CMS Containerized Water Treatment Plant
|Place of Origin:||China|
Payment & Shipping Terms:
|Minimum Order Quantity:||1 Set|
|Packaging Details:||Standard Export Wood Crate/Carton or Naked wrapped by film|
|Delivery Time:||15~30 days|
|Payment Terms:||T/T, Western Union, Paypal etc.|
|Supply Ability:||50 set per month|
|Technology:||Reverse Osmosis||Design:||Skid Mount Containerized|
|Permeate Flow/TPD:||10~50||Permeate Flow/GPD:||2,632~13,158|
|Recovery Rate:||40~70%||Feed TDS/ppm:||<5,000|
|TSS/mg/L:||<5||Silt Density Index:||<3|
|Free Chlorine Mg/L:||0||Dissolved Iron Mg/L:||<0.1|
|Warranty:||1 Year||Material:||SS304/SS316L,carbon Steel|
|Capacity:||0.5-100m3/h||Voltage:||380V,415V,220V,can Be Customized|
|Application:||Water Purification,Filtration,pharmceutical,drinking Water,food||Size:||Depends,1750*550*1650mm|
|Type:||Reverse Osmosis System||Function:||Water Purifying, Desalination|
|Ro Membrane:||Hydranautics Or DOW,4040||Pump:||CNP / Grundfos,CNP|
100m3/h Containerized Water Treatment Plant,
CMS Containerized Water Treatment Plant,
20ft mobile water treatment systems
CMS Containerized Water Treatment Plant
Containerized and Mobile (CMS) Commercial & Industrial Water Systems
We offer a full line of robust containerized and mobile packaged plants, to the latest in wastewater and reuse solutions.
Modular system designs accommodate a wide variety of feed sources, including brackish water, surface water, seawater, reuse water and wastewater. Containerized and Mobile Water Systems can be operated in the most rugged environments and be deployed, as well as installed quickly to seamlessly provide large quantities of water on-demand.
These solutions are ideal for fast response, emergency situations, supplemental, or temporary requirements. They are often used to assist industrial customers during plant start up, piloting and maintenance outages or when a plant’s water treatment system is unavailable or cannot meet the water production requirements.
We design and manufacture a variety of containerized and mobile water treatment systems customized to fit any application. Our containerized and mobile systems are equipped for various applications using reverse osmosis, nanofiltration, ultrafiltration, and more. We can engineer containerized units that can be utilized for various applications including seawater, military, disaster preparedness etc. just to name a few. Most containerized systems can be designed with pre–treatment, reverse osmosis systems, membrane cleaning systems, storage tanks and media filtration as well as insulation, lighting, and air conditioning for the container itself.
|Rated Product Flow 1)||M3/H||0.8||2.3||3.5||4.5||6.5|
|Rated Recovery Rate 1)||%||34||34||34||34||34|
|Min Pressure In2)||barg||4||4||4||4||4|
|Max Pressure In 2)||barg||6||6||6||6||6|
|Min System Pressure3)||barg||20||20||20||20||20|
|Max System Pressure3)||barg||70||70||70||70||70|
|RO Membrane Spec.||inch||4040||8040||8040||8040||8040|
|RO Membrane Qty.||pcs||6||4||6||8||12|
|Container size (qty)||ft||10||10||20||20||20|
|Weight (dry) 4)||ton||3||3||5||6||7|
|Power Input 6)||3PH, 380 AC±10%, 50Hz|
|Rated Product Flow 1)||M3/H||4.5||6.5||9.5||12.5||21.5||32||41.5|
|Rated Recovery Rate 1)||%||35||35||36||36||45||45||45|
|Min Pressure In 2)||barg||4||4||4||5||5||5||5|
|Max Pressure In||barg||6||6||6||7||7||7||7|
|Min System Pressure 3)||barg||20||20||20||20||20||20||20|
|Max System Pressure 3)||barg||70||70||70||70||70||70||70|
|RO Membrane Spec.||8040||8040||8040||8040||8040||8040||8040|
|RO Membrane Qty.||pcs||8||12||18||21||42||56||70|
|Container size (qty)||ft||20||20||40||40||40||40(2)||40(2)|
|Weight (dry) 4)||ton||6||7||11||12||15||24||28|
|Rated Power 5)||kW||17||23||30||36||69||92||119|
|Input 6)||3PH 380V AC±10%,50Hz|
Desalination system is designed to produce high quality portable water from seawater or high salinity brackish water.
Together with our 2nd pass RO or even EDI system, it could provide highly pure water for industrial or commercial usage.
It can produce fresh water from 20 to 1000 ton (5-260 thousand gallons) per day.
Whether your application is drinking, process, or waste water. An onsite containerized water or wastewater treatment system is more practical and cost effective instead of buying treated water or discharging the wastewater to water treatment facilities to remove harmful contaminants from the water. Here are some industries that employ the most use of containerized water treatment systems:
- Public Delivery
- Disaster Relief
- Swimming Pools
- Power & Energy
