Edi Electronic Ultrapure Ro Skid For Semiconductor Manufacturers

Edi Electronic Ultrapure Ro Skid For Semiconductor Manufacturers

Product Details:

Place of Origin: China
Brand Name: Fenigal/OEM
Certification: CE etc.
Model Number: Siro-DP

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard Export Wood Crate/Carton or Naked wrapped by film
Delivery Time: 15~30 days
Payment Terms: T/T, Western Union, Paypal etc.
Supply Ability: 50 set per month
Get Best Price Contact Now

Detail Information

Technology: Reverse Osmosis Design: Skid Mount
Permeate Flow/TPD: 10~1000 Recovery Rate: 60~90%
Feed TDS/ppm: <2,000 Water Temp.: 5~35˚C
Material: SS304/SS316L,carbon Steel Free Chlorine Mg/L: 0
Silt Density Index: <3 Dissolved Iron Mg/L: <0.1
Size: Depends,1750*550*1650mm Capacity: 0.5-110m3/h
Desalination Rate: 98%, 99% TSS/mg/L: <5
Voltage: 380V,415V,220V,can Be Customized Application: School, Restaurant, Offices
PH: 3~9 Pump: CNP / Grundfos,CNP
Type: Reverse Osmosis System Function: Water Purifying, Desalination
High Light:

semiconductor manufacturers ro skid

,

edi ro skid

,

ultrapure reverse osmosis skid

Product Description

Edi Electronic Ultrapure Ro Skid For Semiconductor Manufacturers

EDI Electronic Ultrapure Reverse Osmosis Water Equipment for Semiconductor manufacturers

What is RO System?
The reverse osmosis equipment adopts the osmosis filtration process of reverse osmosis membrane, which is a modern new pure water treatment technology.Reverse osmosis membrane by means of choice through (through) membrane function to pressure as the driving force of membrane separation technology, when system and the pressure is greater than in the aqueous solution of osmotic pressure, the water molecules through the membrane unceasingly, after producing water flows into the central tube, and then out in the end the impurities in the water, such as ion, organic matters, such as bacteria, viruses, interception on the inlet side of the membrane, and then in the thick water outflow water end, so as to achieve separation and purification.

What is EDI system?
Electrodeionization is a water treatment technology that utilizes an electricity, ion exchange membranes and resin to deionize water and separate dissolved ions (impurities) from water. It differs from other water purification technologies in that it is done without the use of chemical treatments and is usually a polishing treatment to reverse osmosis (RO). There are also EDI units that are often referred to as continuous electrodeionization (CEDI) since the electric current regenerates the resin mass continuously. CEDI technique can achieve very high purity, with conductivity below 0.1 µS/cm.

Working process of EDI system:
Raw water(inlet water) → raw water tank → feed pump → sand filter → activated carbon filter → cartridge filter,precision filter → high pressure pump →RO unit → pure water tank → (UV light sterilizer or ozone sterilizer) use

Raw water(inlet water) → raw water tank → feed pump → sand filter → activated carbon filter → cartridge filter,precision filter → high pressure pump →Stage I RO unit → Stage II RO unit →middle water tank → EDI system → polished mixing bed → pure water tank → (UV light sterilizer or ozone sterilizer) use

Application scope of equipment:
water stores,beverage bottlting,spot free make-up water,boiler feed
car wash,hydroponics,window and solar panel washing
manufacturing process
potable water from wells,pharmaceutical makeup,cosmetic product feed water,food manufacturing,coffee makeup

Operation Specifications

Max. feed water temperature: 42°C
Equipment upgrade for TDS up to 5,000 ppm
Hydrogen Sulfide must be removed
Max. Silica tolerance: 25 ppm @ 60% recovery
Feed water TDS: 0-2,000 ppm
Operating pressure: 150 to 250 psi
pH tolerance range: 3-11
Max. Iron content: 0.05 ppm
Feed water pressure: 20 to 80 psi
Hardness over 1 GPG requires water softener
Turbidity should be removed
Operate at higher TDS by lowering recovery



Technical Specification

Model Number Permeate Flow Rate Membranes Motor Rating at 1,000 ppm Approx. Weight Dimensions
GPD M3/D Size Qty. 60Hz (hp) 50Hz (hp) LBS KG L”xW”xH” LxWXH (cm)
ROS-1125 600 2 2.5"x40" 1 1/2 1/2 100 45 21x24x55 53x61x140
ROS-2125 1,200 5 2.5"x40" 2 1/2 1/2 110 50 21x24x55 53x61x140
ROS-3125 1,800 7 2.5"x40" 3 3/4 3/4 125 57 21x24x55 53x61x140
ROS-1140 1,500 6 4"x40" 1 1 1 125 57 21x25x55 53x64x140
ROS-2140 3,000 11 4"x40" 2 1 1 160 73 21x25x55 53x64x140
ROS-3140 4,500 17 4"x40" 3 1.5 1.5 190 86 21x25x55 53x64x140
ROS-4140 6,000 23 4"x40" 4 1.5 1.5 220 100 21x30x55 53x76x140
ROS-5140 7,500 28 4"x40" 5 2 2 250 114 21x30x55 53x76x140
ROS-6140 9,000 34 4"x40" 6 2 2 280 127 21x30x55 53x76x140
ROS-8140 12,000 45 4"x40" 8 3 3 380 173 27x34x56 69x86x142
ROS-10140 15,000 57 4"x40” 10 3 3 450 205 27x34x56 69x86x142
ROS-12140 18,000 68 4"x40” 12 3 3 500 227 27x40x56 69x102x142



Voltage Codes:

116 = 115v, 1ph, 60hz (up to ROS-2140 only)

215 = 220/230v, 1ph, 50hz

216 = 220/230v, 1ph, 60hz

235 = 240v, 3ph, 50hz (ROS-3140+ Only)

236 = 240v, 3ph, 60hz (ROS-3140+ Only)

335 = 380v, 3ph, 50hz (ROS-3140+ Only)

435 = 400/415v, 3ph, 50hz (ROS-3140+ Only)

436 = 460v, 3ph, 60hz (ROS-3140+ Only)

Product parameter:

Water volume(L/H) 100L 300L 500L 1000L 2000L 3000L 4000L 5000L
Product water resistivity( MΩ·cm) ≥15 ≥15 ≥15 ≥15 ≥15 ≥15 ≥15 ≥15
Operating Voltage(V) 35-45 55-65 50-80 80-100 100-150 150-200 200-350 200-350
Electric current(A) 2.0-2.5 2.0-2.5 2.0-2.5 2.0-2.5 2.0-2.5 2.0-2.5 2.0-2.5 2.0-2.5




Edi Electronic Ultrapure Ro Skid For Semiconductor Manufacturers 0

Edi Electronic Ultrapure Ro Skid For Semiconductor Manufacturers 1

Edi Electronic Ultrapure Ro Skid For Semiconductor Manufacturers 2

Desalination Rate
96%-98%
Recovery Rate
50%-75%
Motive Force
Environmental Protection, Water Treatment
Ca2+ & Mg2+
Softener Filter
Material
Full Stainless Steel 304
Control
Manual & Automatic
Disinfection
UV Sterilizer / Ozone Generator
Weight
650kg
Voltage
110V/ 220V/380V
Frequency
50Hz / 60Hz
Power
2.5 Kw
Warranty
1 Year
Trademark
FG
Transport Package
Wooden Case
Specification
2000X670X1700mm
Origin
Guangzhou, China
HS Code
8421219990
