BW Reverse Osmosis Membranes Element-BW-4040HR For High Fluorine Content Groundwater
Product Details:
| Place of Origin: | China |
| Brand Name: | Keensen |
| Certification: | CE |
| Model Number: | BW-4040HR |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiable |
| Packaging Details: | standard export packing |
| Delivery Time: | 5- 8 work days |
| Supply Ability: | 60000 Units per Month |
|
Detail Information |
|||
| Active Membrane Area Ft2(m2): | 85(7.9) | Usage Of This Membrane: | It Is Applicable To Treatment With High Hardness、high Fluorine Content Groundwater And Surface Water In Northwest China. Specifications & Parameters |
|---|---|---|---|
| The Introduction Of This Product: | High Rejection Rate, Large Flux And Excellent Anti-fouling Property. | Max. Pressure Drop Of Single Membrane Element Of This Product: | 15psi(0.1Mpa) |
| PH Range Of Feed Water During Chemical Cleaning Of This Product: | 1-13 | PH Range Of Feed Water During Continuous Operation: | 2-11 |
| Max. FeedWaterSDI15 Of This Model: | 5.0 | ||
| Highlight: | BW Reverse Osmosis Membranes Element,BW-4040HR Reverse Osmosis Membranes |
||
Product Description
BW Reverse Osmosis Membranes Element-BW-4040HR For High Fluorine Content Groundwater
1. High desalination rate of brackish water reverse osmosis membrane: adopting new coating technology and automated membrane winding process, the standard desalination rate of membrane elements can reach more than 99.5%.
2. High water production rate of brackish water reverse osmosis membrane: precise interface reaction control technology makes the comprehensive desalination rate and water production of brackish water reverse osmosis membrane elements reach domestic high levels.
3. Strong anti-fouling property of brackish water reverse osmosis membrane: adopting coating technology to modify the membrane surface physically and chemically; reduce membrane pollution and improve anti-fouling performance.
It is applicable to treatment with high hardness,high fluorine content groundwater and surface water in northwest China.
| Model | Active Membrane Area ft2(m2) | Permeate Flow GPD(T/D) | Stable Rejection Rate (%) |
| BW-4040HR | 85(7.9) | 2000(7.6) | 99.7 |
| Concentration of Solution (NaCl) | Temperature(℃) | pH Value | Operating Pressure psi(MPa) | Recovery Rate(%) |
| 2000ppm | 25 | 7.5-8 | 225(1.55) | 15 |
Notes: The permeate flow of single membrane element may vary with in ±15%.
Operating Limits and Conditions of Membrane Element:
| Max.Working Pressure | 600 psi(4.14MPa) |
| Max. FeedWater Temperature | 45℃ |
| Max. Feed Water Flow | 3.6m3/h |
| Max. FeedWaterSDI15 | 5.0 |
| Free Chlorine Concentration of Feed Water | 0.1mg/L |
| pH Range of Feed Water During Continuous Operation | 2-11 |
| pH Range of Feed Water During Chemical Cleaning | 1-13 |
| Max. Pressure Drop of Single Membrane Element | 15psi(0.1Mpa) |
|
|
Manufacturer, excellent strength
The membrane production process and automated production line introduced from the United States, with an annual production capacity of 3 million square meters of reverse osmosis membranes and nanofiltration membranes. The team has strong and unique R&D and innovation capabilities, and strong technical support can provide customers with customized industry solutions to meet customers' deep and multi-faceted needs.
Quality assurance, superior performance
The entire reverse osmosis membrane and nanofiltration membrane product production process is strictly carried out in accordance with ISO standards. All products are strictly tested with advanced testing equipment to ensure product performance and factory quality.
National qualifications, look for Qinsen Hi-Tech
It has more than 30 international and domestic invention patents, and has fully passed the ISO9001 quality system and national health safety product certification of national authoritative institutions, and the NSF certification of the National Health Foundation of the United States.
