Continuous Electrodeionization Ultrapure Water Machine Continuous Desalination No Chemicals
Product Details:
| Place of Origin: | China |
| Brand Name: | Fenigal |
| Certification: | CE |
| Model Number: | EDI |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiable |
| Packaging Details: | standard export packing |
| Delivery Time: | 5- 8 work days |
| Supply Ability: | 60000 Units per Month |
|
Detail Information |
|||
| Applicable Industries: | Manufacturing Plant, Food & Beverage Factory, Home Use, Construction Works , Energy & Mining | Core Components: | Pressure Vessel, Pump |
|---|---|---|---|
| Product Name: | Electrodeionization EDI RO Purified Ultrapure Water Treatment Systems | Material: | FRP+UPVC/Stainless (Tanks) Customized |
| Maximum Total Chlorine (as Cl): | < 0.02 Ppm | Type: | Pre-treatment+RO+EDI (Customized) |
| Voltage: | 110V / 220V / 380V,50~60Hz | Working Pressure: | 0.2~0.3Mpa |
| Conductivity: | 18MΩ*CM | ||
| Highlight: | Continuous Electrodeionization ultrapure water machine,Continuous Desalination ultrapure water machine,Continuous ultra pure reverse osmosis system |
||
Product Description
Continuous Electrodeionization, Ultrapure Water Machine, Ultrapure Water Continuous Desalination, No Chemicals
ELECTRODEIONIZATION WATER TREATMENT SYSTEMS for Lab., Sanitary injection or boiler feed
Electrodeionization is a water treatment technology that uses electricity, ion exchange membranes, and resins to deionize water and separate dissolved ions (impurities) from the water. It differs from other water purification technologies in that it does not require the use of chemical treatment, typically the polishing process of reverse osmosis (RO). There are also EDI units, often called continuous electrodeionization (CEDI) because the electrical current continuously regenerates the resin mass. CEDI technology can achieve very high purities, with conductivity values below 0.1 µS/cm.
| Model No. | Flow Rates (GPM) | Voltage (DC) | Current (Amps) | ||||
| Product | Typical Operation |
Maximum |
Typ. (4ppm RO Feed) |
Max. (15ppm RO Feed) |
|||
| Avgerage | Peak | Concentrate | |||||
| EDI-2 | 2.00 | 3.00 | 0.20 | ||||
| EDI-5 | 5.00 | 7.50 | 0.50 | ||||
| EDI-9 | 9.00 | 13.50 | 0.90 | 300 | 2 | 6 | |
| EDI-12 | 12.50 | 18.80 | 1.25 | ||||
| EDI-15 | 15.00 | 22.50 | 1.50 | ||||
| EDI-22 | 22.50 | 33.80 | 2.25 | 250-300 | |||
| EDI-27 | 27.50 | 41.25 | 2.75 | 470 | 2 | 7 | |
| EDI-55 | 55.00 | 82.50 | 5.50 | 600 | 2 | 7 | |
| EDI-82 | 82.50 | 123.75 | 8.25 | 470 | 4 | 14 | |
| EDI-110 | 110.00 | 165.00 | 11.00 | 600 | 4 | 14 | |
| EDI-165 | 165.00 | 247.50 | 16.50 | 600 | 6 | 21 | |
| EDI-220 | 220.00 | 330.00 | 22.00 | 600 | 8 | 28 | |
FEED WATER SPECIFICATIONS
- Feed Water Conductivity Equivalent, including CO2
and Silica: < 40 µS/cm - Feed Water Source: RO permeate
- Temperature: 41 – 113 °F (5 – 45 °C)
- Inlet Pressure: = 100 psi (6.9 bar)
- Maximum Total Chlorine (as Cl): < 0.02 ppm
- Iron (as Fe): < 0.01 ppm
- Manganese (as Mn): < 0.01 ppm
- Sulfide (S2-): < 0.01 ppm
- pH: 4 – 11
- Total Hardness (as CaCO3): < 1.0 ppm
- Dissolved Organics (TOC as C): < 0.5 ppm
- Silica (SiO2): < 1.0 ppm
| Features: | Benefits of EDI: |
|
|
| The ideal applications for an Electro-Deionization Unit include: | ||
|
|
|
