Product Details:

Place of Origin: China
Brand Name: Fenigal/OEM
Certification: CE etc.
Model Number: SF

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Export Wood Crate/Carton or Naked wrapped by film/Containerized
Delivery Time: 15~30 days
Payment Terms: T/T, Western Union, Paypal etc.
Supply Ability: 200 set per month
Get Best Price Contact Now

Detail Information

Technology: Pressurized Filtration Material: Carbon Steel
Design: Skid Mount/containerized Water Temp.: 5~35˚C
Water Flow Rate: Up To 2~100 M3/H.vessel Voltage: 380V,415V,220V,can Be Customized
Application: Surface, Underground Water, Sewage Water Treatment Size: Dia.50cm~320cm
High Light:

15m/h multi media filter water treatment

,

bypass filtration multimedia filter water treatment

,

shallow sand multimedia filter water treatment

Product Description

Bypass Filtration Shallow Sand Multimedia Filter Water Treatment 5-12m/H Maximum 15m/H

Automatic Multimedia Bypass Filtration Shallow Sand Filter 5-12m/H and Maximum 15m/H

Industrial Water System Side Stream Shallow Sand Filter


Technical Parameters:

Working temperature

5~40 ºC

Working filtration rate

20~30 m/h and maximum 20 m/h

Material

Cylinder material : 304,316L and Q235

Working pressure

0.05~1.0 Mpa

Filtration flow rate

Stand-alone flow rate : 0.3~100 m3/h



Shallow Sand Filters are specially designed for higher flow rates per unit cross sectional area. In the conventional filters, water first hits the fine bed, where the suspended and turbid particles are trapped making imperative, the requirement of costly equipment like blower for the agitation of fine bed, so that the trapped particles are loosened and removed during the backwash.

Shallow Sand Filters normally used for industrial cooling tower. Cooling Towers, by design, flush airborne contamination such as biocides, heat, slime or silt into the system, where they deposit on heat exchange surfaces. Suspended matter in the cooling water also supplies living microorganisms with a constant food source for sustaining life and multiplying. Shubahm provide suitable cooling tower Side Stream Sand Filters which can remove all the physical contamination from the water which affects the life and efficiency of the cooling towers system.

Advantages and Features of side stream sand filters:

Efficient Turbidity and TSS Removal Filtration up to 20 - 30 Microns FRP, CS, MSEP, SS Vessel available Pressure Vessel is also available Standard and effective media Low Pressure drop across the vessel Air scouring available for high flow pressure vessel Automatic Valves are provided as per customer need Manual, Semi Automatic and Automatic features are provided.

Technology Applications

The following are applications where the addition of a side stream filtration system can improve the water and energy efficiency of the system.
Systems for which the primary source of makeup water is a surface or other unclarified source.
Systems with difficult biological problems, even with the presence of a good biocide program.
Systems that are susceptible to fouling due to either the nature of the application or the environment in which they operate.
Systems where scaling deposits cause a loss of heat transfer.
Systems with high levels of solids buildup in the sump due to dirt and debris deposited by windy conditions.
Systems in which the heat exchangers require frequent mechanical cleaning
Technical description of by-pass filter for the industrial circulating water
Flow filter flow is designed according to 5% to 10% of the total circulation volume (the by-pass filter flow of the cooling water is designed by 10 % of the circulation volume and the by-pass filter flow of chilled water is designed by 5% of the circulation volume) and the filtration rate is designed by 20 — 3Smih according to water quality of the system. Specific to corrosive suspended solids of the circulating water system as well as the control, our technical support team has designed a variety of manual/automatic by-pass filtrating equipment in line with customer demand.

The characteristics of the filtration system
1. Manual or automatic control is available;
2. Water distributor is simple, uniform and reliable;
3. Finished water collector has high strength and long service life;
4. Easy to install. Only connect the inlet and outlet to the waste pipe when installing;
5. Less water consumption in backwash: A homogeneous filter is used, so that backwash cycle is extended and the total backwash water volume is greatly reduced;
6. High backwash efficiency: An advanced water collector is used, ensuring efficient backwash effect.

FAQ:

01. how small a solid needs to be removed,
02. how dirty the water is,
03. how the water will be used once it is filtered,
04. and the source of backwash water needed to clean the filters.



model Filter diameter Height inlet-outlet Filtration area capacity
mm mm mm m³/hour
SF-500 500 816 40 0.2 6~10
SF-600 600 874 40 0.28 8~14
SF-700 700 900 40 0.38 12~19
SF-800 800 960 DN50 0.50 15-25
SF-1000 1000 1200 DN50 0.79 23-39
SF-1200 1200 1400 DN80 1.13 33-55
SF-1400 1400 1600 DN100 1.54 45-75
SF-1600 1600 1800 DN100 2.01 60-100
SF-1800 1800 1950 DN150 2.54 75-125
SF-2000 2000 2150 DN150 3.14 95-155
SF-2200 2200 2250 DN150 3.80 115-190
SF-2400 2400 2100 DN150 4.52 130-210
SF-2600 2600 2400 DN150 5.30 145-225
SF-2800 2800 2500 DN200 6.15 155-240
SF-3000 3000 2600 DN200 7.00 170-255
SF-3200 3200 2800 DN250 8.15 270-320



Bypass Filtration Shallow Sand Multimedia Filter Water Treatment 5-12m/H Maximum 15m/H 0

Bypass Filtration Shallow Sand Multimedia Filter Water Treatment 5-12m/H Maximum 15m/H 1

Bypass Filtration Shallow Sand Multimedia Filter Water Treatment 5-12m/H Maximum 15m/H 2

Bypass Filtration Shallow Sand Multimedia Filter Water Treatment 5-12m/H Maximum 15m/H 3
