Product Details:

Place of Origin: China
Brand Name: Fenigal/OEM
Certification: CE/NSF etc.
Model Number: RON-3340~7340

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Export Wood Crate/Carton or Naked wrapped by film
Delivery Time: 15~30 days
Payment Terms: T/T, Western Union, Paypal etc.
Supply Ability: 50 set per month
Get Best Price Contact Now

Detail Information

Technology: Commercial Water Reverse Osmosis Design: Skid Mount
Recovery Rate: 65~75% Feed TDS/ppm: <2,000
Water Temp.: 5~35˚C PH: 4~9
TSS/mg/L: <5 Silt Density Index: <3
Free Chlorine Mg/L: 0 Dissolved Iron Mg/L: <0.1
Warranty: 1 Year Material: SS304/SS316L,carbon Steel
Voltage: 380V,415V,220V,can Be Customized Application: Water Purification,Filtration,pharmceutical,drinking Water,food
Size: Depends,1750*550*1650mm Type: Reverse Osmosis System
Function: Water Purifying, Desalination Desalination Rate: 99%,99.7%
Control: Electronic,Manual/PLC Ro Membrane: Vontron, Hydranautics Or DOW,4040
Pump: CNP / Grundfos,CNP
High Light:

32000GPD commercial water purification systems


OEM Reverse Osmosis Water Treatment System


32000GPD Reverse Osmosis Water Treatment System

Product Description

32000GPD Reverse Osmosis Water Treatment System

RON Series Commercial Reverse Osmosis Systems 13,000~32,000GPD Europe/NA Market


Designed to produce low dissolved solids water from tap or well water, these RO systems use high efficiency reverse osmosis membranes. These RO systems are designed to work at pressures of 150-250 psi for higher TDS water and use TW reverse osmosis membranes. The TW RO membranes offer higher salt removal and the higher operating pressure overcomes the loss of membrane flow due to higher TDS level.


Operation Specifications

Max. feed water temperature: 42°C
Equipment upgrade for TDS up to 5,000 ppm
Hydrogen Sulfide must be removed
Max. Silica tolerance: 25 ppm @ 60% recovery
Feed water TDS: 0-2,000 ppm
Operating pressure: 150 to 250 psi
pH tolerance range: 3-11
Max. Iron content: 0.05 ppm
Feed water pressure: 20 to 80 psi
Hardness over 1 GPG requires water softener
Turbidity should be removed
Operate at higher TDS by lowering recovery



Model Number Permeate Flow Rate Pressure Vessel 4" Membranes Motor Rating at 1,000 ppm Approx. Weight Dimensions
GPD M3/D Qty. Qty. 60Hz (hp) 50Hz (kw) LBS KG L”xW”xH” LxWXH (cm)
RON-3340 13,000 50 3 9 3 2.2 750 341 136x43x60 345x109x152
RON-5240 15,000 57 5 10 5 3 850 386 96x43x60 244x109x152
RON-4340 18,000 68 4 12 5 2.2 875 398 136x43x60 345x109x152
RON-5340 22,000 85 5 15 5 3 900 409 136x43x60 345x109x152
RON-8240 24,000 91 8 16 5 3 950 432 96x43x68 244x109x173
RON-6340 27,000 102 6 18 5 3 990 450 136x43x68 345x109x173
RON-7340 32,000 121 7 21 5 4 1025 466 136x43x68 345x109x173


Voltage Codes:

235 = 230v, 3ph, 50hz

236 = 240v, 3ph, 60hz

335 = 380v, 3ph, 50hz

435 = 400/415v, 3ph, 50hz

436 = 460v, 3ph, 60hz


Standard Features: Available Options:

4” TFC spiral wound membranes

Stainless steel multi-stage pump with TEFC motor

FRP membrane housings

5 micron cartridge prefilter

Microprocessor based control panel

Programmable time delay and set points

LCD screen

Motor starter

Low pressure switch

High pressure switch

Liquid filled pressure gauges

Permeate conductivity monitor

Permeate & concentrate flow meters

SS pressure vessels

High pressure switch

pH or ORP meter

Recycle flow meter

Product tank float switch

Automatic flush

Export wood crating

Media filters

Ozonation system/UV sterilizers

Water softeners

Skid mounted with pre and post treatment

Solar powered systems


The ideal applications for brackish reverse osmosis systems include:

Metal Finishing
Beverage Production and Bottled Water
Mining Industry
Chemical Blending
Safe Drinking Water
Rinse Water
Power Plants
Plating Operations
EDI Pre-treatment
Food and Beverage
Spot Free Product Rinse
Cooling Towers
Boiler Feed Water
Ice Manufacturing
Ion Exchange Pre-treatment
