Product Details:

Place of Origin: China
Brand Name: Fenigal
Certification: CE
Model Number: PRO-FD8080/15Ws\x

Payment & Shipping Terms:

Minimum Order Quantity: 1 pc
Price: Negotiable
Packaging Details: standard export packing
Supply Ability: 60000 Units per Month
Get Best Price Contact Now

Detail Information
Components: Pump, RO Membrane,Tanks Device Material: Stainless Steel 304 Tank, UPVC Pipe
Product Recovery Rate: 50-75% Control: Electronic,Manual/PLC
Ro Membrane: Hydranautics Or DOW,4040 Pipe Material: UPVC Water Pipes
System Installation Power: 1.7kW-380-415V, 50Hz Product Technology: Reverse Osmosis
Reverse Osmosis Membrane: Filmtec/Hydranautics Plant Permeate: 500 L/H
Main Material: Stainless Steel 304 Tank, UPVC Pipe System Installed Power: 1.7kW-380-415V, 50Hz
Prefilter Tank: 2xSS304 Tanks Product Code: SW-800-150E2
Product Control System: PLC
Highlight:

3.0kW Brackish Water Reverse Osmosis

,

1.5TPH Brackish Water Reverse Osmosis

,

SS304 Skid Brackish Water RO

Product Description

PRO-FD8080/15: High-Efficiency Solution for Brackish Water Treatment

1. Introduction to PRO-FD8080/15

The PRO-FD8080/15 emerges as a cutting-edge brackish water reverse osmosis (RO) plant engineered for industrial applications demanding reliable, high-capacity water purification. With a permeate output of 1.5TPH (9,600 GPD), this system efficiently converts brackish water with TDS ≤2,000ppm into high-purity water, catering to manufacturing, energy, commercial, and hospitality sectors. Its SS304 skid-mounted design ensures corrosion resistance, durability, and seamless installation, while the compact footprint optimizes space in industrial environments.

2. Technical Specifications and Core Features

The PRO-FD8080/15 stands out for its robust technical configuration, combining premium components with intelligent engineering:


  • Output Capacity: 1.5TPH (9,600 GPD) of purified water, ideal for mid-to-large-scale industrial needs.
  • Membrane System: Single-pass 8"x2 RO membranes, with optional upgrades to Filmtec or Hyranautics—brands renowned for high salt rejection rates (≥99%) and extended service life.
  • Power & Voltage: 3.0kW installed power, compatible with 380-415V/50Hz systems, with customizable voltage options for global markets.
  • Feed Water Requirement: Efficiently processes brackish water sources with TDS ≤2,000ppm, adapting to diverse water quality conditions.
  • Skid-Mount Design: Constructed with SS304 stainless steel, the skid ensures easy transportation, quick installation, and resistance to harsh industrial environments.

3. Advanced Treatment Process Flow

The PRO-FD8080/15 employs a streamlined multi-stage filtration sequence to guarantee optimal water quality:


  1. SF (Sand Filter): The first pretreatment stage removes suspended solids, sediments, and particulates up to 5 microns, protecting subsequent components from damage.
  2. ACF (Activated Carbon Filter): Utilizes activated carbon to adsorb organic compounds, chlorine, and odors, preventing membrane degradation and ensuring odor-free permeate.
  3. RO (Reverse Osmosis): The core stage, where thin-film composite membranes (optional Filmtec/Hyranautics) remove dissolved salts, bacteria, and dissolved solids, producing high-purity water with ≤10ppm TDS (depending on feed water).


The pretreatment system includes two FRP (Fiberglass Reinforced Plastic) tanks, enhancing sediment removal and extending membrane life. Instrumentation such as uPVC piping, flow meters, pressure gauges, and LP/HP switches enables real-time monitoring, while an IC-based control unit with a TDS indicator ensures precise water quality management.

4. Benefits for Industrial Users

  • Cost Efficiency: With a low power consumption of 3.0kW, the system minimizes operational costs. The skid-mounted design reduces installation time and maintenance expenses, while FRP tanks offer lightweight durability at a lower cost.
  • Reliability & Performance: SS304 construction and premium RO membranes ensure consistent performance even in harsh conditions, with a service life of 3-5 years (with regular maintenance).
  • Flexibility & Customization: Adaptable to different voltage requirements and feed water conditions, the system caters to diverse needs—from process water in food manufacturing to boiler feed in power plants.
  • Fast Lead Time: Backed by expert technical support, the PRO-FD8080/15 ensures rapid deployment, addressing urgent water treatment demands in time-sensitive industries.

5. Applications and Compliance

The PRO-FD8080/15 is suitable for:


  • Industrial process water in manufacturing plants (e.g., pharmaceuticals, electronics)
  • Boiler feed water and cooling tower make-up in energy facilities
  • Potable water production in commercial buildings, resorts, and remote sites
  • Water reuse systems in wastewater treatment applications


It complies with international standards for industrial water quality, ensuring permeate meets or exceeds requirements for various applications.

6. Conclusion

The PRO-FD8080/15 exemplifies the fusion of efficiency, scalability, and affordability in brackish water reverse osmosis technology. Whether addressing water scarcity in industrial zones or enhancing process efficiency, this system delivers high-purity water with minimal downtime. Its combination of robust SS304 construction, brand-name components, and fast lead times makes it a premier choice for businesses seeking sustainable, high-performance water treatment solutions.

Technical Specifications Table

Category Details
Model PRO-FD8080/15
Permeate Output 1.5TPH (9,600 GPD)
Feed Water TDS ≤2,000ppm
Membrane Type Single-pass 8"x2 RO membranes (Filmtec/Hyranautics optional)
Construction Material SS304 skid-mount frame, uPVC piping, 2x FRP pretreatment tanks
Power Supply 3.0kW, 380-415V/50Hz (custom voltages available)
Treatment Process SF-ACF-RO (Sand Filter → Activated Carbon Filter → Reverse Osmosis)
Pretreatment Tanks 2x FRP tanks (sand and carbon filtration)
Instrumentation Flow meters, pressure gauges, LP/HP switches, operational status indicators
Control System IC-based unit with TDS indicator
Lead Time Fast delivery supported by expert technical team
Applications Industrial process water, boiler feed, potable water, water reuse
