3000GPD Seawater Reverse Osmosis Desalination Plant
Product Details:
| Place of Origin: | China |
| Brand Name: | Fenigal/OEM |
| Certification: | CE/NSF etc. |
| Model Number: | SM-3,000GPD~7,000GPD |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard Export Wood Crate/Carton or Naked wrapped by film |
| Delivery Time: | 15~30 days |
| Payment Terms: | T/T, Western Union, Paypal etc. |
| Supply Ability: | 50 set per month |
|
Detail Information |
|||
| Technology: | Reverse Osmosis | Design: | Skid Mount |
|---|---|---|---|
| Recovery Rate: | 27~48% | Feed TDS/ppm: | <42,000 |
| Water Temp.: | 5~35˚C | PH: | 4~9 |
| TSS/mg/L: | <5 | Silt Density Index: | <3 |
| Free Chlorine Mg/L: | 0 | Dissolved Iron Mg/L: | <0.1 |
| Warranty: | 1 Year | Material: | SS304/SS316L,carbon Steel |
| Voltage: | 380V,415V,220V,can Be Customized | Application: | Water Purification,Filtration,pharmceutical,drinking Water,food |
| Size: | Depends,1750*550*1650mm | Type: | Seawater Reverse Osmosis System |
| Function: | Water Purifying, Desalination | Desalination Rate: | 99%,99.7% |
| Control: | Electronic,Manual/PLC | Ro Membrane: | Hydranautics Or DOW,4040 |
| Pump: | Danfoss/CAT/CNP | ||
| Highlight: | 3000GPD seawater reverse osmosis desalination plant,OEM seawater reverse osmosis desalination plant,3000GPD reverse osmosis desalination system |
||
Product Description
SM series Seawater Reverse Osmosis Desalination System 3,000GPD~7,000GPD
SM – Series Reverse Osmosis Systems are designed and manufactured for seawater applications requiring capacities of 3,000 to 7,000 gallons per day.
SM – Series Reverse Osmosis Systems are equipped with premium components, which include a 316L plunger–type pump for high performance and corrosion resistance, a high grade corrosion resistant aluminum frame, a programmable computer controller with many built–in features and fiberglass membrane housings for durability.
Features
|
Micro-computer Controller LCD Backlit Display Pre–Treatment Lockout Tank Level Input Low and High Pressure Monitoring and Alarm Permeate TDS Monitoring Hour Meter Feed Flush High Rejection Sea Water Membranes FRP – Series Membrane Housings 5 – Micron Sediment Pre–Filter by Pentek® Single O–Ring Cartridge Housing Permeate and Concentrate Flow Meters |
Motorized Valve PVC 0 – 100 psi Pre–Filter Out Pressure Gauge 0 – 1500 psi Concentrate Pressure Gauge 316L Stainless Steel Needle Valve SS Feed Low Pressure Switch SS Pump High Pressure Switch Pressure Relief Valve Pressure Regulator 316L High Pressure Pump TEFC Motor with Thermal Motor Protection White Powder Coated Aluminum Frame High Pressure 316L Stainless Steel Tubing and Fittings High Pressure Hose with Reusable SS Fittings |
Technical Specifications
| Models | SM – 4140 | SM – 5140 | SM – 6140 |
| Design | |||
| Configuration | Single Pass | Single Pass | Single Pass |
| Feedwater Source† | <45,000 ppm | <45,000 ppm | <45,000 ppm |
| System Recovery with Recycle % | 27 – 48 | 27 – 48 | 27 – 48 |
| Rejection and Flow Rates††† | |||
| Nominal Salt Rejection % | 99.4 | 99.4 | 99.4 |
| Permeate Flow Rate (gpm / lpm) | 2.70 / 10.22 | 3.47 / 13.13 | 4.80 / 18.17 |
| Concentrate Flow Rate (minimum) (gpm / lpm) | 4.00 / 15.00 | 4.00 / 15.00 | 4.00 / 15.00 |
| Connections | |||
| Feed Connection (in) | 1 FNPT | 1 FNPT | 1 FNPT |
| Permeate Connection (in) | 1 FNPT | 1 FNPT | 1 FNPT |
| Concentrate Connection (in) | 1 FNPT | 1 FNPT | 1 FNPT |
| Membranes | |||
| Membrane(s) Per Vessel | 1 | 1 | 1 |
| Membrane Quantity | 4 | 5 | 6 |
| Membrane Size | 4040 | 4040 | 4040 |
| Vessels | |||
| Vessel Array | 1:1:1:1 | 1:1:1:1:1 | 1:1:1:1:1:1 |
| Vessel Quantity | 4 | 5 | 6 |
| Pumps | |||
| Pump Type | Piston | Piston | Piston |
| Motor HP | 7.5 | 7.5 | 7.5 |
| RPM at 60Hz | 3600 | 3600 | 3600 |
