1. Chemical corrosion resistance and residual chlorine leakage resistance: The anti-pollution reverse osmosis membrane works in a wide pH range (pH 1~13), has strong chemical stability, and can withstand slight residual chlorine leakage, which increases the safety of use.
2. Intelligence and automation: The equipment adopts electrical control, with a high degree of automation, and can accurately calculate the amount of asphalt spraying and stone chip spreading, reducing manual operation and improving work efficiency.
3. Wide application scenarios: The anti-pollution reverse osmosis membrane is suitable for multiple fields, including pure water and ultrapure water preparation, biopharmaceutical water, wastewater treatment, etc. Its high efficiency and stable performance make it perform well in the fields of deep treatment of industrial wastewater, reuse of urban sewage treatment, and desalination of seawater.
It is applicable to the desalination of surface water, groundwater and water treatment with salt concentration between 2000 and 8000ppm. It can be widely used in the medicine, chemical industry, beverage, electricity and other various industries etc..
| Model | Active Membrane Area ft2(m2) |
Concentrate Channel Spacer (mil) |
Permeate Flow GPD(m3/d) |
Stable Rejection Rate (%) |
Minimum Rejection Rate (%) |
| BW-8040FR | 365(33.9) | 34 | 9500(35.9) | 99.70 | 99.60 |
| Concentration of Solution (NaCl) | Temperature(℃) | pH Value | Operating Pressure psi(MPa) | Recovery Rate(%) |
| 2000mg/L | 25 | 7.5-8 | 225(1.55) | 15 |
Notes: The permeate flow of single membrane element may vary with in ±15%.
Operating Limits and Conditions of Membrane Element:
| Max.Working Pressure | 600 psi(4.14MPa) |
| Max. FeedWater Temperature | 45 ℃ |
| Max. FeedWaterSDI15 | 5.0 |
| Max. Feed Water Flow | 17m3/h |
| Free Chlorine Concentration of FeedWater | 0.1mg/L |
| pH Range of FeedWaterDuring Continuous Operation | 3-10 |
| pH Range of FeedWaterDuring Chemical Cleaning | 1-13 |
| Max. Pressure Drop of Single Membrane Element | 15psi(0.1Mpa) |

![]() |
![]() |
