Ultrapure 0.5-5m3/H Reverse Osmosis Water Purification System
Product Details:
| Place of Origin: | China |
| Brand Name: | Fenigal/OEM |
| Certification: | CE/NSF etc. |
| Model Number: | EDI |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard Export Wood Crate/Carton or Naked wrapped by film/Containerized |
| Delivery Time: | 15~30 days |
| Payment Terms: | T/T, Western Union, Paypal etc. |
| Supply Ability: | 200 set per month |
|
Detail Information |
|||
| Technology: | Pressurized Filtration | Material: | Carbon Steel/FRP/stainless Steel |
|---|---|---|---|
| Design: | Skid Mount/containerized | Water Temp.: | 5~35˚C |
| Water Flow Rate: | Up To 200 M3/day.vessel | Voltage: | 380V,415V,220V,can Be Customized |
| Application: | Surface, Underground Water, Sewage Water Treatment | Size: | Dia.20cm~180cm |
| Control: | Electronic,Manual/PLC | ||
| High Light: | 5m3/h reverse osmosis water purification system,ultrapure reverse osmosis water purification system,0.5m3/h ro water filter system |
||
Product Description
Ultrapure 0.5-5m3/H Reverse Osmosis Water Purification System
Ultrapure Reverse Osmosis Water Purification System RO Water Filter System 0.5-5m3/h
EDI device is a refined water treatment system, It usually works with RO reverse osmosis device to form the ultra-pure water treatment system, which contains pre-treatment, reverse osmosis and EDI. Such a system replaces the ion exchange equipment of traditional water treatment process. The inlet water request of EDI device is that resistivity should be 0.025~0.5MΩ.cm, and the outlet water of RO device can fully meet the requirement. EDI device can produce ultra-pure water, whose resistivity can be more than 15MΩ.cm.
Application ares of EDI device include microelectronics industry, semiconductor industry, power generation industry, pharmaceutical manufacturing industry and laboratory. And it can be used for pharmaceutical distilled water, water of food & beverage processing, water of chemical plant processing and other ultra-pure water application fields.
Features
1. No acid-alkali regeneration needed.
2. Continuous processing.
3. No need to deal with waste acid-alkali.
4. Low operation cost.
5. Simple system design.
6. Stable water quality.
7. Customizable according to customers'needs.
Base parameter
| Raw water | |
| TDS | <60mg/L |
| Inlet Temperature | 5~45ºC |
| Product water quality | |
| Water quality | <0.01uS/cm |
Product Specification
| Model | EDI-100 | EDI-200 | EDI-300 | EDI-400 | EDI-500 |
| Water Yield | 100 m3/d | 200 m3/d | 300 m3/d | 400 m3/d | 500 m3/d |
| Water Quality | <0.01 uS/cm | ||||
| Edi Recovery rate | 90% | ||||
| Operation Pressure | 1-2 Mpa | ||||
| Operating Voltage | 30~80V | 60~120V | 100~160V | 150~250V | 200~350V |
| Dimension(L*W*H) | 600*700*1400 mm |
800*700*1400 mm |
1000*700*1400 mm |
1500*1000*1600 mm |
2000*1200*1800 mm |
| Weight | 120KG | 200KG | 250KG | 320KG | 450KG |
For cost analysis(Operation Cost,Operation Cost analysis of chemicals,System Supplies Cost) of this product, please contact us.
