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Export Wood Crate/Carton or Naked wrapped by film
Delivery Time: 15~30 days
Payment Terms: T/T, Western Union, Paypal etc.
Supply Ability: 200 set per month
Get Best Price Contact Now

Detail Information

Technology: Chemical Disinfection Design: Skid Mount
Water Temp.: 5~35˚C Application: Chemical Dosing
Water Flowrate: 500~10000 L/H Voltage: 380V,415V,220V,can Be Customized
Control: Electronic,Manual/PLC
High Light:

316L polymer preparation unit


prominent polymer preparation unit


10000L/h polymer dosing system

Product Description

316L Polymer Preparation Unit

Polymer Preparation Units PAM/PAC Tanks available in PE, 316L/304L S.S 200-10000L/hr

Automatic polymer dosing system is a range of simple and flexible as well as economic and efficient preparation systems for polymers. After forming small flocs in the coagulation step (see coagulation), flocculant is dosed in order to create bigger and more stable flocs.


The flocculant is often called polymer or poly-electrolyte. Flocculant poly-electrolyte must be prepared from a powder polymer or a fluid concentrated polymer. Polymer is a product that must be well mixed with water to prevent clot formation. After mixing with water a certain maturation time is necessary to "unfold" the polymer chain. Flocculants needs to "mature" about 30 to 60 minutes before it can be dosed. Matured polymer is a sticky liquid. For larger installations we recommend automatic polymer dosing systems for both powder and liquid polymer applications. An automatic polymer dosing systems consists mostly of three compartments with a dosing screw and a powder storage. In the first area the powder is mixed with water. The ratio water powder can be set-up perfectly. The second area is a maturation tank with stirrer .From the third area the matured polymer is pumped into the flocculator. A level probe mounted in an acrylic holder controls the make-up station. The dosing screw at the bottom of the powder storage is provided with a heating element to prevent condensation. In a polymer make up station of liquid polymer, the entire powder buffer and dosing screw is replaced by a polymer dosing pump.


316L Polymer Preparation Unit 0

316L Polymer Preparation Unit 1

Tank volume (L) Influent volume Aging Time Piping Connections() Physical Dimensions(mm) Weight
(m3/h) (h) Inlet Dosing Vent Overflow L/L1 W/W1 H (KW)
PT200 200 350 0.12-0.6 1.0-1.5 DN20 DN20 DN20 DN32 940/860 470/520 1450 250 0.54
PT430 430 750 0.3-1.5 1.0-1.5 DN25 DN25 DN25 DN32 1370/1290 680/730 1450 350 0.92
PT958 958 1580 0.6-3 1.0-1.5 DN25 DN25 DN25 DN40 1800/1720 900/950 1620 480 1.3
PT1340 1340 2200 0.8-4 1.0-1.5 DN32 DN32 DN25 DN40 2130/2050 1070/1120 1620 560 1.7
PT2660 2660 4050 1.6-8 1.0-1.5 DN40 DN40 DN40 DN50 2450/2370 1220/1270 2000 790 2.4
PT4165 4165 6170 2.4-12 1.0-1.5 DN40 DN40 DN40 DN65 2780/2700 1390/1440 2250 1050 3.2
PT6660 6660 9610 4.2-20 1.0-1.5 DN50 DN50 DN40 DN65 3100/3020 1550/1600 2650 1200 4.8
PT10940 10940 15780 6-30 1.0-1.5 DN65 DN65 DN50 DN80 3970/3890 1990/2040 2650 1450
