500LPH Stainless Steel Drinking Ro Water Treatment Plant For Industrial Use
Product Details:
| Place of Origin: | China |
| Brand Name: | Fenigal |
| Certification: | CE |
| Model Number: | EDI |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiable |
| Packaging Details: | standard export packing |
| Delivery Time: | 5- 8 work days |
| Supply Ability: | 60000 Units per Month |
|
Detail Information |
|||
| Machine Flow Rate: | 500LPH | Produced Resistivity Value: | 18MΩ |
|---|---|---|---|
| Pipe: | UPVC Or SS | The Core Components Of The Machine: | Pressure Vessel, Pump, PLC |
| Product Structure: | RO+EDI | Machine Weight: | Customizable |
| The Size Of Machine: | Customizable | Machine Control: | Electric Auto Control (PLC Siemens) |
| Pretreatment: | Sand Filter+carbon Filter + RO Membrane | ||
| Highlight: | 500LPH ro water treatment plant,Stainless Steel ro water treatment plant,Drinking Water Treatment industrial ro plant |
||
Product Description
500LPH Stainless Steel Drinking Water Filter System RO EDI Ultrapure Water Machine RO For Industrial Use
500lph Edi+ro Deionized Ultra Pure Water Treatment system feed water is delivered under a pressure of approximately 16 kg/cm2 through reverse osmosis membranes. Water permeates the minute pores of the membrane and is delivery as purified water. Water Treatment System For Industrial Pure Ss316 Reverse Osmosis Ro Ultra-pure Water Edi 1000LPH RO impurities in the water are concentrated in the reject stream and flushed to drain. Reverse osmosis is capable of removing 90-99% of total dissolved solids (TDS), 99% of organic, including pyrogens , and 99% of all bacteria in the feed water.
Main and basic points of this system:
1. Water source inlet: city tap water or river or well water source TDS less than 20000ppm. 2.
Capacity: Output reverse osmosis pure water is 1000-2000 liters per hour. 3.
Reverse osmosis pure water output application: daily consumption or irrigation or food manufacturing.
If your water source or capacity or output water application is different from the above, please send the following details to this supplier to suggest the most suitable quotation
1. Details of your water source (tap water, well water or river water/lake water?). If it is well water/lake water/river water, please send water quality analysis report. Such as hardness and turbidity.
2. What is the capacity of the RO system you need? (We have experience from 500 lph to 20000lph)
3. What is the output water use? (Industrial/commercial/agricultural? Drinking water?)
Features
FEED WATER SPECIFICATIONS
- Feed Water Conductivity Equivalent, including CO2
and Silica: < 40 µS/cm - Feed Water Source: RO permeate
- Temperature: 41 – 113 °F (5 – 45 °C)
- Inlet Pressure: = 100 psi (6.9 bar)
- Maximum Total Chlorine (as Cl): < 0.02 ppm
- Iron (as Fe): < 0.01 ppm
- Manganese (as Mn): < 0.01 ppm
- Sulfide (S2-): < 0.01 ppm
- pH: 4 – 11
- Total Hardness (as CaCO3): < 1.0 ppm
- Dissolved Organics (TOC as C): < 0.5 ppm
- Silica (SiO2): < 1.0 ppm
| Features: | Benefits of EDI: |
|
|
| The ideal applications for an Electro-Deionization Unit include: | ||
|
|
|
About Us
FG Water Technologies (www.fgwater.com) is now an organic part of Wuxi Fenigal Science and Technology Co. Ltd., which is a high-tech entity integrating water treatment quipment design, manufacturing, trading and shipment served for main industrial sectors.
HAFE-FG Water Technologies has focused on the research of water treatment technology, equipment development and manufacturing, testing and international shipment etc. We work with many leading large-scale or small-medium original equipment manufacturers in China High-tech Development Zones, and engaged ourselves in R&D, manufacturing, and quality testing.
Our main products include a variety of water purification and different treatment equipment, such as seawater reverse osmosis (SWRO) system, brackish water rever osmosis (BWRO), ultrafiltration (UF)system, Electrodeionization/EDI equipment, media pressure filters and ion exchanger softeners. So far, our company has become a major water treatment equipment supplier for food and beverage industry, pharmaceutical industry, chemical industry, electric power industry, urban water supply industry, municipal and industrial wastewater treatment and more industries, as well as being an exporter to more than 20 countries and regions in Asia, Europe, the Americas, Africa, etc.
OUR CLIENTS
INDUSTRIES SERVED
PRODUCTION SYSTEM
Our production system consist of a list of industry-specialized partnership factories accross China. Some of them singularly cover an area of over 10,000 square meters, including 5,000 square meters of workshop and warehouse and 1,500 square meters of office buildings. All of our technical staff has more than 10 years of experience in the design of water treatment systems, so we are able to provide the perfect solution for all kinds of water purification and sewage treatment applications.
Since the establishment, the Company has always regarded quality as the life of our business. We choose the best components only for the production of various water treatment systems. Our systems are easy to use and maintain, and they stays highly reliable even under toughest conditions.
Our FACTORY
