AmberLite IRN160 H/OH Nuclear-Grade Resin 525μm for Water Treatment
Product Details:
| Place of Origin: | China |
| Brand Name: | Purolite™ |
| Certification: | ISO9001 |
| Model Number: | MB400 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | Negotiable |
| Packaging Details: | standard export packing |
| Delivery Time: | 5- 8 work days |
| Payment Terms: | T/T |
| Supply Ability: | 60000 Units per Month |
|
Detail Information |
|||
| Appearance: | Spherical Beads | Moisture Content (max.): | 65% |
|---|---|---|---|
| Particle Size Distribution: | 300 – 1200 μm | < 300 μm (max.): | 1% |
| IRN97 H Cation Resin Particle Diameter: | 525 ± 50 μm | Uniformity Coefficient (max.): | 1.7 |
| Packaging Density (approx.): | 705 – 740 G/L (44.1 – 46.2 Lb/ft³) | Application: | Desalination - Mixed Bed |
| Highlight: | AmberLite IRN160 nuclear-grade resin,water treatment resin 525μm,H/OH ion exchange resin |
||
Product Description
AmberLite™ IRN160 H/OH is a nuclear-grade, uniform particle size mixed bed ion exchange resin specifically designed for water treatment applications in the nuclear power industry. It is a stoichiometric 1:1 equivalent mixture of AmberLite™ IRN97 H (cation) and AmberLite™ IRN78 OH (anion) resins, optimized to minimize separation during installation and transfer due to the smaller cation resin particle size. This resin ensures highest purity and stability, reducing ionic and non-ionic contamination, enabling reliable and safe production while minimizing equipment maintenance and unscheduled outages.
- Minimal separation during installation/transfer
- Faster kinetics and higher exchange capacity
- Excellent chemical stability and resistance to bead fracture
- Reduced radioactive waste generation
- Primary water treatment: Primary coolant blowdown, pre-outage cleanup
- Fuel pool purification
- Rad waste treatment and decontamination: Removal of radioactive cations (e.g., 137Cs137Cs, cobalt isotopes), anionic radioactive material, and silver
- PWR steam generation blowdown (APG)
- BWR condensate polishing
Historical Reference:
Previously sold as AmberLite™ IRN160 Ion Exchange Resin.
| Property | IRN97 H Cation Resin | IRN78 OH Anion Resin |
|---|---|---|
| Copolymer | Styrene-divinylbenzene | Styrene-divinylbenzene |
| Matrix | Gel | Gel |
| Type | Strong acid cation | Strong base anion |
| Functional Group | Sulfonic acid | Trimethylammonium |
| Physical Form | Amber translucent spherical beads | Amber translucent spherical beads |
| Ionic Form as Shipped | H⁺ | OH⁻ |
| Total Exchange Capacity | ≥ 2.10 eq/L (H⁺ form) | ≥ 1.20 eq/L (OH⁻ form) |
| Water Retention Capacity | 45.0 - 51.0% (H⁺ form) | 54.0 - 60.0% (OH⁻ form) |
| Ionic Conversion (H⁺) | ≥ 99% | -- |
| Ionic Conversion (OH⁻) | -- | ≥ 95% |
| Ionic Conversion (CO₃ ²⁻) | -- | ≤ 5% |
| Ionic Conversion (Cl⁻) | -- | ≤ 0.05% |
| Ionic Conversion (SO₄ ²⁻) | -- | ≤ 0.1% |
| Parameter | IRN97 H Cation Resin | IRN78 OH Anion Resin |
|---|---|---|
| Particle Diameter | 525 ± 50 μm | 630 ± 50 μm |
| Uniformity Coefficient | ≤ 1.20 | ≤ 1.10 |
| < 300 μm | ≤ 0.2% | ≤ 0.2% |
| < 425 μm | -- | ≤ 0.5% |
| > 850 μm | ≤ 5.0% | -- |
| > 1180 μm | -- | ≤ 2.0% |
For additional particle size information, refer to Document No.: 45-D00954-en.
| Element | IRN97 H Cation Resin | IRN78 OH Anion Resin |
|---|---|---|
| Na | ≤ 40 mg/kg | ≤ 20 mg/kg |
| K | ≤ 20 mg/kg | ≤ 20 mg/kg |
| Fe | ≤ 20 mg/kg | ≤ 20 mg/kg |
| Cu | ≤ 5 mg/kg | ≤ 5 mg/kg |
| Co | ≤ 5 mg/kg | ≤ 5 mg/kg |
| Ca | ≤ 10 mg/kg | ≤ 10 mg/kg |
| Mg | ≤ 10 mg/kg | ≤ 10 mg/kg |
| Al | ≤ 10 mg/kg | ≤ 10 mg/kg |
| Hg | ≤ 20 mg/kg | ≤ 20 mg/kg |
| Heavy Metals (as Pb) | ≤ 10 mg/kg | ≤ 10 mg/kg |
| Cl | -- | ≤ 250 mg/kg |
| SiO₂ | -- | ≤ 10 mg/kg |
| Parameter | IRN97 H Cation Resin | IRN78 OH Anion Resin |
|---|---|---|
| Whole Uncracked Beads | ≥ 95% | ≥ 95% |
| Friability (Average) | ≥ 400 g/bead | ≥ 600 g/bead |
| > 200 g/bead | ≥ 95% | ≥ 95% |
| Solubility in Water | ≤ 0.10% | ≤ 0.10% |
- Shipping Weight: 700 g/L (for mixed bed AmberLite™ IRN160 H/OH)
- Temperature Range: 5 - 100°C (41 - 212°F)
- pH Range (Stable): 0 - 14
Pressure Drop: Estimated pressure drop as a function of service flow rate and temperature is provided in Figure 1 (refer to original document for detailed curves).
Users should review manufacturing processes and applications from health, safety, and environmental perspectives.
Refer to the latest Safety Data Sheet (SDS) before use and ensure compliance with local regulations.