| System Electrical | |||
| Controller | S – 150 | S – 150 | S – 150 |
| High Voltage Service + Amp Draw | 220V, 3PH, 60Hz, 20A** | 220V, 3PH, 60Hz, 20A** | 220V, 3PH, 60Hz, 20A** |
| Systems Dimensions | |||
| Approximate Dimensions* L x W x H (in / cm) | 60 x 26 x 48.5 / 152.4 x 66.0 x 123.2 |
60 x 26 x 48.5 / 152.4 x 66.0 x 123.2 |
60 x 26 x 48.5 / 152.4 x 66.0 x 123.2 |
| Approximate Weight (lbs / kg) | 270 / 122.47 | 300 / 136.08 | 330 / 149.68 |
Test Parameters: 35,000 TDS Filtered (5 – Micron), Dechlorinated, Municipal Feedwater, 65 psi / 4.50 bar Feed Pressure, 950 psi / 65.5 bar Operating Pressure, 77ªF / 25ªC, Recovery as stated, 7.0 pH. Data taken after 60 minutes of operation.
* Does not include operating space requirements.
** Varies with motor manufacturer.
Operating Limits
| Design Temperature (°F / °C) | 77 / 25 | Maximum Turbidity (NTU) | 1 |
| Maximum Feed Temperature (°F / °C) | 85 / 29 | Maximum Free Chlorine (ppm) | 0 |
| Minimum Feed Temperature (°F / °C) | 40 / 4 | Maximum TDS (ppm) | < 45,000 |
| Maximum Ambient Temperature (°F / °C) | 120 / 49 | Maximum Hardness (gpg) | 1 |
| Minimum Ambient Temperature (°F / °C) | 40 / 4 | Maximum pH (Continuous) | 11 |
| Maximum Feed Pressure (psi / bar) | 65 / 4 | Minimum pH (Continuous) | 2 |
| Minimum Feed Pressure (psi / bar) | 45 / 3 | Maximum pH (Cleaning 30 Minutes) | 13 |
| Maximum Operating Pressure (psi / bar) | 1,000 / 69 | Minimum pH (Cleaning 30 Minutes) | 1 |
| Maximum Feed Silt Density Index (SDI) | <3 |
Low temperatures and feedwater quality, such as high TDS levels will significantly affect the systems production capabilities and performance. Computer projections must be run for individual applications which do not meet or exceed minimum and maximum operating limits for such conditions.
System pressure is variable due to water conditions. Permeate flow will increase at a higher temperature and will decrease at a lower temperature.
Product flow and maximum recovery rates are based on feedwater conditions as stated above. Do not exceed recommended permeate flow.
More information about SWRO
What is seawater reverse osmosis?
Seawater reverse osmosis systems are designed to decline more than 99% of saline compromised within the feed water. These systems also incorporate a rinsing, chemical purifying apparatus to eliminate sodium chloride, avert scaling, and preserve system performance. There are two fundamental elements within every seawater reverse osmosis system, which are reverse osmosis membranes and high pressure feed pumps. These elements make up the center of any reverse osmosis system and need special consideration and application for successful operation.
Does reverse osmosis remove salt from seawater?
Yes, semipermeable membranes enable the feed water to pass through it at a much higher volume than dissolved salts. Reverse osmosis systems work by applying pressure as freshwater streams through its membranes to filter out the concentrated saline in the feed water, as well as minerals and pollutants. These unwanted impurities are either flushed away, recycled, or processed. Seawater reverse osmosis systems utilize more than one membrane to boost the load of purified water turned out each day.
What are the advantages of desalination plants?
Seawater desalination has become a vital alternative to the production of pure freshwater throughout the areas of the world without drinkable water. As other sources such as rivers, lakes, wells, and springs have become more exhausted due to excessive extraction, the ocean has provided an abundant supply of available water for human use. Although ocean water consists of elevated levels of salt, and therefore is unable to be utilized for consumption or most other purposes, seawater desalination has helped make it practical.
